GB/T 42151.92-2025: Communication networks and systems for power utility automation - Part 9-2: Specific communication service mapping(SCSM) - Sampled values over ISO/IEC 8802-3
Delivery: 9 seconds. True-PDF full-copy in English & invoice will be downloaded + auto-delivered via email. See step-by-step procedure
Status: Valid

Std ID	Version	USD	Buy	Deliver [PDF] in	Title (Description)
GB/T 42151.92-2025	English	674	Add to Cart	5 days [Need to translate]	Communication networks and systems for power utility automation - Part 9-2: Specific communication service mapping(SCSM) - Sampled values over ISO/IEC 8802-3

GB/T 42151.92-2025: Communication networks and systems for power utility automation - Part 9-2: Specific communication service mapping(SCSM) - Sampled values over ISO/IEC 8802-3

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS 29.240.01 CCSF21 National Standards of the People's Republic of China Power automation communication networks and systems Part 9-2.Specific Communication Service Mapping (SCSM) Sampled values based on ISO /IEC 8802-3 (IEC 61850-9-2.2020, IDT) Published on 2025-10-31 Implemented on May 1, 2026 State Administration for Market Regulation The State Administration for Standardization issued a statement.

Table of contents

Preface III Introduction IV 1.Scope 1 2 Normative References 1 3 Terms and Definitions 4.Abbreviations 3. 5.Communication Protocol Stack 4 5.1 Protocol Application Overview 4 5.2 Client/Server Services and Communication Protocol Set 4 5.3 Sample Value Service and Communication Protocol Set 4 5.3.1 Sampling value mapping requirements 4 5.3.2 A Protocol Subset 5 5.3.3 T Protocol Subset 5 5.4 Limitation 8 6.Data attribute mapping for IEC 61850-7-2 and IEC 61850-7-3 8. 7 IEC 61850-7-2 Class and Service Mapping 8 7.1 Sample Value Dataset Class 8 7.2 Definition of Sample Value Dataset 8 8.Sample value transfer model mapping 8 8.1 Overview 8.2 Multicast Sample Value Control Block Class and Service Mapping 9 8.2.1 Multicast Sample Value Control Block Definition 9 8.2.2 Multicast Sample Value Service 10 8.3 Unicast Sample Value Control Block Class and Service Mapping 11 8.4 Update the sampling value buffer mapping 11 8.5 Supplementary Definition for Sample Value Transmission 11 8.5.1 Application Layer Functions 11 8.5.2 Presentation Layer Functionality 12 8.6 Basic Data Type Definitions - Presentation Layer Functionality 13 9.Time synchronization 15 10 Consistency 16 10.1 Symbol 16 10.2 PICS 16 10.2.1 Protocol Subset Consistency 16 10.2.2 Sample Value Service 16 11 Substation Configuration Language (SCL) 17 12 SCSM Specific Address Element Definition 17 Appendix A (Informative) ISO /IEC /IEEE 8802-3 Frame Format and ASN.1 Basic Encoding Rules 18 A.1 ISO /IEC /IEEE 8802-3 frame format 18 A.2 ASN.1 Basic Encoding Rules (BER) 21 A.3 ASN.1 Encoded APDU Frame Structure Example 21 Appendix B (Informative) Multicast Address Selection 23 Appendix C (Normative) Compatibility of different revisions of IEC 61850-9-2 24 C.1 Overview 24 C.2 IEC 61850-9-2 Compatibility Rule 24 C.3 Other changes involving backward/forward compatibility 24 C.3.1 Physical Layer Specification Advanced Reference 24 C.3.2 Add optional field 24 to the data frame C.3.3 Add Time Synchronization Specification 24 C.3.4 Field value deletion 24 C.3.5 Attribute value modification 25 C.3.6 Simulation 25 References 26

