JGJ57-2016 English PDFUS$1449.00 · In stock
Delivery: <= 8 days. True-PDF full-copy in English will be manually translated and delivered via email. JGJ57-2016: Code for design of theater building Status: Valid JGJ57: Historical versions
Basic dataStandard ID: JGJ 57-2016 (JGJ57-2016)Description (Translated English): Code for design of theater building Sector / Industry: Building & Construction Industry Standard Classification of Chinese Standard: P33 Classification of International Standard: 91.040.10 Word Count Estimation: 63,625 Date of Issue: 2016-09-05 Date of Implementation: 2017-03-01 Older Standard (superseded by this standard): JGJ 57-2000 Regulation (derived from): Ministry of Housing and Urban - Rural Development Notice No.1304 of 2016 Issuing agency(ies): Ministry of Housing and Urban-Rural Development of the People's Republic of China JGJ57-2016: Code for design of theater building---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.UDC People's Republic of China Industry Standard Record number J67-2016 Code for architectural design of the theater Code for design of theater building 2016-09-05 release 2017-03-01 implementation People's Republic of China Ministry of Housing and Urban - Rural Development People's Republic of China Industry Standard Code for architectural design of the theater Code for design of theater building Approval Department. Ministry of Housing and Urban and Rural Development of the People's Republic of China Date of implementation. March 1, 2007 Ministry of Housing and Urban-Rural Development of the People's Republic of China 1 General1.0.1 To ensure that theater architecture design to meet the use of functional, safety, health, energy saving, Environmental protection, economic and stage technology and other aspects of the basic requirements, the development of this specification. 1.0.2 This specification applies to theater construction design for new construction, expansion and construction. 1.0.3 Theater building design should follow the principles of practical and sustainable development and should According to the cultural needs of the region, functional positioning, service object, management and other reasons To determine its type, size and grade. 1.0.4 According to the nature of the use and performance conditions, the theater building can be used for musical, then Drama, opera and other three kinds of drama performances. When the theater is multi-purpose, its technical requirements should be Its main use nature to determine, other uses should be appropriate to take into account. 1.0.5 The size of the theater building should be divided according to the number of seats in the audience, and should be consistent Table 1.0.5. Table 1.0.5 Theater building scale division Size Audience Seats (Block) 1.0.6 The architectural level of the theater According to the technical requirements of the exhibition can be divided into special, B and other three grades. The technical requirements of the special theater should not be lower than the theater. 1.0.7 The theater building should be stage craft and acoustic design, and the building design should be Stage technology and acoustic design are synchronized and coordinated. 1.0.8 Theater buildings should be accessible design and should comply with current national standards "Barrier design specifications" GB 50763 of the relevant provisions. 1.0.9 When the theater audience hall and film, the projection of optical design and screening room should be consistent The current industry standard "cinema building design" JG J 58 provisions. 1.0.10 Theater building design should comply with the norms, should still be consistent with the existing state Off standard.2 terms2.0.1 theater theater It is equipped with auditorium, stage, technical room and actor, visitor room and so on. 2.0.2 Auditorium auditorium The audience watches the space of the show. 2.0.3 pool stalls First floor auditorium. 2.0.4 F. balcony The first floor of the auditorium above the floor of the audience. 2.0.5 box box (in the auditorium) The auditorium side wall or the back wall is divided into small auditoriums. 2.0 d at sight sight point point View of the viewer 's line of sight. 2.0.7 sight sightline The connection between the viewer's eyes and the design point of view. 2.0.8 line of sight ultra-high value exceeded value of vertical sightl Ineffective Rear view of the audience and the front audience of the vertical distance of the eyes, referred to as C value. 2.0.9 stage stage Part of the theater performance. 2.0.10 frame stage proscenium stage There is a separate stage between the auditorium and the stage. 2.0.11 tel stage Extended to the audience hall, the auditorium surrounded by three sides of the stage. 2.0.12 island stage arena stage In the auditorium, the auditorium is surrounded by the stage. 2.0.13 main stage main stage The main performance space. For the frame stage, it refers to the main line within the tandem line To perform space. 2.0.14 side stage bay area Located on both sides of the main stage, for the exchange of scenery, the actor waiting, temporary storage props, The auxiliary space of the scene. 2.0.15 after the stage back stage Behind the main stage, can increase the depth of the performance area of the area. 2.0.16 backstage backstart A special area for the performers to perform. 