Marine colorized pipe identification
|
Click to Preview a similar PDF
Basic data
| Standard ID | GB/T 32082-2015 (GB/T32082-2015) |
| Description (Translated English) | Marine colorized pipe identification |
| Sector / Industry | National Standard (Recommended) |
| Classification of Chinese Standard | U27 |
| Classification of International Standard | 47.020.50 |
| Word Count Estimation | 8,849 |
| Date of Issue | 2015-10-09 |
| Date of Implementation | 2016-03-01 |
| Quoted Standard | GB/T 191; GB/T 2406.2-2009; GB/T 2408-2008; GB 3033.1; GB 3033.2; GB/T 3978-2008; GB 8624-2012 |
| Regulation (derived from) | National Standard Announcement 2015 No.31 |
| Issuing agency(ies) | General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China |
| Summary | This Standard specifies the color line ship identification (abbreviated identification) terms and definitions, classification and marking requirements, test methods, inspection rules, marking, packaging, transportation and storage. This Standard applies to the resin film (PETP), a flame retardant resin and import raw materials as the main anti-aging pigment identification flag design, manufacture and acceptance. |
Similar standards
GB/T 32078.1|GB/T 32082-2015: Marine colorized pipe identification
---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
(Ship pipeline color identification)
ICS 47.020.50
U27
National Standards of People's Republic of China
Ship piping color identification
Issued on. 2015-10-09
2016-03-01 implementation
Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China
Standardization Administration of China released
Foreword
This standard was drafted in accordance with GB/T 1.1-2009 given rules.
The standard proposed by China State Shipbuilding Corporation.
This standard by the National Standardization Technical Committee shipboard loading (SAC/TC129) centralized.
This standard was drafted. China Shipbuilding Technology and Economy Research Institute, Changzhou Wujin Jiangnan Safety Equipment Co., Ltd.
The main drafters of this standard. Gao Feng, Jiang Min, Yu Jianwei.
Ship piping color identification
1 Scope
This standard specifies the color line ship identification (abbreviated identification) terms and definitions, classifications and marks, requirements, test side
Method, inspection rules, marking, packaging, transportation and storage.
This standard applies to the resin film (PETP), a flame retardant resin and imported anti-aging pigment identification of the main raw material of the design, manufacture
Making and acceptance.
2 Normative references
The following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein
Member. For undated references, the latest edition (including any amendments) applies to this document.
GB/T 191 Packaging - Pictorial signs
GB/T 2406.2-2009 Plastics - Determination of burning behavior by oxygen index Part 2 Method. room temperature test
GB/T 2408-2008 Plastics - Determination of burning behavior of horizontal and vertical
GB 3033.1 Ships and marine technology - Identification colors for the content of piping systems - Part 1. Main colors and media
GB 3033.2 Ships and marine technology - Identification colors for the content of piping systems - Part 2. a different media and (or) function
Add color
GB/T 3978-2008 standard lighting and geometric conditions
GB 8624-2012 Classification for burning behavior of building materials and products
3 Terms and Definitions
The following terms and definitions apply to this document.
3.1
Main color maincolor
Used to represent a group of similar color to identify the major media.
3.2
Additional color secondarycolor
For a group of similar media to further clarify the distinction between the additional identification color.
4 Classification and Marking
4.1 Classification
Identification by object used in the following two categories.
a) Ⅰ type --- different primary colors, additional colors for the content of the flag is used to distinguish the type of media in the pipeline, the width is usually
90mm and 150mm two kinds;
b) Ⅱ type --- marked with an arrow pointing to the main content, to determine the direction of flow inside the pipeline medium, usually 80mm and width
160mm two kinds.
...