Foreword

This document complies with the provisions of GB/T 1.1-2020 "Standardization Work Guidelines Part 1.Structure and Drafting Rules of Standardization Documents". Drafting. This document is Part 9-2 of GB/T 42151 "Communication Networks and Systems for Power Automation". GB/T 42151 has published the following... part. ---Part 3.General Requirements; ---Part 4.Systems and Project Management; ---Part 5.Communication Requirements for Functional and Device Models; ---Part 6.A Description Language for Communication Configuration of Power Automation Systems Related to Intelligent Electronic Devices; ---Part 7-1.Basic Communication Structure Principles and Models; ---Part 7-2.Basic Information and Communication Structure Abstract Communication Service Interface (ACSI); ---Part 7-7.Machine-processable format of relevant IEC 61850 data models for tools; ---Part 8-1.Specific Communication Service Mapping (SCSM) Mapping to MMS (ISO 9506-1 and ISO 9506-2) and ISO /IEC 8802-3; ---Part 9-2.Specific Communication Service Mapping (SCSM) based on sampled values from ISO /IEC 8802-3. This document is equivalent to IEC 61850-9-2.2020 "Electric power automation communication networks and systems - Part 9-2.Specific communication services". Sampling (SCSM) based on ISO /IEC 8802-3 sampling values. The following minimal editorial changes have been made to this document. ---Based on the actual citations in the text, Chapter 2 has added ISO 9506 (all parts); ---Based on the actual citations in the text, ISO 9506-2.2003, IEEE 754.1985, and IEEE 802.1Q.1998 in Chapter 2 have been changed to No date reference; ---The text does not reference ISO /IEC 8326.1996, ISO /IEC 8327-1.1996, ISO /IEC 8649.1996, ISO /IEC 8650-1.1996, ISO /IEC 8822.1994, ISO /IEC 8823-1.1994, RFC791, RFC792, RFC793, RFC826, RFC894, RFC919, RFC1006, RFC1112, and RFC2460 have been moved from Chapter 2 to the References section. ---References have been added. Please note that some content in this document may involve patents. The issuing organization of this document assumes no responsibility for identifying patents. This document was proposed by the China Electricity Council. This document is under the jurisdiction of the National Technical Committee on Standardization of Power System Management and Information Exchange (SAC/TC82). This document was drafted by. State Grid Nanjing Automation Co., Ltd., State Grid Electric Power Research Institute Co., Ltd., and State Grid Corporation of China. National Power Dispatch and Control Center, Nanjing NARI Engineering & Technology Co., Ltd., Beijing Sifang Automation Co., Ltd., XJ Group Electric Co., Ltd., China Electric Power Research Institute Co., Ltd., Jiangsu Hongyuan Electric Co., Ltd., Changyuan Shenrui Relay Protection & Automation Co., Ltd. Limited Liability Company, Tianjin Jingui Huihai Technology Development Co., Ltd., and Quzhou Power Supply Company of State Grid Zhejiang Electric Power Co., Ltd. The main drafters of this document are. Yin Jun, Dong Bei, Shen Jian, Chang Naichao, Du Jun, Ren Yanming, Liao Zeyou, Zhou Bin, Li Jinsong, Yang Song, and Liu Wensong. Sun Dan, Li Qiang, Tang Yongjian, Zheng Xiang, Sun Ming.

