GB/T 19212.11-2020 English PDFUS$339.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email. GB/T 19212.11-2020: Safety of transformers, reactors, power supply units and combinations thereof - Part 11: Particular requirements and tests for separating transformers with high insulation level and separating transformers with output voltages exceeding 1 000 V Status: Valid
Basic dataStandard ID: GB/T 19212.11-2020 (GB/T19212.11-2020)Description (Translated English): Safety of transformers, reactors, power supply units and combinations thereof - Part 11: Particular requirements and tests for separating transformers with high insulation level and separating transformers with output voltages exceeding 1 000 V Sector / Industry: National Standard (Recommended) Classification of Chinese Standard: K41 Classification of International Standard: 29.180 Word Count Estimation: 18,158 Date of Issue: 2020-12-14 Date of Implementation: 2021-07-01 Quoted Standard: GB/T 19212.1-2016; GB/T 19212.17; IEC 60417-DB Adopted Standard: IEC 61558-2-10-2014, MOD Regulation (derived from): National Standard Announcement No. 28 of 2020 Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration Summary: This standard specifies the safety requirements for separation transformers with high insulation levels and separation transformers with an output voltage exceeding 1000 V. Transformers with electronic circuits are also included in this standard. Unless otherwise specified, the following "transformers" include separation transformers with high insulation levels and separation transformers with output voltages exceeding 1,000 V AC or 1,500 V DC. This standard applies to stationary or mobile, single-phase or multi-phase, air cooling (natural cooling or forced cooling), independent or supporting dry-type transformers. The winding can be encapsulated or non-encapsulated. This standard applies to transformers and power supply devices (linear) with an internal operating frequency of not more than 500 Hz. GB/T 19212.11-2020: Safety of transformers, reactors, power supply units and combinations thereof - Part 11: Particular requirements and tests for separating transformers with high insulation level and separating transformers with output voltages exceeding 1 000 V---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order. (Safety of transformers, reactors, power supply units and their combinations:Part 11: Special requirements and tests for separating transformers with high insulation level and separating transformers with output voltages exceeding 1,000 V) ICS 29:180 K41 National Standards of People's Republic of China Safety of transformers, reactors, power supply devices and their combinations Part 11: High insulation level separation transformer and Separation transformer with output voltage exceeding 1000V Special requirements and tests exceeding1000V (IEC 61558-2-10:2014, Safetyoftransformers, reactors, powersupplyunits andcombinationsthereof-Part 2-10: Particularrequirementsandtestsfor separatingtransformerswithhighinsulationlevelandseparatingtransformers withoutputvoltagesexceeding1000V,MOD) Released on 2020-12-14 Implemented on 2021-07-01 State Administration for Market Regulation Issued by the National Standardization Management Committee Table of contentsPreface Ⅲ Introduction Ⅴ 1 Scope 1 2 Normative references 2 3 Terms and definitions 2 4 General requirements 2 5 General description of the test 3 6 Rating 3 7 Category 3 8 Signs and other information 3 9 Electric shock protection 5 10 Change of input voltage setting value 5 11 Load output voltage and output current 5 12 No-load output voltage 5 13 Short circuit voltage 6 14 Fever 6 15 Short circuit and overload protection 6 16 Mechanical strength 6 17 Protection against harmful entry of dust, solid foreign objects and moisture 6 18 Insulation resistance, dielectric strength and leakage current 6 19 Structure 7 20 Components 8 21 Internal wiring 8 22 Power connection and other external flexible cables or cords 8 23 External wire terminal 8 24 Protective earthing device 8 25 Screws and connections 8 26 Creepage distance, electrical clearance and penetration distance 8 27 Heat resistance, flame resistance and tracking resistance 10 28 Rust prevention 10 Appendix 11 Reference 12 Table 101 Output voltage difference 6 Table 102 Dielectric strength test voltage value and its voltage applied part 7 Table 103 Uniform electric field or non-uniform electric field clearance 9 Table 104 Creepage distance of basic insulation or supplementary insulation for material group Ⅲa, Ⅱ and Ⅰ (CTI >175) 9ForewordGB/T 19212 "Safety of Transformers, Reactors, Power Supply Devices and Their Combinations" 1) consists of the following parts: 1) In this series of standards, some parts are under the heading "Safety of power transformers, power supplies, reactors and similar products", and some parts are Under the heading of 1100V and below the safety of transformers, reactors, power supply units and similar products, some parts are Under the heading of "Safety of Source Device and Its Combination", the title of this series of standards may be revised in the future: ---Part 1: General requirements and tests; ---Part 2: Special requirements and tests for general purpose separating transformers and power supplies with built-in separating transformers; ---Part 3: Special requirements and tests for control transformers and power supplies with built-in control transformers; ---Part 4: Special requirements and tests for ignition transformers for gas and oil burners; ---Part 5: Special requirements and tests for isolation transformers and power supply devices with built-in isolation transformers; ---Part 6: Special requirements and tests for transformers for shavers, power supply devices for shavers, and power supply devices for shavers; ---Part 7: Special requirements and tests for safety isolating transformers and power supply devices with built-in safety isolating transformers; ---Part 8: Special requirements and tests for transformers and power supplies for toys; ---Part 9: Special requirements and tests for transformers and power supply devices for electric bells and electric clocks; ---Part 10: Special requirements and tests for transformers and power supply devices for class III portable tungsten filament lamps; ---Part 11: Special requirements and tests for separating transformers with high insulation level and separating transformers with an output voltage exceeding 1000V; ---Part 13: Special requirements and tests for constant voltage transformers and power supply devices; ---Part 14: Special requirements and tests for autotransformers and power supply devices with built-in autotransformers; --- Part 15: Special requirements and tests for voltage regulators and power supply devices with built-in voltage regulators; ---Part 16: Special requirements and tests for isolation transformers for power supply in medical places; ---Part 17: Special requirements and tests for switching power supply devices and transformers for switching power supply devices; ---Part 20: Special requirements for interference attenuation transformers; ---Part 21: Special requirements and tests for small reactors; ---Part 24: Special requirements for transformers used on construction sites; --- Part 27: Special requirements and tests for transformers and power supply devices for energy saving and other purposes: This part is Part 11 of GB/T 19212: This section was drafted in accordance with the rules given in GB/T 1:1-2009: This part uses the redrafting law to amend and adopt IEC 61558-2-10:2014 "Safety of Transformers, Reactors, Power Supply Units and Their Combinations" Full Part 2-10: Special requirements and tests for separating transformers with high insulation levels and separating transformers with output voltages exceeding 1000V: The technical differences between this part and IEC 61558-2-10:2014 and the reasons are as follows: ---Regarding normative reference documents, this section has made adjustments with technical differences to adapt to my country's technical conditions or facilitate the use of The conditions of application and adjustment are collectively reflected in Chapter 2 "Normative Reference Documents": The specific adjustments are as follows: ● The technical differences between GB/T 19212:1-2016 and IEC 61558-1:2009 in Chapter 2 are retained to facilitate the GB/T 19212:1-2016 supporting use; ● Replace IEC 61558- with GB/T 19212:1-2016 and GB/T 19212:17 which are modified and adopted international standards: 1:2005 (including its No: 1 amendment) and IEC 61558-2-16; ● Added reference to IEC 60417-DB (see Chapter 8): --- Amend "creepage distance, electrical clearance and penetration distance" in the original text 26:1 to "electrical clearance"; change the original text 26:1:101 The "creepage distance, electrical clearance and penetration distance" in "Creepage distance" is modified to "creepage distance" to meet the actual situation in my country: This section also made the following editorial changes: ---In order to meet the uniform numbering of the GB/T 19212 series of standards, the standard name is changed to "transformers, reactors, power supply devices and their Combined safety Part 11: Characteristics of high-insulation level separation transformers and separation transformers with an output voltage exceeding 1000V Special requirements and tests"; ---Introduction is added in Chapter 2 and Chapter 3; --- Amend Table 102 in Note 2 of 26:1 to Table 103; --- Delete the sentence below Note 2 and Note 7 in the original text 26:1, because it is consistent with the content in GB/T 19212:1-2016 repeat; ---Adjust the original table 103 to 26:1; ---Move the "altitude not exceeding:2000m" in Note 3 of the original table 104 to the header, and delete the contents of Note 3 and Note 2; ---Change the IEC 60076-11 and IEC 61050 in the references to the corresponding national standards: This part was proposed by China Electrical Equipment Industry Association: This part is organized by the National Standardization Technical Committee (SAC/TC418) for small power transformers, reactors, power supply devices and similar products Focus: Drafting organizations of this section: Shenyang Transformer Research Institute Co:, Ltd:, Beijing Tairuite Testing Technology Service Co:, Ltd:, Tongling Sanjia Transformer Technology Co:, Ltd:, Shanghai Institute of Quality