GB/T 38943.2-2020: Earth-moving machinery--Electrical safety of machines utilizing electric drives and related components and systems - Part 2: Particular requirements for externally-powered machines
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 38943.2-2020	414	Add to Cart	3 days	Earth-moving machinery--Electrical safety of machines utilizing electric drives and related components and systems - Part 2: Particular requirements for externally-powered machines	Valid

Similar standards

GB/T 44257.1   GB/T 44257.2   GB/T 41495   GB/T 25606   GB/T 45375   GB/T 38943.3

Basic data

Standard ID: GB/T 38943.2-2020 (GB/T38943.2-2020)
Description (Translated English): Earth-moving machinery--Electrical safety of machines utilizing electric drives and related components and systems - Part 2: Particular requirements for externally-powered machines
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: P97
Classification of International Standard: 53.100
Word Count Estimation: 22,275
Date of Issue: 2020-07-21
Date of Implementation: 2020-11-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 38943.2-2020: Earth-moving machinery--Electrical safety of machines utilizing electric drives and related components and systems - Part 2: Particular requirements for externally-powered machines

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Earth-moving machinery--Electrical safety of machines utilizing electric drives and related components and systems--Part 2.Particular requirements for externally-powered machines ICS 53.100 P97 National Standards of People's Republic of China Earth-moving machinery uses electric-driven machinery and Electrical safety of related parts and systems Part 2.Specific requirements for externally powered machines (ISO 14990-2.2016, IDT) 2020-07-21 released 2020-11-01 implementation State Administration for Market Regulation Issued by the National Standardization Management Committee

Table of contents

Preface Ⅲ Introduction Ⅳ 1 Scope 1 2 Normative references 1 3 Terms and definitions 1 4 General requirements 2 5 Protection against electric shock 2 6 Electrical fire protection 4 7 Protection against thermal hazards 4 8 Mechanical hazard protection 4 9 Protection against abnormal operation hazards 5 10 Power source 5 11 Route 6 12 Electric motor 8 13 Non-motor load 8 14 Control system 8 15 Manuals and technical documents 8 16 Mark 9 17 Experiment 10 Appendix A (informative appendix) Inquiry form for electrical equipment of external power machinery 11 Reference 14

Foreword

GB/T 38943 "Electrical Safety of Machinery Driven by Electricity for Earth-moving Machinery and Related Parts and Systems" is divided into three parts. ---Part 1.General requirements; ---Part 2.Specific requirements for external power machines; ---Part 3.Specific requirements for self-propelled machines. This part is Part 2 of GB/T 38943. This section was drafted in accordance with the rules given in GB/T 1.1-2009. The translation method used in this part is equivalent to the adoption of ISO 14990-2.2016 ``Earth-moving machinery using electric drive machinery and related parts and Electrical safety of the system Part 2.Specific requirements for externally powered machines. The Chinese documents that have a consistent correspondence with the international documents cited in this section are as follows. ---GB/T 4026-2019 Basic and safety rules for the identification of human-machine interface, equipment terminal, conductor terminal and conductor mark Knowledge (IEC 60445.2017, IDT); ---GB/T 16895.6-2014 Low-voltage electrical installations Part 5-52.Selection of electrical equipment and installation wiring system (IEC 60364-5-52.2009, IDT); ---GB/T 16935.1-2008 Insulation coordination of equipment in low-voltage systems Part 1.Principles, requirements and tests (IEC 60664-1.2007, IDT); ---GB/T 38943.3-2020 Electrical safety of earth-moving machinery and related parts and systems driven by electricity No. 3 Part. Specific requirements for self-propelled machines (ISO 14990-3.2016, IDT). This section has made the following editorial changes. --- Supplementary explanation for the symbols of the electric motor (motor) not explained in Figure 2. Please note that certain contents of this document may involve patents. The issuing agency of this document is not responsible for identifying these patents. This part was proposed by China Machinery Industry Federation. This part is under the jurisdiction of the National Earthmoving Machinery Standardization Technical Committee (SAC/TC334). Drafting organizations of this section. Xuzhou Construction Machinery Group Co., Ltd., Anhui Zhiyi Technology Development Co., Ltd., Tianjin Construction Machinery Research Institute Co., Ltd., Shaanxi Tongli Heavy Industry Co., Ltd. The main drafters of this section. Guan Enlu, Jin Huijie, Liu Jiao, Chen Chaohua, Wang Xia.

