GB/T 5095.2304-2021 English PDF

Q: How long will the true-PDF of English version of GB/T 5095.2304-2021 be delivered?

Upon your order, we will start to translate GB/T 5095.2304-2021_English as soon as possible, and keep you informed of the progress. The lead time is typically 1 ~ 3 working days. The lengthier the document the longer the lead time.

Q: Can I share the purchased PDF of GB/T 5095.2304-2021_English with my colleagues?

Yes. The purchased PDF of GB/T 5095.2304-2021_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.

Q: Does the price include tax/VAT?

Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries). Avoidance of Double Taxation Agreements (DTAs) between Singapore and 100+ Countries: https://www.iras.gov.sg/taxes/international-tax

Q: Do you accept my currency other than USD?

Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay.

US$264.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 5095.2304-2021: Electromechanical components for electronic equipment - Basic testing procedures and measuring methods - Part 23-4: Screening and filtering tests - Test 23d: Transmission line reflections in the time domain
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 5095.2304-2021	264	Add to Cart	3 days	Electromechanical components for electronic equipment - Basic testing procedures and measuring methods - Part 23-4: Screening and filtering tests - Test 23d: Transmission line reflections in the time domain	Valid

Similar standards

GB/T 21711.1 GB/T 17737.100 GB/T 5095.2303 GB/T 5095.2307 GB/T 5095.2501

Basic data

Standard ID: GB/T 5095.2304-2021 (GB/T5095.2304-2021)
Description (Translated English): Electromechanical components for electronic equipment - Basic testing procedures and measuring methods - Part 23-4: Screening and filtering tests - Test 23d: Transmission line reflections in the time domain
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: L23
Word Count Estimation: 14,127
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 5095.2304-2021: Electromechanical components for electronic equipment - Basic testing procedures and measuring methods - Part 23-4: Screening and filtering tests - Test 23d: Transmission line reflections in the time domain

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Electromechanical components for electronic equipment - Basic testing procedures and measuring methods - Part 23-4.Screening and filtering tests - Test 23d. Transmission line reflections in the time domain ICS 31.220.10 L23 National Standards of People's Republic of China Electromechanical components for electronic equipment Basic test procedures and measurement methods Part 23-4.Shielding and Filtering Test Test 23d. Transmission line reflection in the time domain (IEC 60512-23-4.2001, Connectorsforelectronicequipment- Testsandmeasurements-Part 23-4.Screeningandfilteringtests- Test23d. Transmissionline reflectionsinthetimedomain, IDT) Released on 2021-03-09 Implemented on 2021-10-01 State Administration of Market Supervision and Administration Issued by the National Standardization Management Committee

Foreword Ⅲ 1 Scope 1 2 Test equipment 1 3 Test sample 1 4 Test device 1 4.1 Test device 1 for test method A 4.2 Test board 1 for test method B 5 Test procedure (Method A and B) 1 6 Test record file 2 6.1 Test methods A and B 2 6.2 Additional items of test method B 3 Appendix A (Normative Appendix) Description of the test board used for test method B 4 Appendix B (informative appendix) TDR practical guide 7

Foreword

GB/T 5095 "Basic test procedures and measurement methods for electromechanical components for electronic equipment" is divided into several parts according to the test methods. Part 23 of GB/T 5095 is shielding and filtering test. The parts that have been released or planned to be released are as follows. ---Part 23-3.Shielding and Filtering Test Test 23c. The shielding effect line injection method of connectors and accessories; ---Part 23-4.Shielding and filtering test test 23d. reflection of transmission line in the time domain; --- Part 23-7.Shielding and Filtering Test Test 23g. The effective transfer impedance of the connector. This part is part 23-4 of GB/T 5095. This section was drafted in accordance with the rules given in GB/T 1.1-2009. The translation method used in this part is equivalent to IEC 60512-23-4.2001 "Connector Test and Measurement for Electronic Equipment Part 23-4" Minutes. shielding and filtering test 23d. reflection of transmission line in the time domain. This section has made the following editorial changes. ---The standard name is composed of "Connector Test and Measurement for Electronic Equipment Part 23-4.Shielding and Filtering Test Test 23d. Time The Reflection of Transmission Lines in the Domain is revised to Part 23-4 of the Basic Test Procedures and Measurement Methods of Electromechanical Components for Electronic Equipment. Shielding and filtering test 23d. reflection of transmission line in the time domain". Please note that some of the contents of this document may involve patents. The issuing agency of this document is not responsible for identifying these patents. This part was proposed by the Ministry of Industry and Information Technology of the People's Republic of China. This part is under the jurisdiction of the National Standardization Technical Committee of Electromechanical Components for Electronic Equipment (SAC/TC166). Drafting organizations of this section. Sichuan Huafeng Enterprise Group Co., Ltd., China Electronics Standardization Institute. The main drafters of this section. Pang Bin, Zhu Ming, Xiao Miao, Wang Qilong, Zhou Yong. Electromechanical components for electronic equipment Basic test procedures and measurement methods Part 23-4.Shielding and Filtering Test Test 23d. Transmission line reflection in the time domain

1 Scope

This part of GB/T 5095 specifies two test methods. The performance of the connector. In these methods, the connector under test is regarded as a transition point with a controlled characteristic impedance in the transmission line. Test method A uses precision coaxial cable and semi-rigid coaxial cable to connect with the connector under test and the test equipment. This test method is applicable For connectors or cable assemblies of various shapes. Test method B uses a precision test board, a precision coaxial cable and a semi-rigid coaxial cable to connect with the connector under test and the test equipment. The try The inspection method is suitable for printed board connectors.

2 Test equipment

Time domain reflectometer (TDR) or pulse generator and oscilloscope, precision cable with characteristic impedance and step Signal generator (if applicable).

3 Test sample

The test sample shall consist of a connector mating pair and/or cable assembly equipped with multiple contacts. The contact can be connected with the corresponding test cable Different signal or ground conductor connections.

4 Test device

4.1 Test device for test method A The required device is a semi-rigid coaxial cable (or equivalent). If special devices are required, as described in 6.1. 4.2 Test board for test method B For the board-to-board connector, two printed circuit test boards with controlled characteristic impedance circuit structure are used. Detailed description in Appendix A The requirements and structure of these test boards are discussed. 5 Test procedure (Method A and B) 5.1 Calibration of the test signal. A calibration curve is used to measure the effective rise time and amplitude of the test signal. The calibration curve used includes The influence of the device in the rise time of the measurement system. Note. It is recommended that the product of the upper frequency limit (MHz) and the rise time of the input signal is approximately 0.6. 5.2 Establishing a zero-reflection baseline. Establish a zero-reflection baseline for the measurement of connector reflection (see Appendix B in B.2 for more information). ......
