GB/T 29028-2012: SWZ large universal coupling with bearing box
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 29028-2012	439	Add to Cart	4 days	SWZ large universal coupling with bearing box	Valid

Similar standards

GB/T 5015 GB/T 5014 GB/T 30819 GB/T 43757 GB/T 39545.4 GB/T 29027

Basic data

Standard ID: GB/T 29028-2012 (GB/T29028-2012)
Description (Translated English): SWZ large universal coupling with bearing box
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J19
Classification of International Standard: 21.120.01
Word Count Estimation: 19,177
Quoted Standard: GB/T 191; GB/T 197; GB/T 1801; GB/T 1184; GB/T 3098.1; GB/T 4879; GB/T 6388; GB/T 7284; GB/T 11345; GB/T 13384; JB/T 5000.1; JB/T 5000.15
Regulation (derived from): National Standards Bulletin No. 41 of 2012
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the SWZ type large overall bearing cross shaft universal coupling (hereinafter referred to as universal coupling) of the type, the basic parameters and dimensions, technical requirements, inspection rules, marking, packaging and st

GB/T 29028-2012: SWZ large universal coupling with bearing box

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
SWZ large universal coupling with bearing box ICS 21.120.01 J19 National Standards of People's Republic of China SWZ type large overall bearing Cross shaft universal coupling Issued on. 2012-12-31 2013-10-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This standard was drafted in accordance with GB/T 1.1-2009 given rules. This standard by the National Standardization Technical Committee of the machine shaft and accessories (SAC/TC109) and focal points. This standard was drafted. China's second heavy machinery company, the machine Productivity Promotion Center, Ltd. Deyang Rieter basis. The main drafters of this standard. Tan Ren Wan, Ming Chui new Liuxue Guang Jiang spring, Diaoyong Jian, Deng Takami. SWZ type large overall bearing Cross shaft universal coupling

1 Scope

This standard specifies the type SWZ large overall bearing cross shaft universal coupling (hereinafter referred to as universal coupling) the type, basic Parameters and dimensions, technical requirements, inspection rules, marking, packaging and storage. This standard applies to join two different axes of the universal joint drive shafts. Its turning diameter of 600mm ~ 1200mm, Nominal torque is transmitted 1080kN · m ~ 9000kN · m, axis angle of 10 °.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. GB/T 191 Packaging - Pictorial signs GB/T 197 common thread tolerance (GPS) with limits and tolerances and fits select GB/T 1801 Geometrical product specifications GB/T 1184 shape and position tolerances without individual tolerance value GB/T 3098.1 Mechanical properties of fasteners Bolts, screws and studs GB/T 4879 rust-proof packaging GB/T 6388 transport package shipping mark GB/T 7284 wooden frame GB/T 11345 steel welds manual ultrasonic testing and classification of testing results GB/T 13384 mechanical and electrical products packaging General technical conditions JB/T 5000.1 heavy machinery - General requirements - Part 1. Product Inspection Part 15 JB/T 5000.15 Heavy mechanical general techniques. non-destructive testing of steel forgings 3 Types, basic parameters and dimensions Type 3.1 Universal coupling type divided into three kinds as shown in Table 1. Table 1 large cross shaft universal coupling type Type code name icon BF standard telescopic flange ......
