GB/T 18759.5-2016: Electrical equipment of machines -- Open numerical control system -- Part 5: Software platform
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 18759.5-2016	919	Add to Cart	7 days	Electrical equipment of machines -- Open numerical control system -- Part 5: Software platform	Valid

Similar standards

GB/T 39331   GB/T 16977   GB/T 36415   GB/T 18759.8   GB/T 18759.7   GB/T 18759.6

Basic data

Standard ID: GB/T 18759.5-2016 (GB/T18759.5-2016)
Description (Translated English): Electrical equipment of machines -- Open numerical control system -- Part 5: Software platform
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J07
Classification of International Standard: 29.020
Word Count Estimation: 46,467
Date of Issue: 2016-04-25
Date of Implementation: 2016-11-01
Quoted Standard: GB/T 9387.1-1998; GB/T 15969.3-2005; GB/T 18759.1-2002; GB/T 18759.2-2006; GB/T 19769.1-2005
Regulation (derived from): National Standard Announcement No
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard stipulates the structure and basic structure of the open CNC system software platform for mechanical and electrical equipment. It provides a reference frame for the analysis, design and implementation of the open NC system software platform, which meets the requirements of the open and interoperation of numerical control system of mechanical and electrical equipment. This standard applies to metal processing machinery, textile machinery, printing machinery, sewing machines, plastic and rubber machinery, woodworking machinery and other electrical equipment used in open CNC system. Other industrial machinery and equipment used in the open CNC system can also refer to the implementation.

GB/T 18759.5-2016: Electrical equipment of machines -- Open numerical control system -- Part 5: Software platform

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Electrical equipment of machines - Open numerical control system - Part 5. Software platform ICS 29.020 J07 National Standards of People's Republic of China Mechanical and Electrical Equipment Open CNC System Part 5. Software platform system-Part 5. Softwareplatform 2016-04-25 released 2016-11-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of the People 's Republic of China China National Standardization Management Committee released Directory Preface Ⅴ 1 Scope 1 2 normative reference document 1 3 Terms and Definitions, Symbols and Abbreviations 1 3.1 Terms and definitions 1 3.2 Symbols and Abbreviations 3 4 basic requirements 3 4.1 Overview 3 4.2 Basic structure 4 4.3 platform model 4 4.4 Data types and data structures 5 5 operating system 6 5.1 Overview 6 5.2 Task Scheduling Management 6 5.3 High-precision real-time clock 7 5.4 Real-time operating system interrupt management 7 5.5 real-time tasks (process)/inter-thread communication 7 5.6 Real-time tasks (process) management 7 5.7 Device Management 7 5.8 Network Management 7 6 middleware 7 6.1 Overview 7 6.2 Communication module 8 6.3 graphics library 8 Mathematical library 8 6.5 real-time operating system module 8 6.6 Kinematic modules 6.7 bus driver module 9 Application Programming Interface 7.1 Overview 9 7.2 Common operating system interface 9 7.3 communication interface 9 7.4 graphical interface 9 7.5 Math library interface 9 7.6 Real-time operating system interface 9 7.7 Kinematic Interface 10 7.8 bus driver interface 10 7.9 Application Programming Interface Example 10 Configuration of system, device, and function 8.1 Overview 10 8.2 System Model 10 8.3 Device model 10 8.4 Functional Component Model 11 8.5 Function Block Model 12 Application Model 8.7 Configuration of systems, devices, and functional components 14 Appendix A (informative) Operating system function interface example 17 Appendix B (informative) Middleware 19 Appendix C (informative) Application Programming Interface (API) 25 Appendix D (informative) Data type and data structure 29 Appendix E (Informative Appendix) ONC Software Architecture Example 38 Reference 40 Figure 1 ONC system basic architecture 4 Figure 2 software platform architecture 5 Figure 3 Example of data type hierarchy 5 Figure 4 real-time operating system basic structure 6 Figure 5 Interoperability between middleware and application software 8 Figure 6 System model 10 Figure 7 Device model 11 Figure 8 functional component model 12 Figure 9 Function Block Model 13 Figure 10 Apply the model Figure B.1 Managing Function Block Status and Transition Conditions Figure 22 Figure B.2 Management Function Block Type Generic Form 23 Figure D.1 Community variable memory model example Figure E.1 Interpolation module (example) 38 Figure E.2 Interpolation module internal structure (example) 38 Figure E.3 PLC module structure (example) 39 Figure E.4 Fieldbus Drive Module Architecture (Example) 39 Table A.1 Task (process) communication call function interface (example) 17 Table A.2 Real-time tasks (processes) between the management function interface (example) 17 Table B.1 Standard input and output of the service interface function block 20 Table B.2 Management Function Block Status Table 22 Table B.3 Management Function Block Conversion Conditions Table 22 Table B.4 CMD input values and semantics 23 Table B.5 STATUS Output Values and Semantics 23 Table B.6 Command syntax 24 Table D.1 Attributes of the basic data types Table D.2 Code when the BOOL type data is True Table D.3 Encoding when BOOL type data is False Table D.4 Example of storage of SINT type data 30 Table D.5 Example of storage for INT type data 31 Table D.6 Storage example for LINT type data 31 Table D.7 Example of Storage for USINT Type Data Table D.8 Example of Storage for UINT Type Data Table D.9 Example of Storage for ULINT Type Data Table D.10 Storage format for REAL and LREAL type data 33 Table D.11 Example of storage for REAL type data 33 Table D.12 Example of storage for CHAR type data 34 Table D.13 Examples of derived data types