Introduction

GB/T 42151, "Communication Networks and Systems for Power Automation," aims to provide interoperability for all devices in power automation systems. It consists of the following parts. ---Part 1.Overview. This section aims to provide an overview of the series of standards. ---Part 2.Terminology. This section aims to list the terms and definitions used in this series of standards. ---Part 3.General Requirements. This section aims to introduce the general requirements for communication networks, with a focus on quality requirements. ---Part 4.Systems and Project Management. The purpose is to describe the requirements for systems and project management processes, as well as the requirements for engineering and testing. Requirements for specialized support tools. ---Part 5.Communication Requirements for Functional and Device Models. The purpose is to specify the communication requirements for each function of the power automation system. ---Part 6.A description language for communication configuration of power automation systems associated with intelligent electronic devices. The purpose is to achieve some degree of compatibility. Description of the ability to exchange information between intelligent electronic devices, and the exchange of power automation systems between tools provided by different manufacturers. describe. ---Part 7.Basic Communication Structure of Power Automation Systems. The purpose is to define a hierarchical class model and the communication methods provided by these classes. The service enables communication between devices. ---Part 8.Specific Communication Service Mapping (SCSM). The purpose is to provide services within the substation control layer and bay layer, as well as between the control layer and... Communication mapping between interval layers. ---Part 9.Specific Communication Service Mapping (SCSM). The purpose is to provide services within the substation bay layer and process layer, as well as between the bay layer and... Communication mapping between process layers. ---Part 10.Conformance Testing. The purpose is to specify the standard techniques for implementing conformance testing and the methods to be used when proposing performance parameters. Specific measurement techniques. This document is Part 9-2 of GB/T 42151 "Electric Power Automation Communication Networks and Systems", which defines communication networks and systems based on ISO /IEC 8802-3. Transmitted Sampled Values Specific Communication Service Mapping (SCSM) This Specific Communication Service Mapping provides a complete sampled value model mapping. As described in IEC TR61850-1, the communication structure of the process bus has different organizational forms. Besides direct communication via ISO /IEC... 8802-3 transmits sampled value datasets. To access the sampled value control block, the relevant IEC 61850-8-1 service is required. This specific communication service... The service mapping provides references to the relevant IEC 61850-8-1 services. In less complex devices (such as merging units), the sampled value control block can... It can be pre-configured, in which case there is no need to implement IEC 61850-8-1 services based on the MMS protocol stack. This document defines the mapping from the sampled value model (IEC 61850-7-2) to ISO /IEC 8802-3.This specific communication service mapping is related to... IEC 61850-7 and IEC 61850-6 together enable interoperability between equipment from different manufacturers. This document does not specify the implementation of an individual or product, nor does it restrict the implementation of entities and interfaces in a computer system. Power automation communication networks and systems Part 9-2.Specific Communication Service Mapping (SCSM) Sampled values based on ISO /IEC 8802-3

1 Scope

This document specifies the mapping of specific communication services for sampled value transmission in accordance with the IEC 61850-7-2 Abstract Communication Service Specification. (SCSM). This mapping is an abstract model based on a hybrid protocol stack, which directly accesses ISO /IEC 8802-3 link transmission samples. The value also utilizes relevant services from IEC 61850-8-1. Specific Communication Service Map (SCSM) consists of three parts. ---Detailed description of the communication protocol stack used; ---The mapping method between the abstract specifications of IEC 61850-7 and the specific elements of the protocol stack; ---This protocol stack does not include the implementation specifications for certain features.

2 Normative references

The contents of the following documents, through normative references within the text, constitute essential provisions of this document. Dated citations are not included. For references to documents, only the version corresponding to that date applies to this document; for undated references, the latest version (including all amendments) applies. This document. GB/T 16262.1-2025 Abstract Syntax Notation for Information Technology I (ASN.1) Part 1.Basic Notation Specification (ISO /IEC 8824-1.2021, IDT) Note. The content referenced in GB/T 16262.1-2025 has no technical differences from the content referenced in ISO /IEC 8824-1.2008. GB/T 25931-2010 Precise clock synchronization protocol for networked measurement and control systems (IEC 61588.2009, IDT) Note. GB/T 12406-2022 represents the currency code (ISO 4217.2015, MOD). Note. GB/T 16720 (all parts) Specification for Manufacturing Messages of Industrial Automation Systems [ISO 9506 (all parts)] Note. GB/T 16720.2-2005 Industrial Automation System Manufacturing Message Specification Part 2.Protocol Specification (ISO 9506-2.2003, IDT) ISO /IEC /IEEE 8802-3 Requirements for communication and data exchange between information systems (Local Area Networks and Metropolitan Area Networks) - Part 3.Ethernet Note. GB/T 15629.3-2014 Information Technology - Telecommunication and Information Exchange Between Systems - Specific Requirements for Local Area Networks and Metropolitan Area Networks - Part 3.With Collision... Collision-detection carrier sense multiple access (CSMA/CD) access method and physical layer specification (ISO /IEC 8802-3.2000, MOD) ISO /IEC 8825-1 Information Technology ASN.1 Coding Rules Part 1.Basic Coding Rules (BER), Regular Coding Rules codingRules(DER)] ...
