GB/T 43081-2023: Lamps and light sources for road vehicles - Dimensional, electrical and luminous requirements Delivery: 9 seconds. True-PDF full-copy in English & invoice will be downloaded + auto-delivered via email. See step-by-step procedure Status: Valid
Excerpted PDFsFull copy of true-PDF will be delivered in 9 seconds upon purchase: GB/T 43081-2023Similar standardsGB/T 43017 GB/T 19258.1 GB 19258 GB/T 45515GB/T 43081-2023: Lamps and light sources for road vehicles - Dimensional, electrical and luminous requirements---This is an excerpt. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.), auto-downloaded/delivered in 9 seconds, can be purchased online: https://www.ChineseStandard.net/PDF.aspx/GBT43081-2023 GB NATIONAL STANDARD OF THE PEOPLE’S REPUBLIC OF CHINA ICS 29.140.99 CCS K 71 GB/T 43081-2023 / IEC 60809:2021 Replacing GB/T 15766.1-2008 Lamps and light sources for road vehicles - Dimensional, electrical and luminous requirements (IEC 60809:2021, IDT) ISSUED ON: NOVEMBER 27, 2023 IMPLEMENTED ON: JUNE 01, 2024 Issued by: State Administration for Market Regulation; National Standardization Administration. Table of ContentsForeword ... 3 1 Scope ... 5 2 Normative references ... 5 3 Terms and definitions ... 6 4 Requirements and test conditions for filament bulbs ... 10 5 Requirements and test conditions for discharge lamps ... 20 6 Requirements and test conditions for LED light sources ... 25 7 Sampling and compliance conditions ... 28 8 Lamp (data) sheets ... 28 Appendix A (Normative) Shape, length, position of the filament... 55 Appendix B (Normative) Method for measuring the color of filament bulbs ... 58 Appendix C (Normative) Test conditions for photoelectric performance ... 61 Appendix D (Normative) Method for measuring the internal parts of R2 bulbs ... 66 Appendix E (Normative) Measuring methods for internal parts of H4 and HS1 bulbs ... 71 Appendix F (Normative) Measuring method for internal parts of HB1 bulbs ... 78 Appendix G (Informative) Optical device for measuring arc position and shape and electrode position of discharge bulb ... 81 Appendix H (Normative) Methods for measuring the photoelectric performance of discharge lamps ... 83 Appendix I (Informative) Summary of lamp types and their applications ... 85 Appendix J (Normative) Test conditions for color durability measurement ... 88 Appendix K (Informative) Method for determining the value of the optical center length 5) of Lx3A, Lx3B, Lx4A, Lx4B, Lx5A, Lx5 4), L1A/6, L1B/6 ... 93 Appendix L (Informative) Method for determining the maximum brightness gradient of an LED light source ... 95 References ... 97ForewordThis document was drafted in accordance with the provisions of GB/T 1.1-2020 "Directives for standardization - Part 1: Rules for the structure and drafting of standardizing documents". This document replaces GB/T 15766.1-2008 "Lamps and light sources for road vehicles - Dimensional, electrical and luminous requirements". Compared with GB/T 15766.1- 2008, in addition to structural adjustments and editorial changes, the main technical changes are as follows: - ADD the terms and definitions of "luminous flux maintenance rate", "non- replaceable light source", "rated value" (see 3.8, 3.12, 3.13); - CHANGE the content of "color durability" (see 4.4.2; 2.4.2 of GB/T 15766.1-2008); - CHANGE the expression of the "color" range definition domain of filament lamps, changing the expression method of approach lines to the expression method of boundary lines and intersections (see 4.4; 2.4 of GB/T 15766.1-2008); - ADD the chromaticity requirements of "finished filament lamps emitting selective yellow light" in the "color" of filament lamps (see 4.8); - DELETE "Requirements for standard headlamps" (see 2.8.4 of GB/T 15766.1- 2008); - ADD the requirements for "non-replaceable filament bulbs" (see 4.11); - CHANGE the "rise characteristics" requirements for gas discharge bulbs (see 5.6.2; 3.6.2 of GB/T 15766.1-2008); - CHANGE the expression of the "color" range definition domain of gas discharge bulbs, changing the approach line expression method to the boundary line and intersection expression method (see 5.8; 3.8 of GB/T 15766.1-2008); - ADD the "LED light source requirements and test conditions" (see Chapter 6); - CHANGE the bulb type catalog to distinguish between bulb types that refer to R.E.5 and bulb types included in this document (see Table 3; Table 3 of GB/T 15766.1-2008); - DELETE the bulb type data leaflet in the "leaflet" that was repeated with UNR.E.5 (see Chapter 5 of GB/T 15766.1-2008); - ADD 9 filament bulb types and bulb data leaflets of "H6, HB1, S4, H5, H2, HS3, B1.13W, B0.6W, B2.4W" (see 8.3); Lamps and light sources for road vehicles - Dimensional, electrical and luminous requirements1 ScopeThis document applies to electric light sources in road vehicle lighting devices and/or light signal devices (see Note 1). It is particularly applicable to light sources listed in UN Resolution R.E.5 and light sources subject to other regulations. This document specifies the technical requirements for interchangeability, including dimensions, optoelectronic performance, as well as corresponding measurement methods. For the light sources listed in this document, their leaflets are either included in this document or refer to UN Resolution R.E.5. IEC 60810 specifies requirements for light source life, torsion strength, vibration and impact resistance. IEC 60983 specifies small road motor vehicle bulbs for auxiliary purposes that are not covered by regulations. Note 1: In this document, the terms "bulb" and "light source" refer to the same product, as these two terms are interchangeable in this document. Note 2: In different vocabularies and standards, different terms are used for "incandescent lamp" (845-07-04 in GB/T 2900.65-2004), "discharge lamp" (845-07-17 in GB/T 2900.65- 2004), "LED lamp". In this document, "filament lamp", "discharge lamp", "LED light source" are used. However, when only "lamp" and "light source" are written, it refers to lamps of these three technologies, unless the context clearly indicates that it is used to refer to lamps of a certain technology only. In UN regulations, the term "light source" is used for products specified in this document. Note 3: "Device" in this document refers to equipment used for lighting purposes. For example, equipment used as headlights or signal lights.2 Normative referencesThe contents of the following documents constitute essential provisions of this ......Source: Above contents are excerpted from the full-copy PDF -- translated/reviewed by: www.ChineseStandard.net / Wayne Zheng et al. |