Supervision and Inspection Technology, Zhongshan Baolijin Electronics Co:, Ltd:, Industrial and Saibao Quality and Safety Testing Center of the Fifth Institute of Electronics, Ministry of Information Technology, Shanghai Entry-Exit Inspection and Quarantine Bureau Mechanical and Electrical Products Testing Technology Center, Tianjin Optoelectronics Huigao Electronics Co:, Ltd:, Wenzhou Chint Power Electric Co:, Ltd:, Mingzhu Electric Co:, Ltd: The main drafters of this section: Zhang Xianzhong, Zhang Yafang, Li Xinman, Yu Yimin, Lin Junrong, Sun Jianlong, Liang Hui, Li Dongbo, Li Hui, Mao Qiwu, Li Sijia:IntroductionThis part is formulated on the basis of GB/T 19212:1-2016, and this part needs to be used in conjunction with GB/T 19212:1-2016: This part is to supplement and modify the corresponding chapters and articles of GB/T 19212:1-2016 The content is transformed into the content of this section: This section is numbered starting from 101 for the newly added content of GB/T 19212:1-2016: Safety of transformers, reactors, power supply devices and their combinations Part 11: High insulation level separation transformer and Separation transformer with output voltage exceeding 1000V Special requirements and tests1 ScopeThis chapter of GB/T 19212:1-2016 is replaced by the following: This part of GB/T 19212 specifies the safety of separation transformers with high insulation level and separation transformers with an output voltage exceeding 1000V: All requirements: Transformers with electronic circuits are also included in this section: Note 1: Safety requirements include electrical, temperature and mechanical aspects: Unless otherwise specified, the following "transformers" include high insulation level separation transformers and output voltages exceeding AC 1000V or DC 1500V separation transformer: This section applies to standing or mobile, single-phase or multi-phase, air cooling (natural cooling or forced cooling), independent or supporting dry transformer: The winding can be encapsulated or non-encapsulated: This section applies to transformers and power supply devices (linear) whose internal operating frequency does not exceed 500Hz: When this part is used in combination with GB/T 19212:17 switching power supply device, it is also applicable to the internal working frequency of more than 500Hz: Power supply unit: When the requirements of the two standards are inconsistent, the stricter standard is preferred: This section applies to the rated power supply voltage not exceeding 1000V AC, the rated power supply frequency and internal working frequency not exceeding 500Hz: This section applies to the rated output not exceeding: ---For single-phase transformer, it is 25kVA; ---For multi-phase transformers, it is 40kVA: If the purchaser and the manufacturer agree otherwise, this section also applies to transformers that do not limit the rated output: This section applies to no-load output voltage or rated output voltage: ---For high insulation level separation transformer, no more than AC 1000V or DC 1500V; ---For the separation transformer with output voltage exceeding 1000V, it exceeds AC 1000V or DC 1500V and does not exceed AC or DC 15000V: This section does not apply to: --- Transformer included in GB/T 1094:11; ---GB/T 19149 neon lamp transformer; ---IEC 61347-2-10 related or supporting power supply and converter: This section does not apply to external circuits and their components that are scheduled to be connected to the input terminals and output terminals of the transformer: When installation regulations or final product standards do not require double insulation or reinforced insulation between circuits, the changes included in this section can be used: Depressor: Note 2: Generally, the transformer is scheduled to be used in conjunction with the equipment to provide a voltage different from the power supply voltage to meet the functional requirements of the equipment: Its electric shock protection can It can be provided (or realized) through other parts of the supporting equipment, such as the housing: Parts of the output circuit can be connected to the input circuit or protection Ground: This section applies to transformers supporting special equipment, and its scope is determined by relevant standards: Note 3: Note the following: ......Tips & Frequently Asked Questions:Question 1: How long will the true-PDF of GB/T 19212.11-2020_English be delivered?Answer: Upon your order, we will start to translate GB/T 19212.11-2020_English as soon as possible, and keep you informed of the progress. The lead time is typically 2 ~ 4 working days. The lengthier the document the longer the lead time.Question 2: Can I share the purchased PDF of GB/T 19212.11-2020_English with my colleagues?Answer: Yes. The purchased PDF of GB/T 19212.11-2020_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.Question 3: Does the price include tax/VAT?Answer: Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries) -- See Avoidance of Double Taxation Agreements (DTAs): List of DTAs signed between Singapore and 100+ countriesQuestion 4: Do you accept my currency other than USD?Answer: Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay. |
