Path: Home > GB/T > Page493 > GB/T 7757-2009 Price & DeliveryUS$254.00 · In stock · Download in 9 secondsGB/T 7757-2009: Rubber, vulcanized or thermoplastic -- Determination of compression stress-strain properties Delivery: 9 seconds. True-PDF full-copy in English & invoice will be downloaded + auto-delivered via email. See step-by-step procedureStatus: Valid GB/T 7757: Historical versions
| Std ID | Version | USD | Buy | Deliver [PDF] in | Title (Description) |
| GB/T 7757-2009 | English | 254 |
Add to Cart
|
3 days [Need to translate]
|
Rubber, vulcanized or thermoplastic -- Determination of compression stress-strain properties
|
| GB/T 7757-1993 | English | 319 |
Add to Cart
|
3 days [Need to translate]
|
Rubber, vulcanized or thermoplastic. Determination of compression stress-strain properties
|
Basic data | Standard ID | GB/T 7757-2009 (GB/T7757-2009) | | Description (Translated English) | Rubber, vulcanized or thermoplastic -- Determination of compression stress-strain properties | | Sector / Industry | National Standard (Recommended) | | Classification of Chinese Standard | G40 | | Classification of International Standard | 83.060 | | Word Count Estimation | 13,194 | | Date of Issue | 2009-04-24 | | Date of Implementation | 2009-12-01 | | Older Standard (superseded by this standard) | GB/T 7757-1993 | | Adopted Standard | ISO 7743-2007, IDT | | Regulation (derived from) | PRC National Standard Approval Announcement 2009 No.6 (Total No.146) | | Issuing agency(ies) | General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China | | Summary | This standard specifies the use of a standard sample, product or part of the product was measured vulcanized rubber or thermoplastic rubber compression stress-strain measurement method performance. This method is not material for large permanent deformation. | GB/T 7757-2009: Rubber, vulcanized or thermoplastic -- Determination of compression stress-strain properties
---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Rubber, vulcanized or thermoplastic. Determination of compression stress-strain properties
ICS 83.060
G40
National Standards of People's Republic of China
GB/T 7757-2009/ISO 7743.2007
Replacing GB/T 7757-1993
Vulcanized or thermoplastic rubber
Determination of compression stress-strain properties
(ISO 7743.2007, IDT)
Posted 2009-04-24
2009-12-01 implementation
Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China
Standardization Administration of China released
Foreword
This standard is equivalent to using ISO 7743.2007 (E) "vulcanized rubber or thermoplastic rubber --- compression stress strain properties" English
Text version.
This standard replaces GB/T 7757-1993 "Rubber, vulcanized or thermoplastic - Determination of compression stress-strain properties."
This standard is equivalent translation ISO 7743.2007 (E).
For ease of use, this standard also made the following editorial changes.
a) "this International Standard" be replaced by "this standard";
b) use a decimal point instead of a decimal comma ",". ",";
c) Remove the International Standards Preface;
d) remove the reference.
This standard compared with the previous version, the main changes are as follows.
--- Increased for the product of Test Method C (1993 Edition Chapter 1, Chapter 1 of this edition).
--- Increased the provision of the sample (1993 Edition Chapter 1, Chapter 5, Chapter 6 Chapter 1 edition).
--- Increased demands on the test machine (1993 version 4.4, this version 5.4).
--- Increasing the normative Appendix B calibration (Excerpts Appendix B).
Appendix A of this standard is an informative annex, Annex B normative appendix.
The standard proposed by China Petroleum and Chemical Industry Association.
This standard by the National Standardization Technical Committee and rubber products and chemical physics at the Technical Committee rubber rubber.
This standard Central Rubber Group in Shenyang Rubber Research and Design Institute is responsible for drafting.
The main drafters of this standard. Fecamp red.
This standard replaces the standards previously issued as follows.
--- GB/T 7757-1987, GB/T 7757-1993.
GB/T 7757-2009/ISO 7743.2007
Vulcanized or thermoplastic rubber
Determination of compression stress-strain properties
Warning. Use of this standard should be familiar with normal laboratory practice. This standard does not purport relates to the use of this standard may occur
All security issues. Develop appropriate safety and health system and to ensure compliance with national regulations is the responsibility of the user.
Note. Some programs in this standard may result in waste and pollution to the local environment. After the safe use of the substance
Manage these wastes, reference to the relevant literature.
1 Scope
This standard specifies the use of a standard sample, or a number of products - Determination of vulcanized rubber or thermoplastic rubber measured compressive stress-strain properties
Setting Method.
This standard specifies three methods.
--- Using standard samples and the metal plate (Method A) by the lubricant lubrication;
--- Using standard samples and the sample and the metal plate are bonded together (Method B);
--- Use part of the product or products and the metal plate by Lubricate (Method C).
The results of three methods are not the same. For lubricated by the sample, if it reaches sufficient lubrication, the test results only to rubber mold
For the amount, regardless of the shape of the specimen. However, effective lubrication is often difficult to achieve, it should be the same test sample, the difference comparative test results
To represent different lubrication conditions. For samples with a metal plate bonded together, the modulus of the rubber and the test results of the sample shape.
Sample shape a greater impact on the test results, therefore, the test results and the results by Lubricate the specimen obtained is not significant
with. For the product, depending on the results of the test specimen geometry, but the product is mainly used in the test for comparison purposes, it is acceptable.
Note. For clearly defined shape of the product, such as О-rings, the test results may be associated with hardness values. However, with respect to a predetermined size and shape of the different samples
Thus, the obtained results can not be extrapolated to other sizes and shapes of the test.
Appendix A gives the size and shape of the adhesive or lubricant guidelines impact on the results of the sample.
This method is not permanent deformation of the material used.
Appendix B gives a list of this type of calibration measurements.
2 Normative references
The following documents contain provisions which, through reference in this standard and become the standard terms. For dated references, subsequent
Amendments (not including errata content) or revisions do not apply to this standard, however, encourage the parties to the agreement are based on research
Whether the latest versions of these documents. For undated reference documents, the latest versions apply to this standard.
GB/T 2941 rubber physical test method for sample preparation and conditioning General Procedure (GB/T 2941-2006, ISO 23529.
2004, IDT)
Geometrical product specifications ISO 4287 term surface structure contour method of surface structure, definitions and parameters
ISO 5893 Rubber & Plastics stretching, flexing and compression testing machine (constant speed) technical performance
ISO 18899 rubber test equipment calibration guide
3 Terms and definitions
The following terms and definitions apply to this standard.
GB/T 7757-2009/ISO 7743.2007
...
