GB/T 18779.4-2020: Geometrical product specifications (GPS)-Inspection by measurement of workpieces and measuring equipment - Part 4: Background on functional limits and specification limits in decision rules
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 18779.4-2020	319	Add to Cart	4 days	Geometrical product specifications (GPS)-Inspection by measurement of workpieces and measuring equipment - Part 4: Background on functional limits and specification limits in decision rules	Valid

Similar standards

JJF 1951   JJF 1561   JJF 1406   GB/T 18779.3   GB/T 18779.2   GB/T 18779.1

Basic data

Standard ID: GB/T 18779.4-2020 (GB/T18779.4-2020)
Description (Translated English): Geometrical product specifications (GPS)-Inspection by measurement of workpieces and measuring equipment - Part 4: Background on functional limits and specification limits in decision rules
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: A52
Classification of International Standard: 17.040.01
Word Count Estimation: 17,175
Date of Issue: 2020-12-14
Date of Implementation: 2021-07-01
Quoted Standard: GB/T 18779.1
Adopted Standard: ISO/TS 14253-4-2010, MOD
Regulation (derived from): National Standard Announcement No. 28 of 2020
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration
Summary: This standard specifies the main assumptions under the theoretical ideal judgment rule in GB/T 18779.1. It specifies the reasons why these rules should be the default rules and the factors to be considered before applying different judgment rules. This standard applies to all specifications involved in the GPS general standard (see GB/T 20308), that is, the standard compiled by SAC/TC 240, including workpiece specifications (usually given in the form of specification limits) and measurement equipment specifications (usually in maximum The allowable error form is given)

GB/T 18779.4-2020: Geometrical product specifications (GPS)-Inspection by measurement of workpieces and measuring equipment - Part 4: Background on functional limits and specification limits in decision rules

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
(Product Geometric Technical Specification (GPS) Measurement and Inspection of Workpieces and Measuring Equipment Part 4: The basis for determining the functional limits and specification limits in the rules) ICS 17:040:01 A52 National Standards of People's Republic of China Product Geometric Technical Specification (GPS) Measurement inspection of workpiece and measuring equipment Part 4: Functional Limits in Judgment Rules The basis of the norm (ISO /T S14253-4:2010,MOD) Released on 2020-12-14 Implemented on 2021-07-01 State Administration for Market Regulation Issued by the National Standardization Management Committee

Table of contents

Preface Ⅲ Introduction Ⅳ 1 Scope 1 2 Normative references 1 3 Terms and definitions 1 4 The relationship between functional limits and specification limits 2 5 Determination of functional limits 7 6 Specification limits and methods for determining specification limits based on functional limits 8 7 Assuming the shape of the functional degradation curve 9 8 Determine the specification limit 10 9 Other judgment rules 10 Appendix A (informative appendix) and GPS matrix model relationship 12 Reference 13

Foreword

GB/T 18779 "Geometric Technical Specifications for Products (GPS) Measurement Inspection of Workpieces and Measuring Equipment" is divided into 6 parts: ---Part 1: The rules for determining qualified or unqualified inspections according to specifications; ---Part 2: Guidelines for Evaluation of Uncertainty of GPS Measurement in Measuring Equipment Calibration and Product Inspection; ---Part 3: Guidelines on reaching a consensus on the expression of measurement uncertainty; ---Part 4: The basis for determining the functional limits and specification limits in the rules; ---Part 5: Uncertainty of inspection of indicating measuring instrument; ---Part 6: General rules for acceptance/rejection of instruments and workpieces: This part is Part 4 of GB/T 18779: This section was drafted in accordance with the rules given in GB/T 1:1-2009: This part uses the redrafting method to modify and adopt ISO /T S14253-4:2010 "Geometrical Technical Specifications for Products (GPS) Workpieces and Measurements" Measurement and inspection of equipment: Part 4: The basis for determining the functional limits and specification limits in the rules:" The technical differences between this part and ISO /T S14253-4:2010 and the reasons are as follows: ---Regarding normative reference documents, this section has made adjustments with technical differences to adapt to my country's technical conditions and adjustments: The situation is collectively reflected in Chapter 2 "Normative Reference Documents", and the specific adjustments are as follows: ● Replace ISO 14253-1 (see Chapter 3, 4:2, 4:3, 9:1) with GB/T 18779:1 equivalent to the international standard: This section has made the following editorial changes: --- Rewrite Appendix A in accordance with the requirements of GB/T 20308-2020: This part is proposed and managed by the National Standardization Technical Committee for Product Geometric Technical Specifications (SAC/TC240): Drafting organizations of this section: China Jiliang University, China National Machinery Productivity Promotion Center, Beijing Times Peak Technology Co:, Ltd:, China Metrology Science Research Institute, Hexagon Measurement Technology (Qingdao) Co:, Ltd:, Zhengzhou University: The main drafters of this section: Kong Ming, Ming Cuixin, Hao Jianguo, Wang Weinong, Wang Jin, Zhu Yue, Zhao Jun, Zheng Peng:

