GB/T 1957-2006: Tolerances and general features for plain limit gauges Delivery: 9 seconds. True-PDF full-copy in English & invoice will be downloaded + auto-delivered via email. See step-by-step procedure Status: Valid GB/T 1957: Historical versions
Similar standardsGB/T 1957-2006: Tolerances and general features for plain limit gauges---This is an excerpt. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.), auto-downloaded/delivered in 9 seconds, can be purchased online: https://www.ChineseStandard.net/PDF.aspx/GBT1957-2006GB NATIONAL STANDARD OF THE PEOPLE’S REPUBLIC OF CHINA ICS 17.040.30 J 42 Replacing GB/T 1957-1981 Tolerances and general features for plain limit gauges Issued on: FEBRUARY 05, 2006 Implemented on: AUGUST 01, 2006 Issued by. General Administration of Quality Supervision, Inspection and Quarantine of the People’s Republic of China; Standardization Administration of the People’s Republic of China. Table of ContentsForeword ... 3 1 Scope ... 4 2 Normative references ... 4 3 Terms and definitions ... 4 4 Symbols ... 5 5 Gauge Codes and Rules for Use ... 5 6 Tolerance ... 6 7 Requirements ... 9 8 Acceptance and Inspection ... 9 9 Marking and Packaging ... 10 Annex A ... 12 Annex B ... 13 Annex C ... 14ForewordThis Standard replaces GB/T 1957-1981 Tolerances and general features for plain limit gauges. Compared with GB/T 1957-1981, the main changes of this Standard are as follows. - Change the format according to GB/T1.1-2000; - Change the standard’s name; - Add terms and definitions used in this Standard (section 3 of this edition); - Add description of the symbols used in this Standard (section 4 of this edition); - Change the hardness of gauge measuring planes (section 13 of the 1981 edition; section 7.4 of this edition); - Change the finish of gauge measuring planes into roughness (section 14 of 1981 edition; section 7.5 of this edition); - Add the acceptance and inspection requirements of gauges (section 8 of this edition); - Modifyr the recommended gauge types and the size application scope (Annex 1 to 1981 edition; Annex B to this edition); - Take workpiece determination to be the requirements of the annex (section 3, 4 and 5 of 1981 edition; Annex C of this edition). This Standard was proposed by China Machinery Industry Federation. This Standard shall be under the jurisdiction of National Technical Committee on Measuring Instruments of Standardization (SAC/TC 132). Drafting organization of this Standard. Harbin Measuring & Cutting Tool Group Co., Ltd. Main drafters of this Standard. Wu Ying, Gao Shanming, and Yao Xuli. Thr previous version replaced by this Standard is as follows. — GB/T 1957-1981. Tolerances and general features for plain limit gauges1 ScopeThis Standard specifies the terms and definitions, tolerance, requirements, inspection, marks and package of plain limit gauges. This Standard applies to plain limit gauges of which the basic dimensions of holes and shafts are up to 500mm, and tolerance grades are IT6 to IT16. The plain limit gauges (hereinafter referred to as gauges) defined in this Standard apply to inspection of the basic dimensions of holes and shafts specified in GB/T 1800.1-1997 ~ GB/T 1800.4-1999 Limits and Fits.2 Normative referencesThe articles contained in the following documents have become part of this document when they are quoted herein. For the dated documents so quoted, all subsequent modifications (including all corrigendum) or revisions made thereafter do not apply to this Standard. However, the parties who reach an agreement according to this Standard are encouraged to study whether the latest versions of these documents may be used. For the undated documents so quoted, the latest versions (including all modification sheets) apply to this document. GB/T 1800.1-1997 Limits and fits – Bases - Part 1. Terminology (neq ISO 286-1.1988) GB/T 1800.2-1998 Limits and fits – Bases - Part 2. Basic rules of tolerances, deviations and fits (eqv ISO 286-1.1988) GB/T 1800.3-1998 Limits and fits – Bases - Part 3. Numerical values tables of standard toleranes and fundamental deviations (eqv ISO 286-1.1988) GB/T 1800. 4-1999 Limits and fits - Tables of standard tolerance grades and limit deviations for holes and shafts (eqv ISO 286-2.1988)3 Terms and definitionsThe following terms AND definitions determined in GB/T 1800.1-1997 to GB/T 1800.4-1999 apply to this Standard. 8.1 Acceptance 8.1.1 The specified dimension values in this Standard are subject to standard measuring conditions, that is, temperature is 20°C and the measuring force is zero. 8.1.2 The inspection of ring gauges shall be subject to calibration. If there are disputes, C.3 in Annex C will prevail. 