Textile machinery and accessories--Bars for drop wires for electrical warp stop motions ICS 59.120.30 W94 National Standards of People's Republic of China Warp beam for electronic warp stop device of textile machinery and accessories (ISO 13435..2011, MOD) 2019-12-31 release 2019-12-31 implementation State Administration of Market Supervision Published by the National Standardization Administration

Foreword

This standard was drafted in accordance with the rules given in GB/T 1.1-2009. This standard uses the re-drafting method to modify and adopt ISO 13435..2011 "E-stop device for textile machinery and accessories". There are technical differences between this standard and ISO 13435..2011.The clauses related to these differences have passed the margins on the outer side. The vertical single line (|) at the location is marked. The main technical differences are. --- In the table 1 before the size code b, h1 and h2, the size names were added as "total thickness", "total height" and "outer contact rod height", Add the code "l" after the dimension name "length" and mark it in Figures 1 and 2 --- Added the size specifications in Table 1 and modified the limit deviation of the total thickness b; --- Modified the title of Chapter 3, added numbers and titles as "3.1 classification" and "3.2 mark", and changed the column items a) ~ e) to paragraphs. Editorial amendments to this standard are as follows. --- Amended the table in Table 1 entitled "Main Dimensions of Stop Bars for Electronic Stop Devices". This standard is proposed by China Textile Industry Federation. This standard is under the jurisdiction of the National Technical Committee for Standardization of Textile Machinery and Accessories (SAC/TC215). This standard was drafted. Changshu Changxin Textile Equipment Co., Ltd., Guangdong Kangtes Weaving Equipment Co., Ltd., Lutai Textile Co., Ltd. Co., Ltd., Shaanxi Textile Equipment Research Institute, National Textile Machinery Product Quality Supervision and Inspection Center (Shanxi). The main drafters of this standard. Fu Xiaoyan, Chen Yusheng, Dai Xiaodi, Zhang Jianxiang, Wang Rui, Zhao Yusheng, Cao Zhendong, Zhang Shidan, Liu Liqiang, Du Meimei. Warp beam for electronic warp stop device of textile machinery and accessories

1 Scope

This standard specifies the type, main dimensions and deviations, classification and marking, material, and structure of the stop bar used for the electronic stop device of the loom. This standard applies to integrated internal contact stop rods (type E1) and split internal contact stop rods (type E2).

2 size

2.1 E1 type The structure of the integrated inner contact stop bar is shown in Figure 1. The main dimensions and the limit deviation of the total thickness b are shown in Table 1. Explanation. 1 --- inner contact rod; 2--insulating layer; 3--outer contact rod. Figure 1 E1 structure --- toothed 2.2 E2 type The split-type internal contact warp beam is used to control the left and right sides of the loom respectively.The structure is shown in Fig. 2. Table 1. Explanation. 1 --- inner contact rod; 2--insulating layer; 3--outer contact rod. Figure 2 E2 structure --- toothed ......
