GB/T 32666.2-2016: High-grade and popular numerical control system of machine tool -- Part 2: Requirements and verification specifications for spindle drive device
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 32666.2-2016	1039	Add to Cart	8 days	High-grade and popular numerical control system of machine tool -- Part 2: Requirements and verification specifications for spindle drive device	Valid

Similar standards

GB/T 28615 GB/T 24343 GB/T 24344 GB/T 17421.1 GB/T 32667 GB/T 32666.1

Basic data

Standard ID: GB/T 32666.2-2016 (GB/T32666.2-2016)
Description (Translated English): High-grade and popular numerical control system of machine tool -- Part 2: Requirements and verification specifications for spindle drive device
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J50
Classification of International Standard: 25.040.20
Word Count Estimation: 52,532
Date of Issue: 2016-04-25
Date of Implementation: 2016-11-01
Quoted Standard: GB/T 191-2008; GB/T 2423.1-2008; GB/T 2423.2-2008; GB/T 2423.4-2008; GB/T 2423.5-1995; GB/T 2423.8-1995; GB/T 2423.10-2008; GB/T 2423.16-2008; GB/T 2423.17-2008; GB/T 2423.22-2012; GB/T 2828.1-2012; GB 4208-2008; GB/T 4942.1-2006; GB/T 5169.11-2006; GB/T 5169.16-2008
Regulation (derived from): National Standard Announcement No
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the technical requirements and test methods for the manufacture and acceptance of spindle drives of high-end and universal CNC machines. This standard applies to the spindle drive unit (hereinafter referred to as the spindle drive unit or product) of the high-grade and universal type machine tool numerical control system and the AC spindle servo drive unit (hereinafter referred to as the spindle drive unit) constituting the spindle drive unit, the AC spindle servomotor Spindle motor). Other similar drives may be referred to this standard.

GB/T 32666.2-2016: High-grade and popular numerical control system of machine tool -- Part 2: Requirements and verification specifications for spindle drive device

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
High-grade and popular numerical control system of machine tool.Part 2. Requirements and verification specifications for spindle drive device ICS 25.040.20 J50 National Standards of People's Republic of China High - grade and universal machine tool numerical control system Part 2. Requirements and acceptance specifications for spindle drives Part 2. Requirementsandverificationspecificationsforspindledrivedevice 2016-04-25 released 2016-11-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China China National Standardization Management Committee released Directory Preface III 1 Scope 1 2 normative reference document 1 3 Terms and definitions 2 4 working environment conditions 6 4.1 Climatic environmental conditions 6 4.2 Mechanical environmental conditions 11 4.3 Power Environmental Conditions 14 4.4 SPECIAL ENVIRONMENTAL CONDITIONS 16 5 functional and electrical performance 17 5.1 Spindle drive (unit) 17 5.2 Spindle motor 21 Design and Manufacture 6.1 mark (logo) 25 6.2 Appearance and structure 6.3 Component Quality 26 6.4 Operation and maintenance convenience 6.5 spindle motor basic shape and installation size 27 6.6 Radial runout of the spindle motor 6.7 Radial round run of the spindle motor flange on the motor axis 6.8 Spindle motor mounting with the end face of the motor axis of the end of the runout 29 6.9 Spindle motor outlet mode and lead wire 30 Safety and Electromagnetic Compatibility 7.1 Housing protection 30 7.2 Shock protection 31 7.3 protection link 31 7.4 Insulation resistance 32 7.5 withstand voltage test 33 7.6 Fire protection and flame retardancy of nonmetallic materials 35 7.7 Electromagnetic emission interference 35 7.8 Electrostatic Discharge Immunity Electrical fast transient burst immunity 7.10 Surge (impact) immunity 7.11 Voltage sags and short interruptions 7.12 radio frequency electromagnetic radiation immunity 40 7.13 Radio Frequency Field Sensing Conduction Disturbance Immunity 40 7.14 Immunity performance criterion 7.15 Noise 42 8 Reliability 42 9 Product accompanying file 42 9.1 Requirements 42 9.2 Test (Test) 43 10 packaging, storage and transportation 43 10.1 Packaging 43 10.2 Storage 43 Test conditions and inspection rules 11.1 Test conditions 44 11.2 Inspection rules 11.3 Inspection sequence 48 Quality assurance and customer service Reference 49

