GB/T 39561.3-2020: Interconnection and interoperation of numerical control equipment - Part 3: Implementation oriented model mapping
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 39561.3-2020	559	Add to Cart	5 days	Interconnection and interoperation of numerical control equipment - Part 3: Implementation oriented model mapping	Valid

Similar standards

GB/T 39331   GB/T 16977   GB/T 36415   GB/T 39561.4   GB/T 39561.5   GB/T 39561.2

Basic data

Standard ID: GB/T 39561.3-2020 (GB/T39561.3-2020)
Description (Translated English): Interconnection and interoperation of numerical control equipment - Part 3: Implementation oriented model mapping
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J07
Classification of International Standard: 29.020
Word Count Estimation: 30,364
Date of Issue: 2020-12-14
Date of Implementation: 2021-07-01
Quoted Standard: GB/T 39561.1-2020
Regulation (derived from): National Standard Announcement No. 28 of 2020
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration
Summary: This standard specifies the rules and procedures for mapping the interconnection and interoperability of the equipment description model of CNC equipment to other communication protocol information models. This standard applies to the mapping of CNC equipment interconnection and interoperability equipment description model to MTConnect, OPC UA and other communication protocol information models.

GB/T 39561.3-2020: Interconnection and interoperation of numerical control equipment - Part 3: Implementation oriented model mapping

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
(Numerical control equipment interconnection and interoperability Part 3: Implementation-oriented model mapping) ICS 29:020 J07 National Standards of People's Republic of China Interconnection and interoperability of CNC equipment Part 3: Implementation-oriented model mapping 2020-12-14 release 2021-07-01 implementation State Administration for Market Regulation Issued by the National Standardization Management Committee

Table of contents

Foreword Ⅰ 1 Scope 1 2 Normative references 1 3 Terms, definitions and abbreviations 1 4 Model mapping content 1 5 Model mapping rules 2 Appendix A (informative appendix) Model mapping for MTConnect 4 Appendix B (informative appendix) OPCUA-oriented model mapping 17 Reference 27

Foreword

GB/T 39561 "Numerical Control Equipment Interconnection and Interoperability" contains the following parts: ---Part 1: General technical requirements; ---Part 2: Equipment description model; ---Part 3: Implementation-oriented model mapping: ---Part 4: CNC machine tool object dictionary; ---Part 5: Industrial Robot Object Dictionary; ---Part 6: CNC machine tool testing and evaluation; ---Part 7: Industrial robot testing and evaluation: This part is Part 3 of GB/T 39561: This section was drafted in accordance with the rules given in GB/T 1:1-2009: This part was proposed by China Machinery Industry Federation: This part is under the jurisdiction of the National Industrial Machinery Electrical System Standardization Technical Committee (SAC/TC231): Drafting organizations of this section: National Machine Tool Quality Supervision and Inspection Center, Tsinghua University, Shenyang High Precision CNC Intelligent Technology Co:, Ltd:, Qing University, China University of Petroleum (Beijing), Shandong Jianzhu University, Ministry of Industry and Information Technology, Computer and Microelectronics Development Research Center (China Software Evaluation Center), Chongqing Goog Technology Yangtze River Research Institute Co:, Ltd:, Qilu University of Technology, Shandong Yima Intelligent Technology Co:, Ltd:, Dongguan Mingling Industrial Automation Technology Co:, Ltd: The main drafters of this section: Huang Zuguang, Shao Zhufeng, Wang Liping, Zhang Zhaokun, Xue Ruijuan, Zhao Qinzhi, Yu Haoyu, Yan Ping, Wang Jinjiang, Ji Shuai, Yu Xian, Wu Di, Zhou Tingting, Ma Hongjun, Wang Manjiang: Interconnection and interoperability of CNC equipment Part 3: Implementation-oriented model mapping

1 Scope

This part of GB/T 39561 stipulates that the equipment description model for the interconnection and interoperability of numerical control equipment is used to transfer information from other communication protocols: Rules and procedures for type mapping: This part is applicable to the communication protocol information of CNC equipment interconnection and interoperability equipment description model to MTConnect, OPCUA, etc: Model mapping: Note: MTConnect is a communication protocol for the interconnection of CNC equipment:

2 Normative references

The following documents are indispensable for the application of this document: For dated reference documents, only the dated version applies to this article Pieces: For undated references, the latest version (including all amendments) applies to this document: GB/T 39561:1-2020 Interconnection and Interoperability of Numerical Control Equipment Part 1: General Technical Requirements 3 Terms, definitions and abbreviations 3:1 Terms and definitions The following terms and definitions defined in GB/T 39561:1-2020 apply to this document: 3:1:1 Sourcemodel The CNC equipment information model to be converted: 3:1:2 Targetmodel The model obtained after mapping the source model: 3:1:3 Modelmapping The method and process of converting the device description model into one or more communication protocols: 3:2 Abbreviations The following abbreviations apply to this document: ID: Identifier OPCUA: Open Platform Communication Unified Architecture (OpenPlatformCommunicationUnifiedArchitecture) XML: Extensible Markup Language (ExtensibleMarkupLanguage)

4 Model mapping content

Model mapping is to map the information model organized by a certain structure obtained locally by the CNC equipment into the information that conforms to certain general agreements: ......
