GB/T 26664-2011 PDF English

Price & Delivery

US$259.00 · In stock · Download in 9 seconds
GB/T 26664-2011: Metallic line spring coupling
Delivery: 9 seconds. True-PDF full-copy in English & invoice will be downloaded + auto-delivered via email. See step-by-step procedure
Status: Valid
Std IDVersionUSDBuyDeliver [PDF] inTitle (Description)
GB/T 26664-2011English259 Add to Cart 3 days [Need to translate] Metallic line spring coupling

Click to Preview a similar PDF

Basic data

Standard ID GB/T 26664-2011 (GB/T26664-2011)
Description (Translated English) Metallic line spring coupling
Sector / Industry National Standard (Recommended)
Classification of Chinese Standard J19
Classification of International Standard 21.120.20
Word Count Estimation 11,146
Date of Issue 2011-06-16
Date of Implementation 2012-03-01
Quoted Standard GB/T 191; GB/T 699; GB/T 700; GB/T 1222; GB/T 3077; GB/T 4879; GB/T 5783; GB/T 6388; GB/T 7244; GB/T 11352; GB/T 13384; GB/T 18254
Regulation (derived from) Announcement of Newly Approved National Standards No. 9 of 2011
Issuing agency(ies) General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary This standard specifies the JXL metal wire spring coupling (hereinafter referred to as coupling) of the type, the basic parameters and the main dimensions, and gives the technical requirements, inspection rules, marking, packaging and storage. This standard applies to join two coaxial drive shafts, two-axis compensation relative offset and a buffer, damping performance. Operating temperature is -40��C ~ +250��C, transmission nominal torque 160N �� m ~ 160000N �� m.

GB/T 26664-2011: Metallic line spring coupling


---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Metallic line spring coupling ICS 21.120.20 J19 National Standards of People's Republic of China Metal wire spring coupling Issued on. 2011-06-16 2012-03-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Table of Contents

Preface Ⅰ 1 Scope 1 2 Normative references 1 3 model representation and mark 1 4 Types, basic parameters and the main dimensions 2 5 Technical requirements 5 6 Inspection rules 5 7 signs, packaging and storage 5

Foreword

This standard is in accordance with GB/T 1.1-2009 given rule drafting. This standard by the National Standardization Technical Committee of the machine shaft and accessories (SAC/TC109) and focal points. This standard was drafted. China Gas Turbine Research Institute, the machine Productivity Promotion Center. Drafters of this standard. Pan Yuan, Wan Shihua, Zhang Fu deposit, the new Ming Chui Deng Takami. Metal wire spring coupling

1 Scope

This standard specifies the JXL metal wire spring coupling (hereinafter referred to as the coupling) the type, basic parameters and the main dimensions, and gives Technical requirements, inspection rules, marking, packaging and storage. This standard applies to join two coaxial drive shafts, two-axis relative offset compensation and a buffer, damping performance. Working temperature -40 ℃ ~ 250 ℃, transfer nominal torque 160N · m ~ 160000N · m.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. GB/T 191 Packaging - Pictorial signs GB/T 699 high-quality carbon structural steel GB/T 700 carbon structural steel GB/T 1222 spring steel GB/T 3077 alloy steel GB/T 4879 rust-proof packaging GB/T 5783 full thread hex head bolts GB/T 6388 transport package shipping mark GB/T 7244 heavy spring washer GB/T 11352 Carbon steel castings for general engineering purposes GB/T 13384 mechanical and electrical products packaging General technical conditions GB/T 18254 high carbon chromium bearing steel

3 Model designation and marking

3.1 Coupling Model representation shall meet the following requirements. Metal elastic element code (group code) Linear spring Code Coupling Code Specification Code 3.2 tag example JXL1 metal wire spring coupling ...