Foreword

GB/T 18759 "mechanical and electrical equipment open CNC system" is divided into the following parts. - Part 1. General; Part 2. Architecture; Part 3. Bus interface and communication protocol; - Part 4. Hardware platform; - Part 5. Software platform; - Part 6. Network interface and communication protocol; - Part 7. General technical conditions; Part 8. Test and Acceptance. This part is part 5 of GB/T 18759. This part is drafted in accordance with the rules given in GB/T 1.1-2009. This part is made by the China Machinery Industry Federation. This part of the National Industrial Machinery Electrical System Standardization Technical Committee (SAC/TC231) centralized. This part is responsible for the drafting unit. Shenyang high precision CNC Technology Co., Ltd., the State Machine Tool Quality Supervision and Inspection Center. This part participates in the drafting unit. Shenyang Institute of Computing Technology, Chinese Academy of Sciences, Guangzhou CNC Equipment Co., Ltd., Beijing Kay En Di CNC technology limited liability company, Beijing Aerospace CNC System Co., Ltd., Dalian Guangyang Technology Engineering Co., Ltd., Wuhan Huazhong NC Co., Ltd., Shanghai Jiaotong University, Beijing University of Aeronautics and Astronautics, Shandong University, Zhejiang University, Shenyang Machine Tool (Group) Co., Ltd., Zhejiang Kaida Machine Tool Co., Ltd., Beijing easy to cubic Technology Co., Ltd. This part of the main drafters. Yu Dong, Huang Zuguang, Yin Zhenyu, Hu Yi, Hu Tianliang, Yang Hongli, Wang Jian, Yang Tangyong, Feng Dongqin, Xue Ruijuan, Song Bao, Wang Qin. Mechanical and Electrical Equipment Open CNC System Part 5. Software platform

1 Scope

This part of the provisions of the mechanical and electrical equipment open CNC system software platform construction and basic structure for the open CNC system Software platform analysis, design and implementation of the reference frame to meet the mechanical and electrical equipment, CNC system open and interoperability requirements. This part applies to metal processing machinery, textile machinery, printing machinery, sewing machinery, plastic and rubber machinery, woodworking machinery and other electrical facilities Standby open CNC system. Other industrial machinery and equipment with the open CNC system can also refer to the implementation.

2 normative reference documents

The following documents are indispensable for the application of this document. For dated references, only the dated edition applies to this article Pieces. For undated references, the latest edition (including all modifications) applies to this document. GB/T 9387.1-1998 Information technology - Open systems interconnection - Basic reference model - Part 1. Basic model (ISO / IEC 7498-1..1994, IDT) GB/T 15969.3-2005 Programmable controllers - Part 3. Programming languages (IEC 61131-3..2002, IDT) Mechanical electrical equipment - Open numerical control systems - Part 1. General principles GB/T 18759.1-2002 Mechanical and electrical equipment - Open numerical control systems - Part 2. Architecture - GB/T 18759.2-2006 GB/T 19769.1-2005 Functional blocks for industrial process measurement and control systems - Part 1. Structures (IEC 61499-1..2003, MOD) 3 terms and definitions, symbols and abbreviations 3.1 Terms and definitions The following terms and definitions apply to this section. 3.1.1 Open CNC system opennumericalcontrol (ONC) system Application software is built on the system, which follows the system platform of openness, expansibility and compatibility, so that the application software has Portability, operability and man-machine interface consistency. [GB/T 18759.1-2002, 3.1] 3.1.2 System platform By the hardware platform and software platform for the operation of numerical control applications for the movement of components to control the basic components, and the Department of CNC Other components together to achieve the operation of the mechanical control. [GB/T 18759.1-2002, 3.3] 3.1.3 Hardware platform hardwareplatform Software platform and application software to run the basic components, in the basic structure of the bottom. ......
