GB/T 29816-2013: Valve positioner based on HART protocol general specification
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 29816-2013	629	Add to Cart	5 days	Valve positioner based on HART protocol general specification	Valid

Similar standards

GB/T 17213.18 GB/T 17213.16 GB/T 17213.4 GB/T 17213.9 GB/T 22137.2 GB/T 17213.14

Basic data

Standard ID: GB/T 29816-2013 (GB/T29816-2013)
Description (Translated English): Valve positioner based on HART protocol general specification
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: N16
Classification of International Standard: 25.040.40
Word Count Estimation: 27,210
Quoted Standard: GB/T 2900.56-2008; GB 3836.1; GB 3836.2; GB 3836.4; GB 3836.20; GB/T 17212-1998; GB/T 17626.1; GB/T 17626.2; GB/T 17626.3; GB/T 17626.4; GB/T 17626.5; GB/T 17626.6; GB/T 17626.8; GB/T 18268.1-2010; GB/T 18271.3-2000; GB/T 22137.1-2008; GB/T 22137.2-2008;
Regulation (derived from): National Standards Bulletin No. 22 of 2013
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies: Based on HART Protocol HART communications relating positioner terms and definitions, abbreviations, requirements and test methods. This standard applies: Based on HART Protocol valve positioner.

GB/T 29816-2013: Valve positioner based on HART protocol general specification

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Valve positioner based on HART protocol general specification ICS 25.040.40 N16 National Standards of People's Republic of China Based on HART Protocol positioner General technical conditions Issued on. 2013-11-12 2014-03-15 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Preface Ⅰ 1 Scope 1 2 Normative references 1 3 Terms, definitions and abbreviations 2 3.1 Terms and definitions 2 3.2 Abbreviations 2 Requirement 3 4 4.1 Working conditions 3 4.2 HART communication protocol 3 4.3 positioner family of devices Interoperability Specification 3 4.4 Electromagnetic Compatibility 21 4.5 Other amounts that affect the performance of 22 4.6 22 explosion-proof performance 5 Test methods 22 5.1 test environment condition 22 5.2 HART communications protocol test 22 5.3 positioner family of devices Interoperability Specification Test 23 5.4 compatibility test capacitor 23 5.5 Other tests related effects of influence quantities 23 5.6 Performance test explosion 23

Foreword

This standard was drafted in accordance with GB/T 1.1-2009 given rules. The standard proposed by China Machinery Industry Federation. This standard by the national industrial process measurement and control Standardization Technical Committee (SAC/TC124) centralized. This standard was drafted. Shenzhen Wan News Controls Co., Southwest University, Shanghai Automation Instrumentation Co., Ltd., Central-day instrument Co., Ltd., Shanghai ABB Engineering Co., Ltd., Siemens (China) Co., Ltd. Zhejiang Di yuan Instrument Co., Ltd., Xiamen Anton electricity Sub Ltd., Fujian on the Run Precision Instrument Co., Ltd., Beijing Rip three yuan Instrument Co., Ltd., Beijing Institute of Automation Technology, Chongqing Ai Victoria Instrument Co., Ltd., Sichuan-Chongqing valve Co., of Instrumentation Technology and Economy Institute, Shanghai Industrial Automation Instrumentation Institute. The main drafters of this standard. a Jixun, Liangyun Ping, He Ting Huang, Ni Min, Yang Bin, Shen Wei is willing, Wang Baobing, Doulian Wang, Sun Xiangdong, Hong Xiaoping, Zou Chong, Ge Jian, Li Zhenzhong, Zhao Lixing, Zhang Chuan Chao, Zhang Feng, Zhong Shenghui, Wang Chunxi, Li Minghua, Qian Qi, Zhu Peijun. Based on HART Protocol positioner General technical conditions

1 Scope

This standard specifies the protocol based on HART positioner terms and definitions relating to HART communication, abbreviations, requirements and tests method. This standard applies to HART-based positioner.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. GB/T 2900.56-2008 Electrotechnical terminology control technology GB 3836.1 explosive atmospheres - Part 1. General requirements for equipment GB 3836.2 explosive atmospheres - Part 2. the flameproof "d" protection equipment GB 3836.4 explosive atmospheres - Part 4. the intrinsically safe "i" protection equipment GB 3836.20 Explosive atmospheres - Part 20. Equipment protection level (EPL) for the Ga-class equipment GB/T 17212-1998 industrial process measurement and control - Terms and definitions GB/T 17626.1 Electromagnetic compatibility Testing and measurement techniques - Overview of immunity tests GB/T 17626.2 Electromagnetic compatibility Testing and measurement techniques - Electrostatic discharge immunity test GB/T 17626.3 electromagnetic compatibility test and measurement technology RFEMS test GB/T 17626.4 Electromagnetic compatibility Testing and measurement techniques - Electrical fast transient burst immunity test GB/T 17626.5 electromagnetic compatibility test and measurement technology surge (impact) immunity test GB/T 17626.6 Electromagnetic compatibility Testing and measurement techniques Immunity to conducted disturbances induced field GB/T 17626.8 Electromagnetic compatibility Testing and measurement techniques - Power frequency magnetic field immunity test Electrical equipment EMC requirements - Part GB/T 18268.1-2010 measurement, control and laboratory use 1. General requirements GB/T 18271.3-2000 Process measurement and control devices - General methods and procedures for evaluating performance - Part 3. effects of influence quantities Test GB/T 22137.1-2008 industrial process control systems positioner - Part 1. pneumatic positioner output performance assessment Setting Method GB/T 22137.2-2008 industrial process control systems positioner Part 2. pneumatic output of the smart valve positioner Can evaluation method IEC 61158-5-20.2010 Industrial communication networks - Fieldbus specifications - Part 5-20. Application layer service definition - Type 20 Basis (Industrialcommunicationnetworks-Fieldbusspecifications-Part 5-20. Applicationlayer servicedefinition-Type20elements) IEC 61158-6-20.2010 Industrial communication networks - Fieldbus specifications - Part 6-20. Application layer service definition - Type 20 Basis (Industrialcommunicationnetworks-Fieldbusspecifications-Part 6-20. Applicationlayerpro- tocolspecification-Type20elements) IEC 617841.2010 Industrial communication networks profiles - Part 1. Fieldbus profile (Industrialcommunication ......
