GBZ44946-2024 English PDFUS$359.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email. GBZ44946-2024: Hydraulic fluid power - Filter element test methods - Service life evaluation Status: Valid
Basic dataStandard ID: GB/Z 44946-2024 (GB/Z44946-2024)Description (Translated English): Hydraulic fluid power - Filter element test methods - Service life evaluation Sector / Industry: National Standard Classification of Chinese Standard: J20 Classification of International Standard: 23.100.60 Word Count Estimation: 18,114 Date of Issue: 2024-11-28 Date of Implementation: 2025-06-01 Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration GBZ44946-2024: Hydraulic fluid power - Filter element test methods - Service life evaluation---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.GB /Z 44946-2024 Hydraulic fluid power - Filter element test methods - Service life evaluation Hydraulic transmission filter element test method Actual life span assessment Hydraulic fluid power-Filter element test methods- Service life evaluation ICS 23.100.60 CCS J20 Guiding technical documents of the People's Republic of China on national standardization Released on 2024-11-28 2025-06-01 Implementation State Administration for Market Regulation The National Standardization Administration issued Table of ContentsPreface ... Ⅲ Introduction ... Ⅳ 1 Scope ... 1 2 Normative references ... 1 3 Terms and Definitions ... 1 4 General Principles ... 1 5 Correlation between actual life and test life ... 2 6 Establishment and evaluation of mathematical models ... 3 Appendix A (Normative) Collection of filter element operating parameters ... 6 Appendix B (Informative) Actual Life Assessment Case ... 8 References ... 13ForewordThis document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for standardization work Part 1.Structure and drafting rules for standardization documents" Drafting is required. Please note that some of the contents of this document may involve patents. The issuing organization of this document does not assume the responsibility for identifying patents. This document was proposed by the China Machinery Industry Federation. This document is under the jurisdiction of the National Hydraulic and Pneumatic Standardization Technical Committee (SAC/TC 3). This document was drafted by. Aviation Industry (Xinxiang) Measurement Technology Co., Ltd., Liming Hydraulics Co., Ltd., Zhejiang Zhenhang Industrial Group Co., Ltd. Co., Ltd., Beijing Europ Filtration Technology Development Co., Ltd., Jiujiang Qisuo Precision Electromechanical Technology Co., Ltd., Xinxiang Pingfei Hydraulic Co., Ltd., Beijing University of Chemical Technology, Xinxiang Wanhe Filtration Technology Co., Ltd. The main drafters of this document are. Feng Lan, Zheng Yuan, Liu Guojun, Du Lipeng, Xiong Liyuan, Geng Cong, Yang Miao, Liu Yong, Lü Jizhong, Li Fangjun, Wang Xinxiang and Ye Ping.IntroductionHydraulic filter is one of the components with the highest maintenance frequency in the fluid transmission system. There are two main maintenance methods. one is to clean the hydraulic filter. The first step is to replace the filter element (hereinafter referred to as the filter element). Whether cleaning or replacing the filter element, the same problem is faced, that is, how to determine the best time to clean or replace the filter element. The actual life of the filter element or the cleaning interval of the filter element can be used to maintain the filter in a timely, accurate and economical manner, thereby ensuring that the filter protects The hydraulic system can work safely and reliably. Scientific evaluation of the actual life of the filter element can provide guidance for users to use and maintain the filter rationally, reliably and economically. It is particularly important to carry out this work to ensure the reliability, safety and economy of the equipment's hydraulic system. The life of the filter element is determined by the time when the pressure difference rises to the recommended replacement pressure difference. During the use of the filter, under normal circumstances, The pressure difference gradually increases with the increase of working time. The test conditions are designed in the laboratory with reference to the actual working conditions. By adding test dust, the pressure difference can be The test time corresponding to different pressure differences is measured. Based on the principle of equal pressure difference, the corresponding relationship between the actual life of the filter element and the test life can be established. This document provides a theoretical basis for the assessment of the actual life of hydraulic filter elements, and provides guiding procedures and methods for carrying out the assessment work. Hydraulic transmission filter element test method Actual life span assessment1 ScopeThis document describes the theoretical correspondence between the actual life of the filter element and the test life. This document applies to. Establish a mathematical model of the actual life and test life of the filter element; The system oil viscosity, flow rate and solid particle contamination are basically stable; - Obtain the working parameters of the filter element in use and evaluate its actual lifespan in combination with laboratory data. -2 Normative referencesThe contents of the following documents constitute the essential clauses of this document through normative references in this document. For referenced documents without a date, only the version corresponding to that date applies to this document; for referenced documents without a date, the latest version (including all amendments) applies. in this document. GB/T 14041.1 Hydraulic filter element Part 1.Verification of structural integrity and determination of initial bubbling point GB/T 17446 Fluid power systems and components vocabulary GB/T 17486 Evaluation of pressure drop and flow characteristics of hydraulic filters GB/T 18853 Hydraulic transmission filter - Multiple pass method for evaluating filter element filtration performance GB/T 28957.1 Test dust for filter evaluation of road vehicles Part 1.Silicon oxide test dust3 Terms and definitionsThe terms and definitions defined in GB/T 17446 and the following apply to this document. 3.1 Test life The filter element is subjected to multiple tests according to GB/T 18853.If the structural integrity of the filter element meets the requirements, the filter element is tested from the beginning to the pressure. The time it takes for the pressure difference to rise to the limit pressure difference. 3.2 Actual service life The cumulative pressure difference from the beginning of use to the pressure difference rising to the limit pressure difference under specific use conditions and when the structural integrity of the filter element meets the requirements. Meter usage time. Note. Specific use conditions refer to the use conditions determined through consultation with the user based on the common working conditions of the filter element.4 GeneralThere is a functional relationship between the actual life of the filter element and the test life, which can be verified through experiments. ......Tips & Frequently Asked Questions:Question 1: How long will the true-PDF of GBZ44946-2024_English be delivered?Answer: Upon your order, we will start to translate GBZ44946-2024_English as soon as possible, and keep you informed of the progress. The lead time is typically 2 ~ 4 working days. The lengthier the document the longer the lead time.Question 2: Can I share the purchased PDF of GBZ44946-2024_English with my colleagues?Answer: Yes. The purchased PDF of GBZ44946-2024_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.Question 3: Does the price include tax/VAT?Answer: Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries) -- See Avoidance of Double Taxation Agreements (DTAs): List of DTAs signed between Singapore and 100+ countriesQuestion 4: Do you accept my currency other than USD?Answer: Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay. |
