GB/T 43149-2023: Design and metrological characteristics of height gauges
---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS 17.040.30
CCSJ42
National Standards of People's Republic of China
Design and metrological characteristics of height calipers
Published on 2023-09-07
2024-04-01 Implementation
State Administration for Market Regulation
Released by the National Standardization Administration Committee
Table of contents
Preface III
Introduction IV
1 Scope 1
2 Normative reference documents 1
3 Terms and Definitions 1
4 Design Features 2
4.1 Overall design and naming 2
4.2 Main dimensions 5
4.3 Types of indicating devices 6
4.4 Protection level 10
4.5 Measuring claw (needle) 10
4.6 Base 10
4.7 Design characteristics (manufacturer specifications) 10
5 Metrological characteristics 10
5.1 General 10
5.2 Operating conditions 11
5.3 Ruler frame lock 11
5.4 Definition of metrological characteristics (subject to MPE) 11
6 Verification of conformance to specifications12
6.1 General 12
6.2 Measuring standards for calibration of metrological properties12
7 flags 12
Appendix A (Informative) Error Test 13
Appendix B (informative) Data example table 17
Appendix C (informative) Calibration of metrological characteristics 18
Appendix D (informative) Relationship with GPS matrix model 19
Reference 20
Foreword
This document complies with the provisions of GB/T 1.1-2020 "Standardization Work Guidelines Part 1.Structure and Drafting Rules of Standardization Documents"
Drafting.
This document is equivalent to ISO 13225.2012 "Product Geometric Technical Specification (GPS) Length Measuring Instruments. Height Caliper Design and
Measurement Properties”.
This document has made the following minimal editorial changes.
---In order to coordinate with the existing standards, the name of the standard is changed to "Design and Measurement Characteristics of Height Calipers".
Please note that some content in this document may be subject to patents. The publisher of this document assumes no responsibility for identifying patents.
This document is proposed by China Machinery Industry Federation.
This document is under the jurisdiction of the National Standardization Technical Committee for Measuring Tools and Measuring Instruments (SAC/TC132).
This document was drafted by. Chengdu Xincheng Measuring Tools Co., Ltd., Guilin Guanglu Digital Measurement and Control Co., Ltd., Zhejiang Changxing Yufeng Precision Machinery
Co., Ltd., Dongguan Tema Electronics Co., Ltd., Hanzhong Wanmu Instrument and Electric Co., Ltd., Harbin Measuring Tools and Cutting Tools Group Co., Ltd.,
Jingjiang Measuring Tool Co., Ltd., Suzhou Guoliang Measuring Tool Technology Co., Ltd., Qinghai Measuring Tools and Cutting Tools Co., Ltd., Shenzhen Dongye Precision Instrument Co., Ltd.
Co., Ltd., Chengdu Tool Research Institute Co., Ltd.
The main drafters of this document. Dai Chao, Li Daming, Yan Liexue, Yang Jun, Yang Zhongyi, Zhao Geng, Yu Xiaoxia, Qin Xiangdong, Zhao Yonghai, Ma Shibin,
Sun Yunchen, He Yixian.
Introduction
This document is a Geometric Product Specification (GPS) standard and is considered a universal standard for GPS (see ISO 14638). In general GPS matrix
, it affects the size and distance under standard chain links. The GPS master plan given in GB/T 20308 provides the
General principles of GPS systems.
The basic rules for GPS given in ISO 8015 apply to this document, while the default rules given in ISO 14253-1 apply to applications based on
This document establishes specifications unless otherwise stated.
For detailed information on the relationship of the standard to other standards and the GPS matrix model, see Appendix D.
Design and metrological characteristics of height calipers
1 Scope
This document specifies the most important design and metrological characteristics of height calipers (with mechanical or digital display).
2 Normative reference documents
The contents of the following documents constitute essential provisions of this document through normative references in the text. Among them, the dated quotations
For undated referenced documents, only the version corresponding to that date applies to this document; for undated referenced documents, the latest version (including all amendments) applies to
this document.
GB/T 24634-2009 Product Geometric Specification (GPS) General concepts and requirements for GPS measuring equipment (ISO 14978.
2006,IDT)
ISO 14253-1 Geometric Product Specification (GPS) Measurement inspection of workpieces and measuring equipment Part 1.Verification of compliance with specifications
workpieces and measuring equipment-Part 1.Decision rules for verifying conformity or
Note. GB/T 18779.1-2022 Product Geometric Technical Specification (GPS) Measurement Inspection of Workpieces and Measuring Equipment Part 1.Verification according to specifications or
Unqualified determination rules (ISO 14253-1.2017, IDT)
ISO 14253-2 Product Geometric Specification (GPS) Measurement and inspection of workpieces and measuring equipment Part 2.GPS measurement, measurement
spectionby measurementof workpiecesand measuringequipment-Part 2.Guidanceforthe
verification]
Note. GB/T 18779.2-2023 Product Geometric Technical Specification (GPS) Measurement and Inspection of Workpieces and Measuring Equipment Part 2.GPS Measurement, Measuring Equipment
Guide for the evaluation of measurement uncertainty in equipment calibration and product validation (ISO 14253-2.2011, IDT)
ISO /IEC Guide 98-3 Uncertainty of measurement Part 3.Guidelines for the expression of uncertainty of measurement (GOM.1995)
1995)]
Note. GB/T 27418-2017 Evaluation and expression of measurement uncertainty (ISO /IEC Guide 98-3.2008, MOD)
Note. GB/T 4208-2017 Enclosure protection level (IP code) (IEC 60529.2013, IDT)
3 Terms and definitions
The following terms and definitions as defined in GB/T 24634-2009 and ISO /IEC Guide 99 apply to this document.
3.1
Height caliperheightgauge
The ruler frame with measuring claws can move relative to the scale on the ruler body (or column), and the movement is along a direction perpendicular to the reference plane of the base.
...
