GB/T 28420-2012 PDF English

Price & Delivery

US$689.00 · In stock · Download in 9 seconds
GB/T 28420-2012: Electronic toll collection -- Data and technical specification of OBE-SAM
Delivery: 9 seconds. True-PDF full-copy in English & invoice will be downloaded + auto-delivered via email. See step-by-step procedure
Status: Valid
Std IDVersionUSDBuyDeliver [PDF] inTitle (Description)
GB/T 28420-2012English689 Add to Cart 5 days [Need to translate] Electronic toll collection -- Data and technical specification of OBE-SAM

Click to Preview a similar PDF

Basic data

Standard ID GB/T 28420-2012 (GB/T28420-2012)
Description (Translated English) Electronic toll collection -- Data and technical specification of OBE-SAM
Sector / Industry National Standard (Recommended)
Classification of Chinese Standard R07
Classification of International Standard 35.240.60
Word Count Estimation 30,340
Quoted Standard GB/T 28422
Regulation (derived from) National Standards Bulletin No. 13 of 2012
Issuing agency(ies) General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary This standard provides secure access to electronic toll collection module board equipment (OBE-SAM) the main functions and parameters required, file structure, file details, key description, key management, and application of the agreement reset message c

GB/T 28420-2012: Electronic toll collection -- Data and technical specification of OBE-SAM


---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS35.240.60 R07 National Standards of People's Republic of China ETC OBE-SAM and data format skills requirement Issued on. 2012-10-01 2012-06-29 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Table of Contents

Preface Ⅰ 1 Scope 1 2 Normative references 1 3 Terms, Definitions and Abbreviations 1 Main functions and parameters 4 OBE-SAM requirements 2 5 OBE-SAM file structure 2 6 OBE-SAM within 7 Keys Description 7 OBE-SAM Key Management 8 Conventions 8 OBE-SAM reset information 8 9 OBE-SAM application command set 8 References 26

Foreword

This standard rule according to GB/T 1.1-2009 given draft. This standard by the National Intelligent Transportation System Standardization Technical Committee (SAC/TC268) and focal points. This standard is mainly drafted by. Research Institute of Highway Ministry of Transport. The main drafters of this standard. Mei Xinming, Liu Hongwei, Wang Gang, Zhou Bin, Wang Yan. ETC OBE-SAM and data format skills requirement

1 Scope

This standard specifies the electronic toll Security Access Module board equipment (OBE-SAM) The main functions and parameters required file structure, culture Detailed description, description of the agreement and its application command key, key management, reset message set. This standard applies to electronic road toll system, the field of vehicle access control, urban road pricing can refer to use.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated edition applies to this article Member. For undated references, the latest edition (including any amendments) applies to this document. GB/T 28422 electronic toll key information coding Toll road network toll technical requirements (MOC 2007 Announcement No. 35) 3 Terms, definitions and abbreviations 3.1 Terms and Definitions The following terms and definitions apply to this document. 3.1.1 Vehicle equipment OBE-SAM Security Access Module Integrated circuit module comprising a central processing unit (CPU), and is responsible for access to vehicle units (an OBU) and roadside unit (the RSU) license, Message authentication and encryption protection, the security OBU documents and keys. 3.2 Acronyms The following abbreviations apply to this document. ADF. application definition file (ApplicationDefinitionFile) CLA. Command Category byte packets (ClassByteoftheCommandMessage) COS. chip operating system (ChipOperatingSystem) CRC. Cyclic Redundancy Check (CyclicRedundancyCheck) DDF. directory definition file (DirectoryDefinitionFile) DES. Data Encryption Standard (DataEncryptionStandard) EEPROM. electrically erasable programmable read-only memory (ElectricalyErasableProgrammableRead-onlyMemory) EF. basic documents (ElementaryFile) ETC. electronic (no parking) charge (ElectronicTolColection) FCI. file control information (FileControlInformation) FID. File ID (FileIdentifier) ...
