GB/T 21420-2008: General requirements for light-trigged thyristors for HVDC transmission
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 21420-2008	229	Add to Cart	3 days	General requirements for light-trigged thyristors for HVDC transmission	Valid

Similar standards

GB/T 37404 GB/T 31487.3 GB/T 3859.1 GB/T 30425 GB/T 30843.2 GB/T 30843.1

Basic data

Standard ID: GB/T 21420-2008 (GB/T21420-2008)
Description (Translated English): General requirements for light-trigged thyristors for HVDC transmission
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: K46
Classification of International Standard: 31.080.20
Word Count Estimation: 10,139
Date of Issue: 2008-01-22
Date of Implementation: 2008-09-01
Quoted Standard: GB/T 4937-1995; GB/T 15291-1994
Regulation (derived from): Announcement of Newly Approved National Standards No. 2, 2008 (No. 115 overall)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the HVDC light -controlled thyristor type, size, rating, features, inspection rules, signs and orders and other technical requirements. This standard applies to devices within the integrated BOD HVDC light -controlled thyristor series.

GB/T 21420-2008: General requirements for light-trigged thyristors for HVDC transmission

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
General requirements for light-trigged thyristors for HVDC transmission ICS 31.080.20 K46 National Standards of People's Republic of China HVDC light-controlled thyristor general requirements Posted 2008-01-22 2008-09-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This standard reference GB/T 13151-2005 "Semiconductor devices Discrete devices Part 6. Thyristors Section Three large current At 100A, ambient and case - rated reverse blocking triode thyristor Blank detail specification "(IEC 60747-6-3.1993, IDT). Appendix A of this standard is a normative appendix. The standard proposed by China Electrical Equipment Industrial Association. This standard by the National Standardization Technical Committee on Power Electronics. This standard drafting of the main unit. Xi'an Power Electronic Technology Research Institute, Xi'an Electric Power Rectifier Co., Ltd., Beijing Power Machinery Industry Engineering Technology Research Institute of Economy, China Electric Power Research Institute, Xi'an High Voltage Apparatus Research Institute, Southern Power Grid Technology Research Center, Beijing Network Alliance DC Transmission Engineering Technology Co., Ltd. The main drafters of this standard. red Wei, Lu Jianqiu, Guo Liping, Duque, Tian Fang, Meng Qingdong, Gou Ruifeng, Li Xiaolin, Yu Tao PROCEEDINGS White Asia. This standard is the first release.

Introduction

HVDC in China's power grid construction, power transmission for long distance and large-area networking has a very broad prospects for development, as is currently the In order to solve the high-voltage, large-capacity, long-distance power transmission and important means of asynchronous networking. HVDC transmission project is based on our actual needs and high pressure DC transmission technology development trends carried out. Projects in the introduction of technology digestion and absorption of domestic HVDC project construction experience and autonomous equipment Developed based on research to develop national standards for HVDC transmission system equipment. Including basic standards, master control and protection equipment standards Equipment standards. Projects have been completed or are ongoing to develop a total of 19 national standards. (1) GB /Z20996.1-2007 "performance HVDC system in the first part of the steady-state performance" (IEC 60919-1.1991, IDT) (2) GB /Z20996.2-2007 "performance HVDC system fault and the second portion of the operation" (IEC 60919-2. 1991, IDT) (3) GB /Z20996.3-2007 "Performance of HVDC systems - Part III dynamic performance" (IEC 60919-3.1991, IDT) (4) "HVDC converter station insulation coordination procedures" (has been approved) (5) GB/T 20989-2007 "HVDC converter station losses OK" (6) GB/T 18494.2-2007 "Transformers for the second part of HVDC converter transformers" (IEC 61378-2.2001, MOD) (7) GB/T 20838-2007 "oil - immersed HVDC converter transformer technical parameters and requirements" (8) GB/T 20836-2007 "HVDC oil - immersed smoothing reactors" (9) GB/T 20837-2007 "HVDC oil - immersed smoothing reactors and technical requirements." (10) "HVDC converter station gapless metal oxide surge arresters Guidelines" (it has been approved) (11) GB/T 20994-2007 "HVDC and AC filter capacitors in parallel with capacitor" (12) GB/T 20993-2007 "HVDC DC filter capacitor" (13) GB/T 20992-2007 "General requirements for HVDC thyristor with ordinary" (14) GB/T 20995-2007 "Power Electronics stationary transmission and distribution system reactive power compensation device thyristor valve test" (IEC 61954.2003, MOD) (15) "HVDC system control and protection equipment" (has been approved) (16) "General requirements for HVDC light control thyristor" (has been approved) (17) "HVDC bushing technical performance and test methods" (has been approved) (18) "HVDC converter station audible noise" (under development) (19) "HVDC system design and equipment Complete Guide" (under development) HVDC light-controlled thyristor general requirements

1 Scope

This standard specifies the type, size, rating, characteristics, inspection rules HVDC light control thyristor, signs and orders, etc. skills requirement. This standard applies to devices integrated BOD HVDC light thyristor series.

2 Normative references

The following documents contain provisions which, through reference in this standard and become the standard terms. For dated references, subsequent Amendments (not including errata content) or revisions do not apply to this standard, however, encourage the parties to the agreement are based on research Whether the latest versions of these documents. For undated reference documents, the latest versions apply to this standard. GB/T 4937-1995 Semiconductor devices - Mechanical and climatic environmental testing (idt IEC 60749. 1984) GB/T 15291-1994 thyristor semiconductor devices - Part 6 (eqv IEC 60747-6. 1984)

3 models and sizes

3.1 Model Composition and meaning of each part of the model shown in Figure 1. KL It represents the optical thyristor The average on-state current value (unit. A) Blocking voltage of the series (reverse blocking voltage repeat 1/100) Level characteristic parameters and (or) the important parameters (if any) Specifications No. (if any) Figure 1 Model constitution 3.2 Dimensions Figure 2 size A, Dmax, D1 and D2 shall comply with the requirements and provisions of the order contract given model. Figure 2 Dimensions

4 RATINGS AND CHARACTERISTICS

Rating 4.1 Rating (limits) should be consistent with Table 1. ......