Introduction

This part of GB/T 18779 is a geometric product specification (GPS) standard, which will belong to the global GPS standard system (see GB/T 20308): It affects the parts C, D, E, F, and G in the GPS matrix model: For more detailed information about the relationship between this part of GB/T 18779 and other standards and GPS matrix models, see Appendix A: Unless otherwise specified, the determination rules given in GB/T 18779:1 are applicable to ensure that the workpiece and measuring equipment are within the specification range: And it can avoid disputes over whether the workpiece and measuring equipment are within the scope of the specification: In order to make the judgment rules operate as designed, it is important to first give a proof of qualification: In other words, the user/buyer of the product The manufacturer/supplier/seller of the product is always required to provide proof of product conformity: If the subsequent purchase inspection proves to be unqualified, the uncertainty report can be checked according to GB/T 18779:3 to mutually ensure its validity Sex: If the conclusion is that both uncertainty reports are valid, then the only conclusion is one of the measurement results or both It is not representative of the measurement process discussed: If for some reason, the user of the product does not want the supplier to provide the first evidence, but relies on the purchase inspection, the user should pass The measurement uncertainty of the incoming inspection is used to reduce the functional limit to reach the agreed contract specification limit, and negotiate with the supplier to reach an agreement: Another problem is distributors, who buy products from manufacturers and resell them to users: If the distributor asks the product manufacturer to provide Provide the qualification certificate, and then provide the certificate to the user, then the judgment rules given in GB/T 18779:1 will operate correctly: If the dealer If it is decided for some reason to independently provide the user with a certificate of conformity, there will be a situation where neither qualification nor disqualification can be proved: To distributors, neither can return the products according to the original specifications, nor can they resell the products: Therefore, this method is not recommended: The determination rules in GB/T 18779:1 are also based on some assumptions: When these assumptions are not true, these judgment rules may not be economic The best: This part of GB/T 18779 outlines these assumptions and discusses why they are theoretically ideal assumptions: For artifacts, usually only the creator (designer) of the specification knows whether the assumption holds: Therefore, any agreement with GB/T 18779:1 Deviations from prescribed rules can only be proposed and documented by the owner of the specification: For measuring equipment, the specification can be based on a standard prepared unilaterally by the equipment manufacturer or buyer, or based on a standard prepared by the equipment manufacturer and buyer in cooperation: quasi: If the specification is based on a national standard, and the standard does not specify other determination rules, the rules of GB/T 18779:1 apply: In other situations In this case, the determination rules can only be documented by the author of the specification: It should be realized that both implicit and explicit judgment rules are part of the specification: It is necessary to further realize that the issues involved in selecting the optimal decision rule set are complex, and simple rules are expected to be applicable to every situation Is unrealistic: All parties shall ensure that they can obtain sufficient technical resources before deviating from the GB/T 18779:1 determination rule: In this case, the owner of the specification needs to realize that other judgment rules besides the judgment rules defined in GB/T 18779:1 are Applicable, and need to prepare the preparation documents of this policy, provide to trading partners (customers and/or suppliers), in the product technical documents Reference: Product Geometric Technical Specification (GPS) Measurement inspection of workpiece and measuring equipment Part 4: Functional Limits in Judgment Rules The basis of the norm

1 Scope

This part of GB/T 18779 specifies the main assumptions under the theoretical ideal judgment rule in GB/T 18779:1: Given these The rule should be the reason for the default rule and the factors that need to be considered before applying different judgment rules: This part is applicable to all specifications involved in the GPS general standard (see GB/T 20308), that is, the standard compiled by SAC/TC240: Including workpiece specifications (usually given in the form of specification limits) and measuring equipment specifications (usually given in the form of maximum allowable error):

2 Normative references

The following documents are indispensable for the application of this document: For dated reference documents, only the dated version applies to this article Pieces: For undated references, the latest version (including all amendments) applies to this document: GB/T 18779:1 Technical Specification for Product Geometrical Quantity (GPS) Measurement Inspection of Workpieces and Measuring Equipment Part 1: Inspection According to Specifications Rules for determining qualified or unqualified inspection (GB/T 18779:1-2002, eqvISO 14253-1:1998)

3 Terms and definitions

The following terms and definitions defined in GB/T 18779:1 apply to this document: 3:1 Reverse engineering Analyze the shape, size and function of the finished workpiece or prototype and use this information to create a design process for similar products: 3:2 Product functional level Evaluate the completeness of product functions from an overall perspective: 3:3 Productattributefunctionallevelproductattributefunctionallevel Evaluate the completeness of product functions from specific attributes: Note: The overall product function level depends on the function level of all product attributes: 3:4 Workpiece functional level Evaluate the overall completeness of the product function composed of the considered artifacts and a set of qualified artifacts: 3:5 Workpiececharacteristicfunctionallevel Evaluate the completeness of the product function composed of the considered artifact and a set of qualified artifacts from specific attributes: These attributes are affected by the considered ......