2.0.17 Taiwan proscenium opening The stage faces the opening of the Auditorium. 2.0188 lips apron stage Outside the tai line extends to the auditorium table. 2.0.19 earset apron side The edge of the lips to the mouth of Taiwan, l between the two sides of the stage between the stage. 2.0.20 music pool orchestra pit Usually set in front of the lips below, f co-accompaniment band used space. 2.0.21 Taiwan understage Set up in the space below the stage, the equipment is running, installation and inspection Repair the basic space. 2.0.22 tower tower The main stage above the floor to the roof structure of the lower space, is the stage performance and stage machine Equipment, equipment, installation and maintenance of the basic space. 2.0.23 playout stage right Face the audience, the stage on the right side of the actors to play out of the population. 2.0.24 Lower field stage left Face the audience, the stage on the left side of the actors out of the population. 2.0.25 tai line line curtain line Tank structure inside the side of the line in the stage on the projection line, is the stage mechanical positioning The benchmark. 2.0.26 grid top grid; gridiron The upper part of the stage for the installation, maintenance of the suspension of the working layer. 2.0.27 fly bridge Along the side walls of the main stage, the rear wall of the wall is set at a certain height of the work corridor. 2.0.28 big screen proscenium curtain Separate the stage and the auditorium of the soft screen. 2.0.29 Sky curtain cyclorama Hanging in the stage prospects, the performance of the background of the curtain. 2.0.30 stage machinery stage machinery For the stage performance activities of the machinery and equipment collectively. 2.0.31 fire screen fire curtain Set in the stage at the mouth, in the case of fire can quickly close the mouth, isolated dance Taiwan and the audience hall or other areas outside the main stage, to prevent the spread of fire dedicated equipment. 2.0.32 fake counter false proscenium Set in the stage after the mouth, by the film and two side panels, can be appropriate to change the stage Mouth size, and can be used as the main facilities for hanging mouth lamps. 2.0.33 lighting bridge Parallel to the boom, can be lifted, used for installation, maintenance of the bridge Metal frame. 2.0.34 bridge bridge terminal bridge A platform that extends from a bridge over a light bridge or countertop Hanging board. 2.0.35 platform stage wago day In the main stage, side stage, behind the stage, the level of movement of the mechanical stage. 2.0.36 lift elevater stage The stage can lift the mechanical stage. 2.0.37 turntable revolving stage The stage can be rotated horizontally on the mechanical stage. 2.0.38 lift music Also orchestra lift Countertops can lift the music pool. 2.0.39 boom batten Set over the stage, with a single rod or frame hanging curtains, scenery or lighting, etc. rise Down the device. 2.0.40 single point crane point hoist Set up on a stage or performance venue to lift objects at a single hanging point equipment. 2.0.41 sound forehead sound gallery In the mouth outside the front of the top of the installation of the speaker at the top of the work bridge. 2.0.42 fore stage lighting gallery Set at the top of the auditorium, for the installation of lamps to the front of the stage projection of light workers For the bridge. 2.0.43 forehand side lighting Set on both sides of the auditorium, for the installation of lamps to the stage lighting room. 2.0.44 fore stage back lighting Set in the back of the auditorium, used to project the stage to chase the room. 2.0.45 Taiwan mouth light frame On both sides of the main stage, install the vertical steel frame of the lamp. 2.0.46 light hoop lighting (cable) basket Set on both sides of the stage over, for the installation of lamps, you can lift, horizontal movement Of the cage hanger. 2.0.47 flow lights Arranged on the stage table to move the light on the lighthouse. 2.0.48 Stage acoustic reflector orchestral shell An acoustic retroreflector mounted on the main stage for improving the natural sound field conditions. 2.0.49 power amplifier equipment room Installation of PA power amplifier and other equipment room. 2.0. Coordination light cabinet room dimmer cubical room Place the stage lighting cabinet and other lighting control cabinet equipment room. 2.0.51 stage audio equipment room audio room at stage height lev El Set on the stage, for the stage sound cabinet and storage of mobile speakers and so on Of the equipment room. 2.052 stage lighting equipment room lighting room at stage height Level Set up on the stage, for the installation of stage lighting cabinets and other equipment room. 2.0.53 stage stage machinery electrical cabinet room under stage equipment electr Cal cabinet room Placement station F stage machinery electrical cabinet equipment room. 2.0.54 stage stage mechanical electrical cabinet room upper stage equipment electr Cal cabinet room Place the stage equipment on the stage mechanical electrical cabinet. 2.0.55 lighting control room lighting control room Control the operating room of the stage lighting system. 2.0.56 sound control room sound control room Control the operation of the stage sound system. 2.0.57 stage machinery control room stage equipment control room Control the operating room of the stage mechanical system. 