Foreword

GB/T 32666 "high-end and universal machine numerical control system" is divided into the following parts. - Part 1. Requirements and acceptance specifications for numerical control devices; - Part 2. Requirements and acceptance specifications for spindle drives; Part 3. Requirements and acceptance specifications for AC servo drives; This part is part 2 of GB/T 32666. This part is drafted in accordance with the rules given in GB/T 1.1-2009 This part is made by the China Machinery Industry Federation. This part of the National Machine Tool CNC System Standardization Technical Committee (SAC/TC367) centralized. This part of the drafting unit. Guangzhou CNC Equipment Co., Ltd., Wuhan Huazhong Numerical Control Co., Ltd., Wuhan Dengqi Electrical and Mechanical Technology Co., Ltd. Division, Dalian Guangyang Technology Group Co., Ltd., Beijing Kai En Di CNC technology limited liability company, Shenyang high precision CNC Technology Co., Ltd. This part of the main drafters. Zhang Yujie, Zhang Huafeng, Hu Xiao, Zhang Hangjun, Zhang Huanling, Feng Zhaobing, Xu Jianchun, Tao Yaodong, Yang Hongli, Wang Zhicheng. High - grade and universal machine tool numerical control system Part 2. Requirements and acceptance specifications for spindle drives

1 Scope

This part of GB/T 32666 specifies the technical requirements for the manufacture and acceptance of spindle drive devices for high-end and universal machine tool numerical control systems And test evaluation methods. This part is applicable to the spindle drive device (hereinafter referred to as spindle drive device or product) and configuration of high-grade and universal machine tool numerical control system Spindle drive device AC spindle servo drive unit (hereinafter referred to as the spindle drive unit), AC spindle servo motor (hereinafter referred to as the spindle Motor). Other similar drive devices can refer to this section. Note. high-end and universal machine tool CNC system spindle drive device AC spindle servo motor is divided into AC asynchronous spindle motor and AC synchronization master Shaft motor and so on. This section only specifies the spindle drive with AC asynchronous spindle motor, and the spindle with AC synchronous spindle motor The drive will be regulated by another standard.

2 normative reference documents

The following documents are indispensable for the application of this document. For dated references, only the dated edition applies to this article Pieces. For undated references, the latest edition (including all modifications) applies to this document. GB/T 191-2008 packaging and storage icon GB/T 2423.1-2008 Environmental testing for electric and electronic products - Part 2. Test methods - Test A. Low temperature GB/T 2423.2-2008 Environmental testing for electric and electronic products - Part 2. Test methods - Test B. High temperature GB/T 2423.4-2008 Environmental testing for electric and electronic products - Part 2. Test methods - Test Db. alternating damp heat (12 h 12h cycle) GB/T 2423.5-1995 Environmental testing for electric and electronic products - Part 2. Test methods - Test Ea and guidance. Impact GB/T 2423.8-1995 Environmental testing for electric and electronic products - Part 2. Test methods - Test Ed. Free fall GB/T 2423.10-2008 Environmental testing for electric and electronic products - Part 2. Test methods - Test Fc. Vibration (sinusoidal) GB/T 2423.16-2008 Environmental testing for electric and electronic products - Part 2. Test methods - Test J and Guideline. GB/T 2423.17-2008 Environmental testing for electric and electronic products - Part 2. Test methods Test Ka. Salt mist GB/T 2423.22-2012 Environmental testing for electric and electronic products - Part 2. Test methods - Test N. Temperature change GB/T 2828.1-2012 Count Sampling Inspection Procedures Part 1. Batch Inspection Sampling by Reception Quality Limit (AQL) plan GB 4208-2008 enclosure protection class (IP code) Protection class (IP code) classification of the overall structure of rotating electrical machines GB/T 4942.1-2006 GB/T 5169.11-2006 Fire hazard test for electric and electronic products - Part 11. Basic test method for glowing wire/hot wire GB/T 5169.11-2006 Test method for burnability of glowing wire of the product GB/T 5169.16-2008 Fire hazard testing for electric and electronic products - Part 16. Test flame 50W Horizontal and vertical flame experiment method Mechanical electrical safety machinery - Electrical equipment - Part 1. General technical requirements GB 5226.1-2008 GB/T 6113.101-2008 Radio disturbance and immunity measuring equipment and measuring methods - Part 1-1. Radio disturbance ......
