Test method of conversion efficiency of terrestrial photovoltaic (PV) modules
|
Click to Preview a similar PDF
Basic data
| Standard ID | GB/T 34160-2017 (GB/T34160-2017) |
| Description (Translated English) | Test method of conversion efficiency of terrestrial photovoltaic (PV) modules |
| Sector / Industry | National Standard (Recommended) |
| Classification of Chinese Standard | F12 |
| Classification of International Standard | 27.160 |
| Word Count Estimation | 6,695 |
| Date of Issue | 2017-09-07 |
| Date of Implementation | 2018-04-01 |
| Issuing agency(ies) | General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China |
GB/T 34160-2017: Test method of conversion efficiency of terrestrial photovoltaic (PV) modules
---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Test method of conversion efficiency of terrestrial photovoltaics (PV) modules
ICS 27.160
F12
National Standards of People's Republic of China
Photovoltaic conversion efficiency test method of photovoltaic module on the ground
photovoltaic (PV) modules
2017-09-07 Posted
2018-04-01 implementation
General Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China
China National Standardization Administration released
Foreword
This standard was drafted in accordance with the rules given in GB/T 1.1-2009.
This standard is proposed by the State Administration of Quality Supervision, Inspection and Quarantine.
This standard is centralized by China National Institute of Standardization.
This standard was drafted unit. National Solar PV Products Quality Supervision and Inspection Center, Yingli Energy (China) Co., Ltd., Crystal Division have energy
Limited, Zhejiang Global Photovoltaic Technology Co., Ltd., Lianyungang China New Energy Co., Ltd., Shaanxi Nonferrous Optoelectronics Technology Co., Ltd., Lee Teng
Hui Technology Co., Ltd., Tianjin Yingli New Energy Co., Ltd., Shenzhen Institute of Standards and Technology, Xiamen City Product Quality Supervision and Inspection Institute.
The main drafters of this standard. Hu Dan, Huai Chaojun, Wu Cuigu, Li Yingye, Jin Hao, Zhang Ming, He Tao, He Yani, Chen Jie, Wang Hui,
Zhuang Peng, Wu Yuan.
Photovoltaic conversion efficiency test method of photovoltaic module on the ground
1 Scope
This standard specifies the method of photoelectric conversion efficiency of photovoltaic modules on the ground.
This standard applies to flat photovoltaic modules (including crystalline silicon, thin film components, etc.).
This standard does not apply to double-sided photovoltaic modules, concentrating photovoltaic modules.
2 Normative references
The following documents for the application of this document is essential. For dated references, only the dated version applies to this article
Pieces. For undated references, the latest edition (including all amendments) applies to this document.
ISO /IEC 17025 testing and calibration laboratory capacity requirements (Generalrequirementsforthecompetenceof
testingandcalibrationlaboratories)
IEC 60904-1 Photovoltaic devices - Part 1. Measurement of PV current-voltage characteristics (Photovoltaicdevices-Part 1.
Measurementofphotovoltaiccurrent-voltagecharacteristics)
IEC 60904-2 Photovoltaic devices - Part 2. Requirements for standard solar cells (Photovoltaicdevices-Part 2.Require-
mentsforreferencesolardevices)
IEC 60904-9 Photovoltaic devices Part 9. Solar simulator performance requirements (Photovoltaicdevices-Part 9.Solar
simulatorperformancerequirements)
IEC 61215 ground crystalline silicon photovoltaic modules (PV) design identification and stereotypes (Crystalinesiliconterrestrialphoto-
voltaic (PV) modules-Designqualificationandtypeapproval)
IEC 61646 Surface-Mount Thin-Film Terrestrial Photovoltaic (PV)
modules-Designqualificationandtypeapproval)
3 Terms and definitions
The following terms and definitions apply to this document.
3.1
Total component totalmodulearea
The area defined by the outer edge of the upper surface of the component, which is the normal projection area of the incident surface of the component.
Note. The total area of the components is the sum of the total area of the solar cells and the area of the uncovered solar cells, and the vertical projection area of the upper surface of the bezel (if any)
Included.
3.2
Active component activemodulearea
The effective area of a component equals the total area of the solar cells in the component.
Note 1. The effective area of the crystalline silicon module includes the area of the line that is removed. The effective area of the thin film module includes the dead area and the scribe area.
Note 2. The effective area of the component is sometimes referred to as the component window area.
3.3
Module efficiency moduleefficiency
Under specified test conditions, the percentage of the maximum power of the illuminated component to the irradiance incident on the total area of the component.
...
