GB/T 40703-2021: Design specifications of medium temperature solar heating system for industrial applications
Delivery: 9 seconds. True-PDF full-copy in English & invoice will be downloaded + auto-delivered via email. See step-by-step procedure
Status: Valid

Std ID	Version	USD	Buy	Deliver [PDF] in	Title (Description)
GB/T 40703-2021	English	339	Add to Cart	4 days [Need to translate]	Design specifications of medium temperature solar heating system for industrial applications

GB/T 40703-2021: Design specifications of medium temperature solar heating system for industrial applications

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Design specifications of medium temperature solar heating system for industrial applications ICS 27.160 CCSF12 National Standards of People's Republic of China Design specification for solar energy medium temperature industrial heat utilization system applications Released on 2021-10-11 2022-05-01 implementation State Administration for Market Regulation Issued by the National Standardization Management Committee

Table of contents

Foreword Ⅲ 1 Scope 1 2 Normative references 1 3 Terms and definitions 1 4 System composition 2 5 Basic rules 2 6 Parameters for system design 3 7 Energy demand analysis 3 8 Solar collector system 3 8.1 General provisions 3 8.2 Calculation of collector area 4 8.3 Layout of solar collector system 4 8.4 Expansion tank 5 8.5 Buffer tank 5 8.6 Oil storage tank 6 8.7 Oil and gas separator 6 9 Thermal storage system 6 9.1 General provisions 6 9.2 Heat storage medium 6 9.3 Heat storage device 6 10 Heating system 6 10.1 General provisions 6 10.2 Steam generator 7 10.3 Auxiliary energy equipment 7 11 Electrical and control system 7 11.1 General provisions 7 11.2 Control Subsystem 7 11.3 Monitoring subsystem 8 11.4 Electrical safety protection 9 12 General equipment 9 12.1 Circulating pump 9 12.2 Heat transfer working fluid 9 12.3 Heat exchanger 10 12.4 Water treatment equipment 10 12.5 Piping and valves 10 13 System Security 10 Appendix A (informative) Typical process temperature of different industrial processes 12 Appendix B (informative) Recommended collector selection 13 Reference 14

Foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for Standardization Work Part 1.Structure and Drafting Rules of Standardization Documents" Drafting. Please note that some of the contents of this document may involve patents. The issuing agency of this document is not responsible for identifying patents. This document was proposed and managed by the National Solar Energy Standardization Technical Committee (SAC/TC402). Drafting organizations of this document. Shandong Linuorit New Energy Co., Ltd., China National Institute of Standardization, China Academy of Building Research Co., Ltd. Division, Jianke Environmental Energy Technology Co., Ltd., Shanghai Jiaotong University, Shandong Product Quality Inspection Research Institute, Hubei Product Quality Supervision and Inspection Research Institute, Institute of Electrical Engineering, Chinese Academy of Sciences, Institute of Engineering Thermophysics, Chinese Academy of Sciences, Chengdu Boyu New Energy Co., Ltd., Sunpu Energy Technology Co., Ltd., Shandong Qiweite Solar Energy Technology Co., Ltd., Beijing Building Materials Inspection and Research Institute Co., Ltd., Shantou Pu Solar Technology Co., Ltd. Co., Ltd., Guangdong Five Star Solar Co., Ltd. The main drafters of this document. Ma Guangbai, Wang Geng, Liu Meng, Wang Min, Li Bojia, Dai Yanjun, Sun Yuquan, Wu Xiaohong, Yuan Guofeng, Chen Haisheng, Xu Yujie, Liu Jun, Sun Shoujian, Yu Jianwei, Gu Xiuzhi, Tang Wenxue, Su Shiqiang, Liu Huakai, Yang Jie, Zhang Siman, Zhao Xuezhi, Yuan Wanli, Wen Shurong, He Tingting and Hu Zhipeng. Design specification for solar energy medium temperature industrial heat utilization system

1 Scope

This document specifies the system composition, design parameters, and energy demand analysis of the solar energy medium-temperature industrial heat utilization system (hereinafter referred to as the "system") Analysis, general equipment requirements, solar heat collection systems, heat storage systems, heating systems, electrical and control systems, and system safety protection requirements. This document is applicable to those that use liquid as the heat transfer medium, and the heat collection temperature is greater than 100°C and less than 250°C to provide heat energy for industrial processes. Solar system. The solar energy medium-temperature heat utilization system that provides heat for civilian processes can be implemented with reference to this document.

2 Normative references

The content of the following documents constitutes an indispensable clause of this document through normative references in the text. Among them, dated quotations Only the version corresponding to the date is applicable to this document; for undated reference documents, the latest version (including all amendments) is applicable to This document. GB/T 150.1 Pressure Vessel Part 1.General Requirements GB/T 151 heat exchanger GB/T 1576 Industrial boiler water quality GB/T 3797 electrical control equipment GB/T 12936 Terminology for Solar Thermal Utilization GB/T 16895.21 Low-voltage electrical installations Part 4-41.Safety protection and electric shock protection GB/T 18713 Technical Code for Design, Installation and Engineering Acceptance of Solar Hot Water System GB/T 20095 Specification for Performance Evaluation of Solar Hot Water System GB/T 29724 Energy monitoring of solar water heating system GB/T 40517 Solar energy medium and low temperature heat storage device GB 50016 Code for fire protection of building design GB 50057 Code for lightning protection design of buildings GB 50303 Code for Acceptance of Construction Quality of Building Electrical Engineering GB 50364 Technical Standard for the Application of Solar Water Heating System in Civil Buildings GB 50974 Technical Specification for Fire Water Supply and Hydrant System GB 51348 Electrical Design Standard for Civil Buildings SY/T 0515 Specification for Oil and Gas Separator SY/T 0524 Thermal oil heating furnace system specification ISO 9488 Solar Energy Vocabulary (Solarenergy-Vocabulary)

3 Terms and definitions

The following terms and definitions defined in GB/T 12936, GB/T 18713 and ISO 9488 apply to this document. 3.1 Solar medium temperature industrial heat utilization system mediumtemperaturesolarheatingsystemforindustrialapplications The solar heat collection temperature is greater than 100°C and less than 250°C, and it is a system that provides heat energy for industrial production processes. Note. The system consists of solar heat collection system, heat storage system, heating system, electrical and control system. ...