2.0.58 stage supervisory command system stage manager control system With a stage supervision, command performance signals and internal communications and other functions of the system. 2.0.59 stage monitoring system watch monitoring (display) syste Watch the stage performance of the video surveillance system.3 base and total plane3.1 base 3.1.1 The choice of theater construction base should meet the requirements of local urban planning and distribution Should be reasonable. 3.1.2 Theater building base should meet the following requirements. 1 It is desirable to select a convenient area and should be away from industrial sources and sources of noise. 2 base should be at least one facing the city road, or directly to the city road Of the open space; the accessible width of the urban road should not be less than the theater safety exit width The sum of degrees. 3 base along the city road length should be determined by the size of the building or evacuation, And should not be less than 1/6 of the base circumference. 4 base should have at least two different directions to the exit of the city road. 5 The main population of the base should not be directly connected with the fast road, nor should it be straight Facing the intersection of the main roads of the city. 3.1.3 The main space of the theater's main population should meet the following requirements. 1 theater building from the red line of the distance should be consistent with the local planning requirements, and Should be not less than o.2om2 I set aside the air distribution space. 2 greening and parking layout should not affect the use of scattered air, and should not be set Set the obstacle. 3.1.4 When the theater building base is approaching two roads or at the intersection, The road to be adjourned shall comply with the provisions of Article 3.1.2 of this Code In line with the provisions of Article 3.1.3 of this Code, but also should meet the vehicle line of sight requirements, And the location of the main population and the evacuation port should meet the requirements of the local traffic planning. 3.2 total plane 3.2.1 The total layout of the theater should meet the following requirements. 1 total graphic design should function clear partition, traffic flow line is reasonable, to avoid flow And traffic flow, cargo flow cross, and should be conducive to fire, parking and flow distribution. 2 scenery transport vehicles should be able to directly reach the scene to carry the population. 3 Leave room for future alterations and developments. 4 should consider the layout of security facilities. 3.2.2 new, expansion of the theater base should be set up parking lot (library), and parking lot (Library) of the population should be easily connected with the road, the number of parking spaces should meet the local regulations Plan the request. 3.2.3 The total plane design of the theater should meet the traffic requirements of fire engines and freight cars, Its net width should not be less than 4.OOm, through the building when the net height should not be less than 4.OOm. 3.2.4 Environmental design and greening should meet local planning requirements. 3.2.5 theater building base equipment space should not be on the audience hall, stage and its week Ambient noise, vibration interference. 3.2.6 For the installation of the building within the building, should be set out to the outdoor out alone Population, should be set up staff space, and should set the corresponding logo.4 front hall and lounge4.0.1 The lobby and lounge should meet the following requirements. 1 traffic streamline and service district should be clear, and should set the ticket office, merchandise zero Sales department, clothing storage, waiting for the waiting area. 2 minimum area of use indicators should be determined according to the architectural level of the theater, and should be Comply with the provisions of Table 4.0.1. Table 4.0.1 Minimum use area of the lobby and lounge (m2/seat) Level first class Wait for a b Stare at a Lounge 0.30 The lobby is merged with the lounge 0.50 0.20 0.20 0.30 3 When the theater has a hierarchical audience hall, the floor area of the lounge should be based on points The number of seats in the audience is allocated. 4 cold and cold areas of the theater, the front hall should be set bucket. S should be reserved for the installation of security facilities. 4.0.2 theater clothing storage, the area index should not be less than 0.04 Kuang / And cold and cold areas of the area should be appropriate to increase the index. 4.0.3 Theater Misunderstanding Waiting area should be broadcast live broadcast video equipment. 4.0.4 The ticket office of the theater should meet the following requirements. 1 ticket window (Taiwan) the number of each should be set for each one, two adjacent to the sale The center distance of the window (platform) should not be less than 0.90m. 2 for the outdoor ticket window, the upper part of the window should be set awning. 3 ticket office should be installed eye-catching display facilities, can show the program, performance Time, price list and so on. 4.0.S The theater should be set for the audience to use the toilet, and the toilet should be set in front of the room. WC Do not open the door to the audience hall. The proportion of male and female audience should be calculated by 1. 1, female toilet and male Toilet seat (with urine station) ratio should not be less than 2. 