GB/T 21547.4-2008 English PDF

US$214.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 21547.4-2008: VMEbus extensions for instrumentation -- Part 4: TCP/IP-IEEE488.2 instrument interface specification
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 21547.4-2008	214	Add to Cart	3 days	VMEbus extensions for instrumentation -- Part 4: TCP/IP-IEEE488.2 instrument interface specification	Valid

Similar standards

GB 4793   GB/T 15284   GB/T 17215.321   GB/T 18216.12   GB/T 21547.3   GB/T 21547.1

Basic data

Standard ID: GB/T 21547.4-2008 (GB/T21547.4-2008)
Description (Translated English): VMEbus extensions for instrumentation -- Part 4: TCP/IP-IEEE488.2 instrument interface specification
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: N20
Classification of International Standard: 17.220
Word Count Estimation: 11,165
Date of Issue: 2008-06-30
Date of Implementation: 2009-01-01
Adopted Standard: VXI-11.3-1995, IDT
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies a TCP/IP-IEEE488. 2 interface devices. The only direct reference to the specification of the network is to support the Internet Protocol Suite network technology defined in this specification can be applied on other networks. OSI protocol standards such as support networks, but this article does not address the underlying transformations. This specification using the Internet Protocol Suite Upper Open Network Computing (ONC) remote procedure call (RPC). TCP/IP-IEEE488. 2 instrument interface can also support other network protocols.

GB/T 21547.4-2008: VMEbus extensions for instrumentation -- Part 4: TCP/IP-IEEE488.2 instrument interface specification

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
VMEbus extensions for intrumentation Part 4. TCP/IP-IEEE488.2 instrument interface specification ICS 17.220 N20 National Standards of People's Republic of China Vp ME expansion bus of the instrument Part 4. TCP/IP-IEEE488.2 Instrument Interface Specification (VXI-11.3.1995, Rev1.0, IDT) Posted 2008-06-30 2009-01-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

GB/T 21547 "VME bus extension instrument" is divided into the following parts. --- Part 1. TCP/IP Instrument Protocol Specification --- Part 2. TCP/IP-VXI bus interface specification --- Part 3. TCP/IP-IEEE488.1 Interface Specification --- Part 4. TCP/IP-IEEE488.2 instrument interface specification This section GB/T Part of 421,547. Structure and technical content and VXI-11.3 this section.1995, Rev1.0 consistent, just modify the following editorial. --- Increasing the standard name "Section 4"; --- The section numbers A, B, C to 2,3; --- Acronyms given comments. This part is proposed by China Machinery Industry Federation. This part of the measurement and control of Standardization Technical Committee of the Fourth Technical Committee under the jurisdiction of the national industrial processes. This section is drafted. Harbin Polytechnic University, Harbin Institute of Electrical Instrument. The main drafters of this section. Luo Zhongming, the name of Sun Song, Cao Wei, Malone, Ma Huaijian, Yuan Hui Chuang. This section first release. Extended Vp ME1) bus to the instrument Part 4. TCP/IP2) -IEEE488.2 Instrument Interface Specification

1 Introduction

Test and measurement instruments will be connected to the needs of industry in the growing computer network. This connection requires either a local area network, It can also be a WAN. This specification is part of VXI3) bus series specifications, it shows how the instrument is directly connected to industrial standard Online. Communication and programming paradigms support this specification with IEEE488.2 devices support technology is very similar in nature. Described in this specification ASCII protocol allows messages via TCP/IP network passed between controllers and devices. Readers should network, the Internet protocol suite, ONC RPC IEEE488.2 and other aspects of knowledge. 1.1 Scope This specification is part of the series of VXI bus specification and defines a TCP/IP-IEEE488.2 interface devices. 1) VME. VERSA-bus-ModularEuropean 2) TCP/IP. TransmissionControlProtocol/InternetProtocol 3) VXI. VME-busExtensionforInstrumentation The only direct reference network of the present specification is the support network of the Internet protocol suite, defined in this specification techniques can be on another network use. Such as support for OSI standard network protocol, but this article does not address the relevant conversion. The upper specification using open Internet Protocol Suite Network Computing (ONC) remote procedure call (RPC). TCP/IP-IEEE488.2 instrument interface can also support other network protocols. 1.2 Text Structure The text is divided into two parts. Part I. Introduction, the purpose is to make the reader familiar with the intent and scope of this article; The second part. TCP/IP-IEEE488.2 instrument interface defined TCP/IP-IEEE488.2 instrument interface operation, including the GB/T 21547.1-2008 defined transformations between the internal network processing and equipment. Objective 1.3 specification In addition to the purpose of GB/T 21547.1-2008 in the present specification has the following purposes. 1) the definition of TCP/IP-IEEE488.2 instrument interface operation. 2) to define transaction processing from the network to transform the internal operation of the device. 1.4 Terms and Definitions This section with the GB/T 21547.1-2008 same terms and definitions As in other VXI bus specification, the following terms are used to distinguish the contents of each paragraph, these definitions and those Same IEEE1155-1992 defined. 1.4.1 The rule is to ensure compatibility within the system and the various cards that should be followed. Rules with "should" (SHALL) and "should not" (SHALLNOT) represented. These words only for the stated rules, not for other purposes. ......
