GB/T 41099-2021: Specifications for monitoring system for reciprocating compressors
---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Specifications for monitoring system for reciprocating compressors ICS 23:140 CCSJ72 National Standards of People's Republic of China Specification for monitoring systems for reciprocating piston compressors Published on 2021-12-31 2022-07-01 Implementation State Administration for Market Regulation Released by the National Standardization Administration directory Preface I 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 General Requirements 3 5 Monitoring requirements4 6 Monitoring software5 7 Signal Processing and Feature Extraction 6 8 Parameter alarm and analysis and diagnosis 7 9 Monitoring and Analysis Report 7 Appendix A (Informative) Monitoring Signal Normal Range 8 Appendix B (Informative) Common Sensor Measurement Point Configuration Scheme 9 Appendix C (Informative) Installation and Layout Scheme of Commonly Used Sensor Measuring Points 11 Appendix D (informative) Calculation method of monitoring characteristic parameters 14 Appendix E (Informative) Common Fault Monitoring Characteristics Comparison Table 16 Appendix F (Informative) Monitoring Analysis Report Template 17 Reference 18 Figure C:1 Schematic diagram of common sensor measuring point layout 11 Figure C:2 Schematic diagram of measuring point layout of crosshead slide housing vibration sensor 12 Figure C:3 Schematic diagram of crankcase vibration sensor measuring point layout 12 Figure C:4 Schematic diagram of measuring point layout of piston rod offset sensor 13 Figure C:5 Schematic diagram of cylinder vibration and dynamic pressure sensor measuring point layout 13 Figure D:1 Calculation of the axis path of the piston rod Figure 15 Table 1 Monitoring category, sensor installation location, sensor selection, signal collection method and alarm 4 Table 2 Basic parameters of the sensor5 Table 3 Visual analysis and diagnosis functions of monitoring software 6 Table A:1 Normal reference range of monitoring signal8 Table B:1 Standard configuration of sensor measuring points for reciprocating piston compressors with crosshead and piston rod structure9 Table B:2 Standard configuration of sensor measuring points for reciprocating piston compressors without crosshead and piston rod structure9 Table B:3 Optional sensor measuring point configuration for reciprocating piston compressor with crosshead and piston rod structure 9 Table B:4 Optional sensor measuring point configuration for reciprocating piston compressors without crosshead and piston rod structure 10 Table C:1 Recommended sensor installation method 11 Table E:1 Common fault monitoring characteristics comparison table 16