8.2 Inspection 8.2.1 All the parameters of a gauge shall be subject to direct inspection; the major inspection parameters and inspection instruments are tabulated in Table 5. Table 5 Major inspection parameters Inspection instruments Surface roughness Profilers, surface roughness comparison specimens Roundness of Holomorph plug gauges and ring gauges Roundness measuring instruments Generatrix straightness Profilers, Grade-0 knife straight edges Flatness of caliper gauge measuring planes Knife straight edges, optical flats Parallelism of caliper gauge measuring planes Optimeters, length measuring instruments Hardness Vickers hardness testers (or Rockwell hardness testers) 8.3 Decision on the qualification of a workpiece shall be consistent with that in Annex C.9 Marking and Packaging9.1 The end face of a plug gauge probe and the non-working surface of other gauges shall be marked with. a) The manufacturer name and registered trademark; b) Basic dimension and tolerance codes of the inspected workpiece; c) Codes of use of a gauge; d) Year of manufacture. Note 1. Plug gauges with working dimensions less than 14mm are allowed to mark the requirements from a) to d) on the handle or nameplate. Note 2. Single-head double-limit gauges should better not be marked with the code of use. 9.2 The packing box shall be marked with. a) The manufacturer name and registered trademark; b) The name of the product; c) Basic dimension and tolerance codes of the inspected workpiece. 9.3 Gauges shall be subject to anti-corrosive treatment before being properly packaged. 9.4 Gauges that are verified to be satisfactory to this Standard shall be furnished with a certificate, on which the number of this Standard and the date of manufacture shall be marked.Annex A(Informative) Check Gauges A.1 The dimensional tolerance of a check gauge is 1/2 of that of a working gauge for shafts; the dimensional tolerance of a check gauge contains shape errors. A.2 The surface appearance of check gauges, the degree of connection of probes and handles, the making material, the measuring plane hardness and treatment shall be in conformity with 7.1~7.4, 7.6. 3 The surface roughness of the measuring plane of a check plug gauge shall not be more than what is specified in Table A.1. Table A. 1 Check plug gauges Basic dimensions of check gauges /mm Less than or equal to 120 More than 120, less than or equal to 315 More than 315, less than or equal to 500 Surface roughness of measuring planes of check gauges /pm Check plug gauges of IT6~IT9 working ring gauges for shafts 0.05 0.10 0. 20 Check plug gauges of IT10~IT12 working ring gauges for shafts 0.10 0.20 0.40 Check plug gauges of IT13~IT6 working ring gauges for shafts 0.20 0.40Annex B(Informative) Recommended Gauge Types and Size Application Range B.1 The recommended gauge types and size application range are shown in Table B.1. Table B.1 Purpose Recommended order Gauge’s working dimensions /mm ~18 More than 18~100 More than 100~315 More than 315~500 Types of go gauge for workpiece holes 1 Holomorph plug gauge Non-holomorph plug gauge Ball-end bar gauge 2 — Non-holomorph plug gauge or sheet plug gauge Sheet plug gauge — Types of no-go gauge for workpiece holes 1 Holomorph plug gauge Holomorph plug gauge or sheet plug gauge Ball-end bar gauge 2 — Non-holomorph plug gauge — Types of go gauge for workpiece shafts 1 Ring gauge Caliper gauge 2 Caliper gauge — Types of no-go gauge for workpiece shafts 1 Caliper gauge 2 Ring gauge ......Source: Above contents are excerpted from the full-copy PDF -- translated/reviewed by: www.ChineseStandard.net / Wayne Zheng et al. Tips & Frequently Asked Questions:Question 1: How long will the true-PDF of English version of GB/T 1957-2006 be delivered?Answer: The full copy PDF of English version of GB/T 1957-2006 can be downloaded in 9 seconds, and it will also be emailed to you in 9 seconds (double mechanisms to ensure the delivery reliably), with PDF-invoice.Question 2: Can I share the purchased PDF of GB/T 1957-2006_English with my colleagues?Answer: Yes. The purchased PDF of GB/T 1957-2006_English will be deemed to be sold to your employer/organization who actually paid for it, including your colleagues and your employer's intranet.Question 3: Does the price include tax/VAT?Answer: Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries) -- See Avoidance of Double Taxation Agreements (DTAs): List of DTAs signed between Singapore and 100+ countriesQuestion 4: Do you accept my currency other than USD?Answer: Yes. www.ChineseStandard.us -- GB/T 1957-2006 -- Click this link and select your country/currency to pay, the exact amount in your currency will be printed on the invoice. Full PDF will also be downloaded/emailed in 9 seconds.Question 5: Should I purchase the latest version GB/T 1957-2006?Answer: Yes. Unless special scenarios such as technical constraints or academic study, you should always prioritize to purchase the latest version GB/T 1957-2006 even if the enforcement date is in future. Complying with the latest version means that, by default, it also complies with all the earlier versions, technically.How to buy and download a true PDF of English version of GB/T 1957-2006?A step-by-step guide to download PDF of GB/T 1957-2006_EnglishStep 1: Visit website https://www.ChineseStandard.net (Pay in USD), or https://www.ChineseStandard.us (Pay in any currencies such as Euro, KRW, JPY, AUD).Step 2: Search keyword "GB/T 1957-2006". Step 3: Click "Add to Cart". If multiple PDFs are required, repeat steps 2 and 3 to add up to 12 PDFs to cart. Step 4: Select payment option (Via payment agents Stripe or PayPal). Step 5: Customize Tax Invoice -- Fill up your email etc. Step 6: Click "Checkout". Step 7: Make payment by credit card, PayPal, Google Pay etc. After the payment is completed and in 9 seconds, you will receive 2 emails attached with the purchased PDFs and PDF-invoice, respectively. Step 8: Optional -- Go to download PDF. Step 9: Optional -- Click Open/Download PDF to download PDFs and invoice. See screenshots for above steps: Steps 1~3 Steps 4~6 Step 7 Step 8 Step 9 |