1, sanitary appliances should meet the next Column provides. 1 male toilet should be set for every 150 a toilet, every 60 set a urine Or 0.60m long toilet, every 150 set a wash basin. 2 female toilet should be set for every 20 → a toilet, every 100 set a wash Hand basin. 3 men and women toilets should be equipped with barrier-free toilet or set the barrier barrier toilet. 4 When the theater has a hierarchical audience hall, the number of toilet sanitary ware at all levels should be appropriate According to the number of seats in the audience to determine the number of seats.5 Auditorium5.1 line of sight design 5.1.1 The sight of the Auditorium is designed so that viewers can see all of the audiovisual performance areas. When conditions are limited, viewers who are located in poor visual quality should be able to see the performance 80% of the district. 5.1.2 The viewing point of the Auditorium shall meet the following requirements. 1 For the frame-style stage theater, the point of view should be selected at the center of the stage table line. 2 for large lips, stretched out the stage theater, point of view should be the actual needs, The appropriate view of the design point of view. 3 For the island stage, the viewpoint should be selected on the edge of the performance area. 4 When subject to conditions, the view may be properly moved, but not more than the stage 0.30m; can also be moved to the rear of the station line or the edge of the performance area, but not large In l.OOm. 5.1.3 The view of the Auditorium is designed to meet the following requirements. 1 line of sight high value should not be less than 0.12m. 2 when the row to calculate the line of sight ultra-high value, the seats should be arranged in the wrong arrangement, and should To ensure that the line of sight to see the point of view. 3 for children's theater, stretched out, island stage theater, high-value line of sight should be high Appropriate increase. 5.1.4 The height of the stage from the first row of seats shall meet the following requirements. 1 for the frame-style stage, should not be less than 0.60m, and should not be large In l.lOm. 2 for the extended stage, it should be 0.30m ~ 0.60m; for with a mirror The stage of the first stage seats can be flush with the main stage. 3 for island stage countertops, should not be higher than 0.30m, with the first row of seats The ground is flush. 5.1.5 The maximum distance between the auditorium and the viewpoint should not be greater than that of the dance theater 33m; drama and opera theater should not be greater than 28m; stretched out, island stage theater not Should be greater than 20mo 5.1.6 The maximum angle of view for the audience, the frame stage rear row should not be large At 30. , Close to the stage of the box or side of the building should not be greater than 35 °; out of the type, island Stage theater viewers viewing angle should not be greater than 30. The 5.2 seats 5.2.1 Auditorium seats should be compact, should meet the line of sight, row distance, armrest distance, Evacuation and other requirements, the area should meet the following requirements. 1 A theater should not be less than o.som2 seat. 2 B and other theaters should not be less than o.70m2 I seat. 5.2.2 The theater should be provided with a fixed seat with a backrest. When the box seat does not exceed 12 , You can set the active seat. 5.2.3 Auditorium seats should meet the requirements of acoustic design. 5.2.4 seat armrest distance, the hard chair should not be less than 0.50m, soft chair should not be small At 0.55m. 5.2.5 Seat row spacing should meet the following requirements. 1 short row method. the hard chair should not be less than 0.80m, soft chair should not be less than 0.90m, Stepped ground row spacing should be appropriately increased, the back to the back of a row of the most prominent part of the level The distance should not be less than 0.30m. 2 long row method. the hard chair should not be less than 1.OOm; soft chair should not be less than 1.lOm, Stepped ground row spacing should be appropriately increased, back to the ......Tips & Frequently Asked Questions:Question 1: How long will the true-PDF of JGJ57-2016_English be delivered?Answer: Upon your order, we will start to translate JGJ57-2016_English as soon as possible, and keep you informed of the progress. The lead time is typically 5 ~ 8 working days. The lengthier the document the longer the lead time.Question 2: Can I share the purchased PDF of JGJ57-2016_English with my colleagues?Answer: Yes. The purchased PDF of JGJ57-2016_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.Question 3: Does the price include tax/VAT?Answer: Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries) -- See Avoidance of Double Taxation Agreements (DTAs): List of DTAs signed between Singapore and 100+ countriesQuestion 4: Do you accept my currency other than USD?Answer: Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay.Question 5: Should I purchase the latest version JGJ57-2016?Answer: Yes. Unless special scenarios such as technical constraints or academic study, you should always prioritize to purchase the latest version JGJ57-2016 even if the enforcement date is in future. Complying with the latest version means that, by default, it also complies with all the earlier versions, technically. |
