GB/T 30167.2-2013 English PDF

US$94.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 30167.2-2013: Textile machinery -- Weaving machine temples -- Part 2: Full-width temples
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 30167.2-2013	94	Add to Cart	3 days	Textile machinery -- Weaving machine temples -- Part 2: Full-width temples	Valid

Similar standards

FZ/T 93048.1   FZ/T 93019   GB/T 18737.2   GB/T 38417   GB/T 30167.1

Basic data

Standard ID: GB/T 30167.2-2013 (GB/T30167.2-2013)
Description (Translated English): Textile machinery -- Weaving machine temples -- Part 2: Full-width temples
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: W94
Classification of International Standard: 59.120.30
Word Count Estimation: 5,536
Adopted Standard: ISO 8118-2-2006, IDT
Regulation (derived from): National Standards Bulletin No. 25 of 2013
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the loom with a full-size temple of terms and definitions, name, size and marking.

GB/T 30167.2-2013: Textile machinery -- Weaving machine temples -- Part 2: Full-width temples

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Textile machinery Weaving machine temples Part 2... Full-width temples ICS 59.120.30 W94 National Standards of People's Republic of China Textile machinery loom temple Part 2. full-size temple Part 2. Ful-widthtemples (ISO 8118-2.2006, IDT) Issued on. 2013-12-17 2014-10-15 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

GB/T 30167 "Loom textile machinery temple" is divided into the following two parts. --- Part 1. Needle-bearing temple; --- Part 2. full-size temple. This section GB/T Part of 230,167. This section drafted in accordance with GB/T 1.1-2009 given rules. This section uses the translation method identical with ISO 8118-2.2006 "Loom textile machinery temple - Part 2. full-size temple" (English Chinese Version). For ease of use, this part of ISO 8118-2.2006 made the following editorial changes. a) with the "GB/T 30167.2" instead of "ISO 8118-2"; b) Delete the ISO 8118-2.2006 Foreword; c) increase in size between 1 and its interpretation dash symbol "---" and add a semicolon after interpretation ";" last Interpretation After the increase in the period. "." This part is proposed by the China Textile Industry Association. This part of the National Textile machinery and accessories Textile Equipment Standardization Technical Committee Technical Committee (SAC/TC215/SC2) Centralized. This section is drafted. Shanghai Plum Needle-bearing Co., Ltd. Changzhou Eagle Needle-bearing, Lutai Textile Co., Ltd., Shaanxi Textile Equipment Institute. The main drafters of this section. Qiu Li Feng, Zhao Yusheng, Zhang Zhonghui, Cao Guodong, Sun Jian, Zhang overflow, Zhang Jianxiang, DU Li. Textile machinery loom temple Part 2. full-size temple

1 Scope

GB/T 30167 provisions of this part of the loom with the full-size temple of terms and definitions, name, size and marking.

2 Terms and definitions

The following terms and definitions apply to this document. 2.1 Full-size temple ful-widthtemple In the weaving process the fabric for distraction, bringing them closer to the reed's largest warp wide as possible and installed near the cloth fell position means. see picture 1.

3 Name

Figure 1 is a full-size temple components and their dimensions. basic size. d1 --- pole diameter; l1 --- full width temple length; l1-1 --- strut length. Explanation. 1 --- web support base; 2 --- web support cover; 3 --- struts; 4 --- side cover; 5 --- bolts. Note. See Table 1 Diameter strut. 1 full-size temple components and their size ......