Introduction

Electrification technology can make machine packaging more flexible. Early earth-moving machinery (EMM) electrical systems were mainly in the 12V~24V direct Within the flow range, so you need to pay special attention to the following two safety aspects. ---Very high voltages, such as those used in industry, construction and other transportation sectors; ---Greater available electrical energy. Part of this section applies to electrical design (such as Chapter 9, Chapter 11, Chapter 12, and Chapter 17). Due to certain design attributes It is inseparable from electrical safety, so these requirements are necessary. Part of the content of this section is based on IEC 60204-1 and IEC 60204-11, and adjusted according to the actual needs of earth-moving machinery. Non-electrical hazards are described in the ISO 20474 series of standards. Figure 1 helps to understand the relationship between the various components of a machine and its related equipment. Figure 1 is a typical machine and related equipment The prepared block diagram shows the various components of the electrical equipment mentioned in this section. Figure 1 Typical machine frame diagram Earth-moving machinery uses electric-driven machinery and Electrical safety of related parts and systems Part 2.Specific requirements for externally powered machines

1 Scope

This part of GB/T 38943 specifies the characteristics of the electrical system and its components of the electric drive earthmoving machinery (EMM) using external power. Set safety requirements. This part is applicable to AC with any frequency within the range of 50V~36kV and DC within the range of 75V~36kV. Electricity, including any machine for outdoor use with repetitive rate pulsating direct current. The voltage inside the device is not on-board voltage, so it is not within the scope of this section. This part is used in conjunction with GB/T 38943.1.GB/T 38943.1 specifies the general requirements for electric-driven earth-moving machinery. GB/T 38943.3 specifies the specific requirements for self-propelled earth-moving machinery. For earth-moving machinery that has both self-powered and external power (e.g. Such as a battery-powered machine with a built-in charger and power supply function), it should also meet the requirements of GB/T 38943.3.

2 Normative references

The following documents are indispensable for the application of this document. For dated reference documents, only the dated version applies to this article Pieces. For undated references, the latest version (including all amendments) applies to this document. GB/T 38943.1-2020 Electrical safety of earth-moving machinery and related parts and systems driven by electricity, Part 1 Points. General requirements (ISO 14990-1.2016, IDT) ISO 14990-3 Earth-moving machinery, electrical safety of electrical-driven machinery and related parts and systems-Part 3.Self-propelled Machine specific requirements (Earth-movingmachinery-Electricalsafetyofmachinesutilizingelectricdrivesorre- latedcomponentsandsystems-Part 3.Particularrequirementsforself-poweredmachines) IEC 60071-1.2006 Insulation Coordination Part 1.Definitions, Principles and Rules (InsulationCoordination-Part 1. Definitions,principlesandrules) IEC 60071-1Amd.l.2010 Insulation Coordination Part 1.Definitions, Principles and Rules (InsulationCoordination- Part 1.Definitions,principlesandrules) IEC 60364-5-52 Low-voltage electrical installations Part 5-52.Selection and installation of electrical equipment wiring system (Low-voltage electricalinstalations-Part 5-52.Selectionanderectionofelectricalequipment-Wiringsystems) IEC 60445 The basic principles and safety principles of human-machine interface, signs and identifications. Identification of equipment terminals, wire ends and wires (Basicandsafetyprinciplesforman-machineinterface,markingandidentification-Identificationof equipmentterminals.conductorterminationsandconductors) IEC 60664-1 Insulation coordination of equipment in low-voltage systems-Part 1.Principles, requirements and tests (Insulation coordination forequipmentwithinlow-voltagesystems-Part 1.Principles,requirementsandtests)

3 Terms and definitions

The terms and definitions defined in GB/T 38943.1-2020 apply to this document. ......
