GB/T 17473.4-2008: Test methods of precious metals pastes used for microelectronics -- Determination of adhesion
Status: Valid

GB/T 17473.4: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 17473.4-2008	139	Add to Cart	3 days	Test methods of precious metals pastes used for microelectronics -- Determination of adhesion	Valid
GB/T 17473.4-1998	239	Add to Cart	2 days	Test methods of precious metal pastes used for thick film microelectronics--Determination of adhesion	Obsolete

Similar standards

GB/T 17473.2 GB/T 17473.1 GB/T 17473.5 GB/T 17472 GB/T 17473.7 GB/T 17473.6

Basic data

Standard ID: GB/T 17473.4-2008 (GB/T17473.4-2008)
Description (Translated English): Test methods of precious metals pastes used for microelectronics -- Determination of adhesion
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: H68
Classification of International Standard: 77.120.99
Word Count Estimation: 6,688
Date of Issue: 2008-03-31
Date of Implementation: 2008-09-01
Older Standard (superseded by this standard): GB/T 17473.4-1998
Quoted Standard: GB/T 8170
Regulation (derived from): National Standard Approval Announcement 2008 No.5 (Total No.118)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the method for the determination of precious metal microelectronics slurry adhesion. This section applies to microelectronics-Determination of adhesion of precious metal pastes.

GB/T 17473.4-2008: Test methods of precious metals pastes used for microelectronics -- Determination of adhesion

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Test methods of precious metals pastes used for microelectronics. Determination of adhesion ICS 77.120.99 H68 National Standards of People's Republic of China Replacing GB/T 17473.4-1998 Microelectronics precious metal pastes used test method Determination of adhesion Posted 2008-03-31 2008-09-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This standard is GB/T 17473-1998 "precious metal pastes used for thick film microelectronics test methods" (all parts) Integration repair Book is divided into seven sections. --- GB/T 17473.1-2008 microelectronics test method for measuring precious metal slurry solids content; --- GB/T 17473.2-2008 microelectronics test method for measuring the fineness of precious metal pastes; --- GB/T 17473.3-2008 microelectronics precious metal pastes used test method for measuring the resistance parties; --- GB/T 17473.4-2008 microelectronics adhesion testing precious metal pastes used test methods; --- GB/T 17473.5-2008 microelectronics precious metal slurry viscosity measurement test methods; --- GB/T 17473.6-2008 microelectronics resolution measurement test methods of precious metal pastes; --- GB/T 17473.7-2008 microelectronics precious metal pastes used test methods weldability, resistance to soldering determination. This section GB/T of Part 417473-2008. This Part replaces GB/T 17473.4-1998 "precious metal pastes used for thick film microelectronics Test Method for Determination of adhesion." This portion of the GB/T 17473.4-1998 compared to the main changes are as follows. --- The original standard name is amended as. microelectronics precious metal pastes used test methods - Determination of adhesion; --- Removing the original standard content "non-noble metals electronic pastes adhesion assay can also be performed with reference to this standard"; --- Increased SnAg3.0Cu0.5 for lead-free solder welding conductor; --- Replace the original standard belt tunnel furnace sintering furnace; --- Increasing the temperature control of lead-free solder. This part is proposed by the China Nonferrous Metals Industry Association. The non-ferrous metal part by the National Standardization Technical Committee. This section is your research Platinum Ltd. is responsible for drafting. The main drafters of this section. Liu Jisong Chen Qiao, Zhao Ling, Chen Fusheng, Liu Cheng, Zhuwu Xun, Li Jin. This part of the standard replaces the previous editions are. --- GB/T 17473.4-1998. Microelectronics precious metal pastes used test method Determination of adhesion

1 Scope

This section provides test methods microelectronics precious metal pastes adhesion. This section applies to microelectronics precious metal pastes adhesion assay.

2 Normative references

The following documents contain provisions which, through reference in this text, constitute provisions of this part. For dated references, subsequent Amendments (not including errata content) or revisions do not apply to this section, however, encourage the parties to this part of the research agreement Whether the latest versions of these documents. For undated reference documents, the latest versions apply to this section. GB/T 8170 numerical rounding rules

3 PRINCIPLE OF THE METHOD

After the copper wire soldered to the ceramic substrate layer printed graphics cooked noble metal slurry on the copper surface perpendicular to the substrate is bent 90 °, placed The average of the tensile testing machine at a constant speed from the substrate evenly pull off the lead, with the lead when the pull-off force to represent the attached slurry Focus.

4 Materials

4.1 Al2O3 purity of not less than 95% of the ceramic substrate, the surface roughness in the range of 0.5μm ~ 1.5μm (measured at a distance of 10mm Under the conditions of measurement). 4.2 HLSn63PbA or HLSn63PbB Xiqianhanliao; HLSn63PbAgA HLSn63PbAgB or tin-lead-silver solder; SnAg3.0Cu0.5 Lead-free solder. 4.3 tinned copper wire having a diameter of 0.8mm ± 0.02mm. 4.4 capacity not less than 150mL solder bath. 4.5 Flux. rosin alcohol solution, the concentration of 0.15g/mL ~ 20g/mL.

5 instruments and equipment

5.1 tensile testing machine. range is 0N ~ 100N, accurate measurement and recording of the pulling force should reach ± \u200b\u200b5%. 5.2 screen printing machine, the screen pore size of 74μm. 5.3 tunnel sintering furnace, the maximum temperature of 1000 ℃, temperature control accuracy of ± 10 ℃. 5.4 Thickness. accuracy of 1μm.

6 measuring step

At a temperature of 15 ℃ ~ 35 ℃, relative humidity of 45% to 75%, measured at atmospheric pressure 86kPa ~ 106kPa conditions. 6.1 Preparation of slurry film 6.1.1 The submission slurry Stir in central ceramic substrate printed 2mm × 2mm graphics, graphics should look uniform. each The total number of copies printed sample of not less than 10. 6.1.2 The printed pattern is a ceramic substrate at 150 ℃ ~ 200 ℃ drying, depending on the sintering temperature firing slurry deposition. ......
