GB/T 38846-2020: Smart factory--Industrial automation systems engineering role class libraries
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 38846-2020	779	Add to Cart	6 days	Smart factory--Industrial automation systems engineering role class libraries	Valid

Similar standards

GB/T 38673   GB/T 38672   GB/T 38675   GB/T 45341   GB/T 38856

Basic data

Standard ID: GB/T 38846-2020 (GB/T38846-2020)
Description (Translated English): Smart factory--Industrial automation systems engineering role class libraries
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: L67
Classification of International Standard: 25.040
Word Count Estimation: 42,424
Date of Issue: 2020-07-21
Date of Implementation: 2021-02-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 38846-2020: Smart factory--Industrial automation systems engineering role class libraries

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Smart factroy--Industrial automation systems engineering role class libraries ICS 25.040 L67 National Standards of People's Republic of China Intelligent factory industrial automation system engineering Description library 2020-07-21 released 2021-02-01 implementation State Administration for Market Regulation Issued by the National Standardization Management Committee

Table of contents

Preface Ⅲ 1 Scope 1 2 Terms, definitions and abbreviations 1 2.1 Terms and definitions 1 2.2 Abbreviations 2 3 AML description class 2 3.1 AML basic description class library--AutomationMLBaseRoleClassLib 2 3.1.1 Overview 2 3.1.2 Description class AutomationMLBaseRole (AML basic description class) 4 3.1.3 Description class Group (group) 4 3.1.4 Description class Facet (face) 5 3.1.5 Description Port (Port) 5 3.1.6 Description Resource (Resource) 6 3.1.7 Description Product (product) 6 3.1.8 Description class Process (process) 7 3.1.9 Description Class Structure (Structure) 7 3.1.10 Description ProductStructure (product structure) 7 3.1.11 Description class ProcessStructure (process structure) 8 3.1.12 Description class ResourceStructure (resource structure) 8 3.1.13 Description Class PropertySet (Property Set) 8 3.2 Discrete manufacturing industry AML description class library---AutomationMLDMIRoleClassLib 9 3.2.1 General 9 3.2.2 Description class DiscManufacturingEquipment (discrete manufacturing equipment) 10 3.2.3 Description Transport (transmission) 10 3.2.4 Description class Storage (storage) 10 3.2.5 Description Fixture (fixed device) 10 3.2.6 Description class Gate (gate) 11 3.2.7 Description Robot (Robot) 11 3.2.8 Description Tool (tool) 11 3.2.9 Description Carrier (vehicle) 11 3.2.10 Description Machine (Mechanical) 12 3.2.11 Description class StaticObject (static object) 12 3.3 Process manufacturing industry AML description class library ---AutomationMLCMIRoleClassLib 12 3.3.1 General 12 3.3.2 Description class ContManufacturingEquipment (process manufacturing equipment) 13 3.4 Batch manufacturing industry AML description class library---AutomationMLBMIRoleClassLib 13 3.4.1 General 13 3.4.2 Description Class BatchManufacturingEquipment (batch manufacturing equipment) 14 3.5 Control system AML description class library---AutomationMLCSRoleClassLib 14 3.5.1 General 14 3.5.2 Description Class ControlEquipment (control equipment) 15 3.5.3 Description Communication (communication) 15 3.5.4 Description Class ControlHardware (control hardware) 16 3.5.5 Description PC (Personal Computer) 16 3.5.6 Description IPC (Industrial Computer) 16 3.5.7 Description Handheld (portable device) 16 3.5.8 Description class EmbeddedDevice (embedded device) 17 3.5.9 Description Sensor (Sensor) 17 3.5.10 Description class Actuator (actuator) 17 3.5.11 Description Controler (controller) 17 3.5.12 Description PLC (Programmable Logic Controller) 17 3.5.13 Description NC (Numerical Controller) 18 3.5.14 Description RC (Robot Controller) 18 3.5.15 Description PAC (Programmable Automatic Controller) 18 3.6 AML extended description class library---AutomationMLExtendedRoleClassLibrary 18 Appendix A (informative appendix) AML extended description class library 19 Appendix B (informative appendix) Describes application examples of class libraries 33

Foreword

This standard was drafted in accordance with the rules given in GB/T 1.1-2009. This standard was proposed by China Machinery Industry Federation. This standard is under the jurisdiction of the National Industrial Process Measurement Control and Automation Standardization Technical Committee (SAC/TC124). Drafting organizations of this standard. Shanghai Institute of Industrial Automation Instrumentation Co., Ltd., Institute of Comprehensive Technology and Economics of Mechanical Industry Instrumentation, Shanghai Institute of Metrology and Testing Technology, Dalian Yuyang Industrial Intelligence Co., Ltd. The main drafters of this standard. Xiao Honglian, Wang Jianing, Liu Xiaojing, Chen Xi, Li Wenjun. Intelligent factory industrial automation system engineering Description library

1 Scope

This standard specifies the normative and informative AML description library for engineering information modeling. This standard applies to the input/output application of related tools when information is exchanged between engineering tools in the automation area by means of AML. 2 Terms, definitions and abbreviations 2.1 Terms and definitions The following terms and definitions apply to this document. 2.1.1 Automation markuplanguage XML-based engineering data exchange format for intelligent factory industrial automation systems. 2.1.2 Object The data representation of an automation object with one or more CAEXRoleRequirements related to an AML role class. Note. AML object is the core element of automation markup language. It represents an instance and can include management elements, attributes, interfaces, relationships and references. 2.1.3 Class Predefined AML object types, which can be AML system unit classes, AML interface classes, AML role classes or AML attributes Types of. Note 1.The AML class is stored in the AML library. The type of the AML class is SystemUnitClass, InterfaceClass, RoleClass or AttributeType. Note 2.The AML class defines a reusable solution, which is characterized by attributes, interfaces and aggregate objects. Note 3.The AML class can be instantiated multiple times. Note 4.AML class can be user-defined or standard AML class. 2.1.4 Library Contains a library of AML classes. 2.1.5 Port An AML interface that has a direct or indirect relationship with the standard AML interface class Port, and allows you to specify nested interfaces. Note. The port belongs to a parent AML object, which describes various complex interfaces in the object. At a higher level of abstraction, ports can be implemented interconnected. 2.1.6 Group group An AML object that has a direct or indirect relationship with the standard AML role class Group, and provides a specific view of the AML object. 2.1.7 Facet An AML object that has a direct or indirect relationship with the standard AML role class Facet, and provides the AML attribute of an AML object ......
