Test method for volume fraction of reinforcement in metal matrix composites -- Image analysis method
|
Click to Preview a similar PDF
Basic data
| Standard ID | GB/T 32496-2016 (GB/T32496-2016) |
| Description (Translated English) | Test method for volume fraction of reinforcement in metal matrix composites -- Image analysis method |
| Sector / Industry | National Standard (Recommended) |
| Classification of Chinese Standard | H24 |
| Classification of International Standard | 77.040.99 |
| Word Count Estimation | 7,746 |
| Date of Issue | 2016-02-24 |
| Date of Implementation | 2017-01-01 |
| Quoted Standard | GB/T 13298-1991 |
| Regulation (derived from) | National Standard Announcement No |
| Issuing agency(ies) | General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China |
| Summary | This standard specifies the principles, equipment, samples, test methods, test results and test reports for the determination of particle or fiber volume content in metal matrix composites reinforced and unidirectional continuous fiber reinforced. This standard is applicable to the determination of the particle or fiber volume fraction in reinforced unidirectional continuous fiber reinforced metal matrix composites with particle diameters greater than 1 ��m or diameter greater than 1 ��m. |
GB/T 32496-2016: Test method for volume fraction of reinforcement in metal matrix composites -- Image analysis method
---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Test method for volume fraction of reinforcement in metal matrix composites.Image analysis method
ICS 77.040.99
H24
National Standards of People's Republic of China
Standard Test Method for Volume Content of Reinforced Metal Matrix Composites
Image analysis
2016-02-24 released
2017-01-01 Implementation
General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China
China National Standardization Management Committee released
Foreword
This standard is drafted in accordance with the rules given in GB/T 1.1-2009.
This standard is proposed by the National Engineering Materials Standardization Working Group (SAC/SWG3).
The drafting of this standard. Jiangsu Province Product Quality Supervision, Inspection and Research Institute, Shanghai Jiaotong University, Xuzhou City Product Quality Supervision and Inspection Center.
The main drafters of this standard. Zhu Yuhong, Zhu Xiaolin, Ye Huili, Wu Qiwei, Jia Xin, Ouyang Shengbao, Zhang Di, Wang Hao.
Standard Test Method for Volume Content of Reinforced Metal Matrix Composites
Image analysis
1 Scope
This standard specifies the method of determining the particle or fiber volume content of the particle reinforced and unidirectional continuous fiber reinforced metal matrix composites.
Test equipment, test specimens, test methods, test results and test reports.
This standard applies to enhance the particle size greater than 1μm particle enhancement or diameter greater than 1μm single-way continuous fiber reinforced metal complex
Determination of particle or fiber volume in the material.
2 normative reference documents
The following documents are indispensable for the application of this document. For dated references, only the dated edition applies to this article
Pieces. For undated references, the latest edition (including all modifications) applies to this document.
Methods for inspection of metallic microstructures GB/T 13298-1991
3 Principle of the method
3.1 principle of stereology
Stereology (Stereology), from the two-dimensional section or projection surface image feature parameters to restore (or deduce) three-dimensional image morphology
science. According to the principle of stereology, the two-dimensional parameters measured and calculated on the grinding surface of the metallographic sample can determine the volume of the phase in the three-dimensional space.
fraction.
The stereoscopic exchange formula (1).
VV = AA = LL (1)
Where.
VV - Percentage of particles or fiber volume to be measured,%;
AA - Percentage of particles or fiber area to be measured,%;
LL - Percentage of cut line or fiber cut line,%.
3.2 Principles of Image Analyzer
Through the image segmentation technology and data processing system, automatic measurement of the percentage of reinforced area AA, according to formula (1) VV = AA
Volume of volume to be measured.
3.3 Principle of the microscope
Using a scalable microscope eyepiece to directly measure the particles or fibers of the lens to be measured in the field of view of the microscope,
The ratio of the total length of the line segment cut by the measured reinforcement to the total length of the measured line segment is calculated according to VV = LL in equation (1)
Calculate the volume of the volume to be measured.
4 test equipment
4.1 image analyzer with quantitative measurement and analysis software (area, area percentage) and data processing system.
...
