GB/T 24177-2009: Standard test methods for characterizing duplex grain sizes
Delivery: 9 seconds. True-PDF full-copy in English & invoice will be downloaded + auto-delivered via email. See step-by-step procedure
Status: Valid

Std ID	Version	USD	Buy	Deliver [PDF] in	Title (Description)
GB/T 24177-2009	English	434	Add to Cart	4 days [Need to translate]	Standard test methods for characterizing duplex grain sizes

GB/T 24177-2009: Standard test methods for characterizing duplex grain sizes

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Standard test methods for characterizing duplex grain sizes ICS 77.040.99 H24 National Standards of People's Republic of China Characterization and Determination of Double Grain Size 2009-06-25 release 2010-04-01 Implementation General Administration of Quality Supervision, Inspection and Quarantine of the People 's Republic of China China National Standardization Management Committee released

Foreword

This standard is equivalent to the use of ASTME1181-02 "standard method of characterization of double grain size" (English version). For ease of use, this standard makes the following editorial modifications to ASTME1181-02. a) deleted the preamble of ASTME1181-02; b) replace the ASTM standards with corresponding or similar national standards; c) the specific data in the double grain size report format using the data in Appendix A; d) According to GB/T 1.1-2000 requirements, adjust the original standard part of the chapter, the entry settings. The main changes compared to ASTME1181-02 are as follows. a) Deleted 1.2 of ASTME1181-02; b) the addition of 1.2 "This test method only as a recommended test method, the material acceptance test does not specify the scope of qualified"; c) the deletion of a reference to the ASTM Annex "Comparison map of the measured area fraction" (ASTM Annex No. ADJE1181) d) deleted the "keyword" section of ASTME1181-02; e) Added Appendix NA "Differences between this standard and ASTME1181-02 and its causes". Appendix A to this standard is a normative appendix, Appendix B and Appendix NA are informative appendices. This standard is proposed by China Iron and Steel Industry Association. This standard by the National Steel Standardization Technical Committee. The drafting of this standard. Baoshan Iron and Steel Co., Ltd., Metallurgical Industry Information Standards Institute, Northeast Special Steel Group limited liability the company. The main drafters of this standard. Xie Chongjin, Luan Yan, Zeng Wentao, Gu Yan, Sun Shiqiu, Liu Zhenmao.

Introduction

For products with grain size conforming to a single logarithmic normal distribution, the average grain size (using GB/T 6394) and The maximum grain size [using ASTME930-99 (2007)] test method, and this standard applies to the product grain size was other forms The evaluation of the grain size of the cloth. Due to idiomatic usage and well known, the term & quot; duplexgrainsize & quot; is used to express any other Grain size, however, the use of this term does not mean that there are only two grain size distribution. This standard is used to describe the characteristics of grain size different from a single logarithmic normal distribution and to describe the actual grain size with reasonable accuracy Degree distribution. Characterization and Determination of Double Grain Size

1 Scope

1.1 This standard specifies the method of determining the double grain size. This standard divides the double grain size into two categories of six categories and describes them separately The various types of features, to provide a corresponding representation of the method and report format. 1.2 This standard only as a recommended test method, the material acceptance test is not qualified to determine the scope of the provisions.

2 normative reference documents

The terms of the following documents are hereby incorporated by reference into this standard. Whichever is the date of the reference file, which is followed by all (Excluding corrigenda) or revisions do not apply to this standard, however, encourage the parties to reach an agreement under this standard Whether you can use the latest version of these files. For undated references, the latest edition applies to this standard. GB/T 6394 Determination of average grain size of metals (GB/T 6394-2002, ASTME112..1996, MOD) Test method for metallic microstructures GB/T Quantitative metallographic method for the determination of GB/T 15749 ASTME7 Metallography related terms ASTME930-99 (2007) Determination of maximum grain size level (ALA grain size) on metallographic detection surface

3 terms and definitions

ASTME7 and the following terms and definitions apply to this standard. 3.1 Alternating areas with large grain size differences, which extend along the processing direction. 3.2 Equivalent to the average of the grain size distribution. 3.3 Some of the isolated coarse grains are organized by the finer grains of the grain. 3.4 A non-random change that occurs in a certain determinable pattern that may be related to the shape of the test sample or product. Classification and Characteristics of Double Grain Size The double grain size is divided into two categories. random double grain size and topological double grain size. Each category is divided into three types. Contains two or more grain sizes that are significantly different in size and are distributed in random variations. Its distribution status. ALA state, wide level difference State and bimodal state. The average grain size difference between the isolated coarse grains and the matrix grains is not less than 3, and the isolated grains The percentage of the area is no more than 5%. If the percentage of its area is greater than 5%, then the bimodal state. ...
