GB/T 42782-2023: Digital collaborative engineering - Collaborative design requirements

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS 01:100:01 CCSJ04 National Standards of People's Republic of China Digital Collaborative Engineering Collaborative Design Requirements Released on 2023-05-23 2023-09-01 implementation State Administration for Market Regulation Released by the National Standardization Management Committee

table of contents

Preface III 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 Abbreviations 1 5 Collaborative Design Classification 2 5:1 Overview 2 5:2 Collaboration in the design phase 2 5:3 Collaboration of Personnel Roles 2 5:4 Professional collaboration 2 5:5 Hierarchical Collaboration 2 5:6 Domain Collaboration 2 6 General requirements 2 6:1 Collaborative Environment Requirements 2 6:2 Data Collaboration Requirements 3 6:3 Process coordination requirements 3 7 Collaboration requirements in different design stages 3 7:1 Main stages of collaborative design 3 7:2 Collaborative design process at each stage 5 7:3 Design tasks and coordination requirements at each stage 8 7:4 Maturity-based collaboration between design phases 11 7:5 Collaboration requirements between different design stages 11 8 Collaboration requirements for different personnel roles12 8:1 Role definition of collaborative design 12 8:2 Job Responsibilities of Personnel Roles 12 9 Collaborative requirements of different disciplines13 9:1 General 13 9:2 Collaboration between 3D geometric model and simulation model 13 9:3 Synergy between simulation models and simulation models 14 9:4 Collaboration between 3D geometric model and process model 14 10 Collaboration requirements at different levels 15 10:1 General requirements 15 10:2 Top-down 3D geometric model construction 15 11 Collaboration requirements in different domains 16 11:1 Construction of cross-domain collaborative design environment 16 11:2 Cross-domain data synchronization 17 11:3 Security management of cross-domain collaboration 17 Appendix A (informative) Main tasks of different personnel roles in a collaborative environment18

foreword

This document is in accordance with the provisions of GB/T 1:1-2020 "Guidelines for Standardization Work Part 1: Structure and Drafting Rules for Standardization Documents" drafting: Please note that some contents of this document may refer to patents: The issuing agency of this document assumes no responsibility for identifying patents: This document is proposed and managed by the National Technical Product Document Standardization Technical Committee (SAC/TC146): This document is drafted by: Xidian University, China Machinery Productivity Promotion Center Co:, Ltd:, Inner Mongolia First Machinery Group Co:, Ltd: Co:, Ltd:, Lens System Integration Co:, Ltd:, Yalong Intelligent Equipment Group Co:, Ltd:, Shenzhen Dianlian Technology Co:, Ltd:, China Electronics Technology Group Corporation No: 38 Research Institute, Beijing Institute of Aerospace Systems Engineering, Baosteel Engineering Technology Group Co:, Ltd:, Shenzhen Today International Logistics Technology Co:, Ltd:, China Automotive Research Institute Automotive Industry Engineering (Tianjin) Co:, Ltd:, Beijing Guangyu Dacheng CNC Machine Tool Co:, Ltd:, Xiamen Calent Technology Co:, Ltd:, Shanghai Huice Information Technology Co:, Ltd:, Beijing Satellite Manufacturing Co:, Ltd:, Qingdao Ruizhi Intelligent Equipment Technology Co:, Ltd:, China Wuzhou Engineering Design Group Co:, Ltd:, Hangzhou Xindi Digital Engineering System Co:, Ltd:, Zhejiang Dingye Machinery Equipment Co:, Ltd: Company, Beijing Tiantuo Sifang Technology Co:, Ltd:, Jiangsu Changhong Intelligent Equipment Co:, Ltd:, Taizhou Eastern CNC Equipment Co:, Ltd:, Jiangxi Susideli Pharmaceutical Machinery Manufacturing Co:, Ltd:, Yidao Xin'an (Beijing) Technology Co:, Ltd:, Guangzhou Guangdian Metrology and Testing Co:, Ltd:, Ji Nansenfeng Laser Technology Co:, Ltd:, Suzhou Huaxing Yuanchuang Technology Co:, Ltd:, Orange Cloud Internet Design Co:, Ltd: The main drafters of this document: Shao Xiaodong, Wang Yunfeng, Lin Yu, Zhang Peng, Ma Tao, Chen Yunhua, He Xiaopeng, Liu Haizhou, Zheng Jushang, Zhang Hongqi, Cheng Wusi, Zhao Bo, Yuan Lei, Jin Tao, Xiao Lei, Yang Chuanyao, Sun Naijie, Ma Chunlei, Zhao Fu, Jiang Mingxia, Cao Minzhi, Wang Jinjiao, Ma Zhiwei, Chen Zhiyang, Liu Junlong, Wei Lei, Zuo Xiaofei, Yang Gengxin, Qiu Yunjie, Zhao Lingang, Gu Yi, Qian Pengjiang, Huang Caixia, Li Haibing, Ming Zhimao, Sun Mou, Li Fengxi, Xing Zhenhong, Jiang Bin, Wang Hu, Zhao Yingfang, Zhao Kerun: Digital Collaborative Engineering Collaborative Design Requirements

1 Scope

This document specifies the classification and general requirements of collaborative design in digital collaborative engineering of mechanical products, as well as requirements for different design stages and different Detailed requirements for personnel roles, different professions, different levels, and different domains for collaborative design: This document is applicable to the application of digital collaborative design of mechanical products:

2 Normative references

The contents of the following documents constitute the essential provisions of this document through normative references in the text: Among them, dated references For documents, only the version corresponding to the date is applicable to this document; for undated reference documents, the latest version (including all amendments) is applicable to this document: GB/T 24734:1 Technical Product Documentation Digital Product Definition Data General Rules Part 1: Terms and Definitions

3 Terms and Definitions

The following terms and definitions defined in GB/T 24734:1 apply to this document: 3:1 collaborative design colaborative design In order to achieve the same design goal, two or more design subjects apply the same or different design tools in the same One or different domains, through the agreed means of information interaction and coordination mechanism, apply a unified process and task management mechanism, respectively implement the same Or different design tasks, share design data and design status, and finally achieve the design method of the design goal together: 3:2 collaborative design (3:1) performed on two or more domains (network segments, servers or databases): 3:3 model maturity modelmaturity In the process of collaborative design (3:1), the quantification used to reflect the degree of perfection of the technical status of the 3D model from the initial design to the final controlled release index:

4 Abbreviations

The following abbreviations apply to this document: BOM: Bill of Materials (BilofMaterial) ......
