GBZ32009-2015 English PDF

Q: How long will the true-PDF of English version of GBZ32009-2015 be delivered?

Upon your order, we will start to translate GBZ32009-2015_English as soon as possible, and keep you informed of the progress. The lead time is typically 1 ~ 3 working days. The lengthier the document the longer the lead time.

Q: Can I share the purchased PDF of GBZ32009-2015_English with my colleagues?

Yes. The purchased PDF of GBZ32009-2015_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.

Q: Does the price include tax/VAT?

Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries). Avoidance of Double Taxation Agreements (DTAs) between Singapore and 100+ Countries: https://www.iras.gov.sg/taxes/international-tax

Q: Do you accept my currency other than USD?

Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay.

US$189.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GBZ32009-2015: New textile materials -- Datasheet of mechanical properties
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/Z 32009-2015	189	Add to Cart	3 days	New textile materials -- Datasheet of mechanical properties	Valid

Similar standards

GB/T 32612 GB/T 32598 GB/T 32008 GB/T 32011

Basic data

Standard ID: GB/Z 32009-2015 (GB/Z32009-2015)
Description (Translated English): New textile materials -- Datasheet of mechanical properties
Sector / Industry: National Standard
Classification of Chinese Standard: W04
Classification of International Standard: 59.080.01
Word Count Estimation: 9,999
Date of Issue: 2015-09-11
Date of Implementation: 2016-04-01
Quoted Standard: GB/T 3291.1; GB/T 6529; GB/T 14335; GB/T 14337; GB/T 19975-2005
Regulation (derived from): National Standard Announcement 2015 No.25
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China
Summary: This Standard specifies the dry breaking strength of certain textile fibers, wet breaking strength, relative wet strength, elongation at break dry, wet elongation at break and initial modulus of the mechanical properties of the underlying data. This Standard applies to the ultra-high molecular weight polyethylene fiber, aramid 1414, 1313 aramid, polyphenylene sulfide fibers, polyethylene phthalate imide fiber, polyethylene terephthalate fiber, polybutylene terephthalate fiber, polylactic acid fibers, chitosan fibers and lyocell.

GBZ32009-2015: New textile materials -- Datasheet of mechanical properties

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
New textile materials.Datasheet of mechanical properties ICS 59.080.01 W04 People's Republic of China national standardization of technical guidance documents Textile mechanical properties of new materials datasheet 2015-09-11 released 2016-04-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China China National Standardization Administration released

Foreword

This instructional document has been drafted in accordance with the rules given in GB/T 1.1-2009. This Guidance Document is proposed by China National Textile and Apparel Council. The guidance of technical documents by the National Textile Standardization Technical Committee (SAC/TC209) centralized. The drafting of the guidance of technical documents. Textile Industry Standardization Institute, Textile Industry Science and Technology Development Center, Yantai Taihe new material Materials Co., Ltd., Ningbo Institute of Materials Technology and Engineering, Chinese Academy of Sciences, Tianjin Sheng Biological Engineering Co., Ltd., Changshu Jinquan Weaving limited liability company, Hangzhou Cheung Shing high-strength fiber materials Co., Ltd., China Chemical Fiber Industry Association. The main drafters of this guidance document are Han Yuru, Xu Lu, Fei Fei, Li Deli, Wang Guojian, Ma Qianli, Li Dehong, Zhou Xinmin, Fan Haibin, Bao Jianfeng.

Introduction

At present, aramid, polyphenylene sulfide fibers, ultra-high molecular weight polyethylene fibers, new polyester fibers, chitosan fibers, polylactic acid fiber and other high Fibers and new textile fibers developed rapidly, but mostly in the industrialization process, the basic data of a serious shortage of some books, information mentioned Part of the scattered data there is a big difference, and did not indicate the test method, is not comparable, can not meet the product development and application design Department of the material itself based on the performance data needs. The data of this instructional technical document originated from the scientific research special item "Research on basic performance data of textile new material" Fruit, is collected on the basis of the measured value of the sample is given, there are some limitations. Unlike the existing product standards, this guidance document is not a specification of the performance of the final product and is not intended as a Determine whether the product is qualified basis. This guideline is for reference only. The suggestions and opinions on this technical document are directed to the standardization administration under the State Council Department reflected. Textile mechanical properties of new materials datasheet

1 Scope

This guideline gives some of the textile fiber dry fracture strength, wet strength, wet strength, wet breaking strength The basic data of the mechanical properties of elongation, wet elongation at break and initial modulus. This guideline is applicable to UHMWPE fibers, aramid 1414, aramid 1313, polyphenylene sulfide fibers, polyimides Fibers, polytrimethylene terephthalate fibers, polybutylene terephthalate fibers, polylactic acid fibers, chitosan fibers and Lyocell fibers.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version applies to this article Pieces. For undated references, the latest edition (including all amendments) applies to this document. Textile and textile materials - Performance and test terms - Part 1. Fibers and yarns GB/T 6529 Textiles conditioning and testing standard atmosphere Chemical fiber staple fiber linear density test method Test method for tensile properties of GB/T 14337 chemical fiber staple fibers Test method for tensile properties of high strength filament yarn

3 Terms and definitions

GB/T 3291.1 defined and the following terms and definitions apply to this document. 3.1 Drying breaking strength breakingtenacityinstandardatmosphere The ratio of the measured breaking strength to the linear density of the material after conditioning in a standard atmosphere. Note. Generally known as the breaking strength. 3.2 Dry elongation at breakage After conditioning in a standard atmosphere, the ratio of elongation at break measured to the initial length of the material is expressed as a percentage. Note. Generally known as the elongation at break. 3.3 Initial modulus initialmodulus The slope of the material's stress-strain curve initially approaching the straight line. [GB/T 3291.3-1997, definition 2.90] 3.4 Wet breaking strength of wet breaking Under specified conditions, the ratio of the breaking strength to the linear density of the material as measured after soaking. 3.5 Wet breaking elongation at wetbreakingelongation Under specified conditions, the ratio of the elongation at break measured after soaking of the material to its initial length, expressed as a percentage. ......
