US$214.00 · In stock · Download in 9 secondsGB/T 46343.2-2025: Aircraft - Nickel-chromium and nickel-aluminium thermocouple extension cables - Part 2: Terminations general requirements and tests
Delivery: 9 seconds. True-PDF full-copy in English & invoice will be downloaded + auto-delivered via email. See
step-by-step procedureStatus: Valid
| Std ID | Version | USD | Buy | Deliver [PDF] in | Title (Description) |
| GB/T 46343.2-2025 | English | 214 |
Add to Cart
|
3 days [Need to translate]
|
Aircraft - Nickel-chromium and nickel-aluminium thermocouple extension cables - Part 2: Terminations general requirements and tests
|
Click to Preview a similar PDF
Basic data
| Standard ID | GB/T 46343.2-2025 (GB/T46343.2-2025) |
| Description (Translated English) | Aircraft - Nickel-chromium and nickel-aluminium thermocouple extension cables - Part 2: Terminations general requirements and tests |
| Sector / Industry | National Standard (Recommended) |
| Classification of Chinese Standard | V21 |
| Classification of International Standard | 49.060 |
| Word Count Estimation | 10,115 |
| Date of Issue | 2025-10-05 |
| Date of Implementation | 2026-05-01 |
| Issuing agency(ies) | State Administration for Market Regulation and Standardization Administration of China |
GB/T 46343.2-2025: Aircraft - Nickel-chromium and nickel-aluminium thermocouple extension cables - Part 2: Terminations general requirements and tests
---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS 49.060
CCSV21
National Standards of the People's Republic of China
Aircraft Ni-Chromium-Ni-Aluminum Thermocouple Extension Cable
Part 2.General Requirements and Testing for Termination Devices
Published on 2025-10-05
Implemented on May 1, 2026
State Administration for Market Regulation
The State Administration for Standardization issued a statement.
Table of contents
Preface III
Introduction IV
1.Scope 1
2 Normative References 1
3.Terms and Definitions 1
4 General Requirements 2
5.Testing and Verification 3.
Foreword
This document complies with the provisions of GB/T 1.1-2020 "Standardization Work Guidelines Part 1.Structure and Drafting Rules of Standardization Documents".
Drafting.
This document is Part 2 of GB/T 46343 "Extension Cables for Nickel-Chromium/Nickel-Aluminum Thermocouples for Aircraft". GB/T 46343 has been published.
The following section.
---Part 1.General Requirements and Tests for Conductors;
---Part 2.General requirements and testing for termination components.
---Part 3.Dimensions of Crimped Ring Terminals;
---Part 4.Dimensions of Crimped Fittings
This document is equivalent to ISO 8056-2.1988 "Extension cables for nickel-chromium and nickel-aluminum thermocouples for aircraft - Part 2.General requirements for terminals".
Summation test.
The following minimal editorial changes have been made to this document.
---To harmonize with existing standards, the standard name has been changed to "Aircraft Nickel-Chromium/Nickel-Aluminum Thermocouple Extension Cables Part 2.Termination Connections".
"Requirements and Tests".
Please note that some content in this document may involve patents. The issuing organization of this document assumes no responsibility for identifying patents.
This document was proposed and is under the jurisdiction of the National Aircraft Standardization Technical Committee (SAC/TC435).
This document was drafted by. Shanghai Aircraft Design and Research Institute of Commercial Aircraft Corporation of China, Ltd., Shanghai Aircraft Manufacturing Co., Ltd., and AVIC.
General Aircraft South China Aircraft Industry Co., Ltd., AVIC Optoelectronic Technology Co., Ltd., Shenzhen Asia-Pacific Aviation Technology Co., Ltd., Guangzhou Kaiheng
Kesu Co., Ltd., Jiangxi Cable Co., Ltd., and Sichuan Xindian Cable Co., Ltd.
The main drafters of this document are. Xia Xiaojie, Sun Wei, Han Hongwen, Li Rong, Sun Chao, Shen Jingqiang, Xiao Lu, Zhang Huawen, Yao Yuke, Jin Xin, and Zhang Bo.
Li Hui, Liu Yanyue, Zhang Wenhua, and Li Zhun.
Introduction
GB/T 46343 specifies nickel-chromium/nickel-aluminum thermocouple extension cables suitable for aircraft, which are proposed to consist of the following four parts.
---Part 1.General Requirements and Testing for Conductors. The purpose is to specify the general requirements for conductors in aircraft nickel-chromium/nickel-aluminum thermocouple extension cables.
And testing, for the development of conductors for aircraft nickel-chromium-nickel-aluminum thermocouple extension cables.
---Part 2.General Requirements and Tests for Termination Components. The purpose is to specify the general requirements and tests for termination components used in aircraft nickel-chromium/nickel-aluminum thermocouple extension cables.
The requirements and tests were used to develop termination components for aircraft nickel-chromium-nickel-aluminum thermocouple extension cables.
---Part 3.Dimensions of Crimped Ring Terminals. The purpose is to specify the dimensions of crimped ring terminals for aircraft nickel-chromium/nickel-aluminum thermocouple extension cables.
The size requirements of the ring-shaped terminal block are specified for the development of crimp-type ring terminals used in aircraft nickel-chromium-nickel-aluminum thermocouple extension cables.
---Part 4.Crimping Joint Dimensions. The purpose is to specify the dimensions of crimping joints for aircraft nickel-chromium/nickel-aluminum thermocouple extension cables.
The goal is to develop a crimp connector for use in aircraft nickel-chromium/nickel-aluminum thermocouple extension cables.
Aircraft Ni-Chromium-Ni-Aluminum Thermocouple Extension Cable
Part 2.General Requirements and Testing for Termination Devices
1 Scope
This document specifies the general requirements and tests for press-fit non-insulated nickel-chromium alloy or nickel-aluminum alloy terminals.
This document applies to the crimping of standard flexible nickel-chromium alloy or nickel-aluminum alloy conductor thermocouple cables to ensure the thermoelectric performance of the thermocouple circuit.
and resistance stability.
Note. Termination fittings use the same metal material, and their temperature rating is determined by the insulation layer of the crimped cable. Temperature ratings are typically 105℃ and 150℃.
200℃ and 260℃.
2 Normative references
The contents of the following documents, through normative references within the text, constitute essential provisions of this document. Dated citations are not included.
For references to documents, only the version corresponding to that date applies to this document; for undated references, the latest version (including all amendments) applies.
This document.
3 Terms and Definitions
The following terms and definitions apply to this document.
3.1
crimped joint
Crim the terminals or permanent in-line connectors of the appropriate thermocouple material (e.g., nickel-chromium or nickel-aluminum) onto the mating conductor.
A permanent connection is formed.
3.2
Terminal end
A connection device made of a suitable thermocouple material. A permanent connection is formed between the conductor and the terminal using a crimping tool.
Connect and secure the cable insulation layer.
Note. The terminal block includes a crimping sleeve capable of accommodating the thermocouple cable conductor. The crimping sleeve may or may not have additional means for accommodating the cable insulation.
3.3
Termination
Terminal blocks or permanent online connectors.
3.4
crimping
The crimping cylinder around the conductor is physically squeezed or deformed to achieve mechanical and electrical connection.
3.5
insulation support
Part of the crimping cylinder used for inserting cable insulation layers, which fixes the insulation layer by reshaping.
...
