GB/T 33552-2017: Small-size gasoline engine direct-link high speed centrifugal pumps -- Specification for performance evaluation
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 33552-2017	109	Add to Cart	3 days	Small-size gasoline engine direct-link high speed centrifugal pumps -- Specification for performance evaluation	Valid

Similar standards

GB/T 24674   GB/T 33006   GB/T 25409   GB/T 33548   GB/T 33547

Basic data

Standard ID: GB/T 33552-2017 (GB/T33552-2017)
Description (Translated English): Small-size gasoline engine direct-link high speed centrifugal pumps -- Specification for performance evaluation
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: B91
Classification of International Standard: 65.060.35
Word Count Estimation: 5,591
Date of Issue: 2017-03-09
Date of Implementation: 2017-10-01
Quoted Standard: GB/T 2828.1; GB/T 2829; GB/T 3216; GB/T 24673
Regulation (derived from): National Standard Notice No. 5 of 2017
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the performance rating evaluation index, other requirements, test methods, inspection rules and performance grade of small gasoline engine direct connection high speed centrifugal pump. This standard applies to the rated power �� 5.89 kW, the speed of 3 600 r/min and above the small gasoline engine direct high-speed centrifugal pump (hereinafter referred to as pump).

GB/T 33552-2017: Small-size gasoline engine direct-link high speed centrifugal pumps -- Specification for performance evaluation

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Small-size gasoline engine direct-link high speed centrifugal pumps - Specification for performance evaluation ICS 65.060.35 B91 National Standards of People's Republic of China Small gasoline engine direct high - speed centrifugal pump Performance evaluation specification 2017-03-09 released 2017-10-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China China National Standardization Management Committee released

Foreword

This standard is drafted in accordance with the rules given in GB/T 1.1-2009. This standard is proposed by the China Machinery Industry Federation. This standard by the National Agricultural Machinery Standardization Technical Committee (SAC/TC201) centralized. The main drafting unit of this standard. China Agricultural Mechanization Research Institute, Jiangsu University Fluid Machinery Engineering Technology Research Center, Liou set Mission Zhejiang Pump Co., Ltd., Hangzhou Slater Pump Co., Ltd., Ai Erda Motor Co., Ltd., Zhejiang Xi Ling Co., Ltd., Wenling City Pengzhuo Electromechanical Technology Co., Ltd., Taizhou Dongxie Electrical Machinery Factory, National Pump and System Engineering Technology Research Center, Wenling City, Zhejiang Province Supervision and inspection. The main drafters of this standard. Zhang Xiansheng, Wang Yang, Yan Dongfu, Zhang Jiangping, Zhao Liwei, Chen Yunfu, Wang Jiahui, Ying Huiliang, Talking about Gao, Jin Shibin, Cao Liangzhi, Kong Fanyu, Wang Weijun. Small gasoline engine direct high - speed centrifugal pump Performance evaluation specification

1 Scope

This standard specifies the performance rating criteria, other requirements, test methods, inspection rules and performance rules for small gasoline engine direct-coupled high-speed centrifugal pumps. Performance level identification and so on. This standard applies to the rated power ≤ 5.89kW, the speed of 3600r/min and above the small gasoline engine direct high-speed centrifugal pump Referred to as the pump).

2 normative reference documents

The following documents are indispensable for the application of this document. For dated references, only the dated edition applies to this article Pieces. For undated references, the latest edition (including all modifications) applies to this document. GB/T 2828.1 Sampling inspection procedures Part 1. Batch inspection sampling plan for retrieval by quality limit (AQL) GB/T 2829 Periodic inspection count Sampling procedures and tables (for inspection of process stability) GB/T 3216 rotary power pump hydraulic performance acceptance test 1, 2 and 3 High - speed centrifugal pump for small gasoline engine

3 performance rating evaluation index

This standard determines the performance level of the pump by checking the specified flow rate of the pump, stipulating the head and pump efficiency. The performance rating of the pump is divided into 1, 2, 3 Three grades, one level indicates the highest pump performance. The evaluation index of each performance grade shall meet the requirements of Table 1. Table 1 Performance level Specifies the flow rate of the lift pump efficiency Grade 1 QG (1 5%) HG (1 3%) ηSP 3.0 Grade 2 QG (1 ± 5%) HG (1 ± 3%) ηSP 1.0 3 QG (1 ± 8%) HG (1 ± 5%) ηSP-Δη In the table, ηSP is the pump efficiency value specified in GB/T 24673 and the tolerance is not satisfied. The pump efficiency tolerance Δη shall comply with the provisions of GB/T 24673. QG, HG points Do not specify the required flow rate for the pump in GB/T 24673 and specify the head value and no tolerance. The specified head value HG of the pump is allowed to be in accordance with the provisions of GB/T 24673 Amendment.

4 other requirements

The pump type, other basic parameters and technical requirements shall comply with the provisions of GB/T 24673. ......
