GB/T 32788.2-2016: Test method for properties of prepreg -- Part 2: Determination for resin flow of prepreg
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 32788.2-2016	159	Add to Cart	3 days	Test method for properties of prepreg -- Part 2: Determination for resin flow of prepreg	Valid

Similar standards

GB/T 40388   GB/T 39491   GB/T 36262   GB/T 32788.4   GB/T 32788.5   GB/T 32788.3

Basic data

Standard ID: GB/T 32788.2-2016 (GB/T32788.2-2016)
Description (Translated English): Test method for properties of prepreg -- Part 2: Determination for resin flow of prepreg
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: Q23
Classification of International Standard: 83.120
Word Count Estimation: 8,876
Date of Issue: 2016-06-14
Date of Implementation: 2017-05-01
Quoted Standard: GB/T 1446; GB/T 32788.1; GB/T 32788.3
Adopted Standard: ISO 15034-1999, MOD
Regulation (derived from): National Standard Announcement No. 8 of 2016
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the principles, apparatus and equipment, samples, test conditions, test procedures, test results and test reports of the fluidity of prepreg resin. This standard applies to the carbon fiber, glass fiber, aramid fiber as a reinforcing material to thermosetting resin matrix for the determination of prepreg resin fluidity.

GB/T 32788.2-2016: Test method for properties of prepreg -- Part 2: Determination for resin flow of prepreg

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Test method for properties of prepreg. Part 2. Determination for resin flow of prepreg ICS 83.120 Q23 National Standards of People's Republic of China Test method for performance of prepregs Part 2. determination of resin fluidity Part 2. Determinationforresinflowofprepreg (ISO 15034..1999, Composites-Prepregs- Determinationofresinflow, MOD) 2016-06-14 release 2017-05-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China China National Standardization Management Committee released

Foreword

GB/T 32788 "Prepreg performance test method" is divided into six parts. Part 1. Determination of gel time; - Part 2. Determination of resin fluidity; Part 3. Determination of volatile matter content; - Part 4. Determination of tensile strength; - Part 5. Determination of resin content; Part 6. Determination of mass per unit area. This part is part 2 of GB/T 32788. This part is drafted in accordance with the rules given in GB/T 1.1-2009. This part uses the re-drafting method to modify ISO 15034..1999 "Determination of the fluidity of composite prepregs". This section has a greater structural adjustment compared to ISO 15034..1999, which is listed in Appendix A and ISO 15034..1999 Of the chapter number of the control list. The technical differences between this section and ISO 15034..1999 are as follows. This part of the scope of the expansion of the scope of use, with "thermosetting resin as the base of the prepreg resin fluidity determination"; --- replaced ISO 291..1997 with GB/T 1446, removed ISO 472..1999 and ISO 8604. 1988, increased GB/T 32788.3 Test method for the properties of prepregs - Part 3. Determination of volatile matter content; - the deletion of the terms "terms and definitions"; - a cutting template with a size of (150 ± 1) mm × (150 ± 1) mm has been added to cut the test material (see 4.1); - the "glazing glass cloth, type 181 or equivalent" is summarized as "rubber cloth" (see 4.4); - increase the sampling position "at least 50mm from the edge" to clear the sampling position (see 5.1); - Modification of the "state adjustment and test environment" requirements, in coordination with other parts of this standard (see Chapter 6); - summarize the section "Making the sample assembly process" (see 7.5); - the procedure for repeating the steps (at least 3 results) described in 8.1 to 8.8 for the remaining samples is removed from the test procedure; - the deletion of the "according to ISO 9872" requirement, this part has been specified in the "normative reference document" - Added "Calculate arithmetic mean, take 3 significant digits.", In coordination with other parts of this standard (see 8.3). This section makes the following editorial changes. - Change the standard name to "Prepreg performance test method Part 2. Determination of resin fluidity"; - Added Appendix A (informative) "This section is in contrast to the chapter numbering of ISO 15034..1999". This section is proposed by the China Building Materials Federation. This part of the National Fiber Reinforced Plastics Standardization Technical Committee (SAC/TC39) centralized. This part is responsible for the drafting unit. Harbin FRP Research Institute. This part participates in the drafting unit. AVIC Composite Material Co., Ltd., Hebei Haozheng Non-metallic Material Testing Service Co., Ltd., Lei Ke Germany (polymer) Tianjin Co., Ltd., Jiangsu Hengshen Co., Ltd., Qihe County, Xingda Composite Materials Co., Ltd. This part of the main drafters. Li Jinliang, Wang Baorui, Sun Yuanjun, Ren Kun, Ding Xinjing, Liu Dongxun, Zhang Rongqi, Yu Hao, Li Hongjiang, He Tao. Test method for performance of prepregs Part 2. determination of resin fluidity

1 Scope

This part of GB/T 32788 specifies the principle, instrument and equipment, sample, test conditions, test procedure, Test results and test reports. This part is suitable for the use of carbon fiber, glass fiber, aramid fiber as a reinforcing material, thermosetting resin-based prepreg resin flow Determination of the force.

2 normative reference documents

The following documents are indispensable for the application of this document. For dated references, only the dated edition applies to this article Pieces. For undated references, the latest edition (including all modifications) applies to this document. GB/T 1446 Fiber reinforced plastics - Test methods - General Test methods for performance of prepregs - Part 1. Determination of gel time GB/T Test methods for performance of prepregs - Part 3. Determination of volatiles content GB/T

3 principle

Cutting the sample from the prepreg sample into the intermediate composition of the sintered glass cloth and the insulating film, placing the sample assembly in the specified test The temperature and pressure under the plate press for curing, curing, part of the resin flow out of the sample. The quality of the samples before and after the test Ratio, that is, the mobility of the resin.

4 instruments and equipment

4.1 Cutting template. made of hard material such as steel or ceramic, specifications (100 ± 1) mm × (100 ± 1) mm, (150 ± 1) mm × (150 ± 1) mm each piece, the thickness of about 5mm. 4.2 Cutting Tools. Single-sided blade. 4.3 Analysis of balance. sense of 0.001g. 4.4 Glue glass cloth. 4.5 porous heat-resistant insulation film. such as. containing the appropriate pore structure of the tetrafluoroethylene film, resin can flow smoothly through the hole. 4.6 non-porous heat-resistant insulation film. such as. tetrafluoroethylene and hexafluoropropylene copolymer. 4.7 Flat press. the maximum temperature of.200 ℃, and can be 100mm × 100mm area to maintain the pressure of 600kPa.

5 samples

5.1 Using a cutting template and cutting tool, a sample of 100 mm x 100 mm was cut in the width of the prepreg, and a sufficient number And stack them together to obtain a sample of about 0.2 mm to 0.5 mm thick. If the width of the prepreg can not be cut enough in advance The impregnation sample (such as a narrowing of the prepreg) can be cut in the length of the prepreg, at least 50 mm from the edge. ......
