GB/T 17157-2012: Specifications for aerial photogrammetric analytical mapping of 1: 25 000 1: 50 000 1: 100 000 topographic maps

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS07.040 A77 National Standards of People's Republic of China Replacing GB/T 17157-1997 1.250001.500001.100000 Topographic map aerophotogrammetry analytic mapping specification Issued on. 2012-10-01 2012-06-29 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Table of Contents

Introduction Ⅲ 1 Scope 1 2 Normative references 1 3 1 General Provisions 3.1 specification topographic map 1 3.2 Mapping Accuracy 1 3.3 Requirements aerial data 1 3.4 Requirements aerial outside the industry, the outcome of the 2 Requirements 3.5 Instrument 2 Requirements 3.6 data recording format 2 4 Mapping System 2 4.1 photograph measuring instruments 2 Computer 2 4.2 4.3 Orientation photo software 2 4.4 data acquisition software 2 4.5 2 graphics editing software 4.6 annotation symbol library 2 2 graphics output 4.7 software 5 Preparation 2 5.1 Data Collection 2 5.2 Technical Design 3 6 photographic processing 3 7 Aerotriangulation 3 8 Mapping 3 8.1 Orientation 3 photo 8.2 Mapping and editing 3 8.3 Terrain picture output 4 4 9 Related documentation 10 results of quality inspection and acceptance 4 11 Achievements handed 4

Foreword

This standard rule according to GB/T 1.1-2009 given draft. This standard replaces GB/T 17157-1997 "1.250001.500001.100000 topographic map and aerial photogrammetry Digital Surveying FIG specification. " This standard and GB/T 17157-1997 compared to the main changes are as follows. --- Redefined the standard name and scope; --- Normative references have been revised; --- Modify the overall structure of the standard; --- References GB/T 12340, GB/T 20257.3, GB/T 12343.1 content and GB/T 24356 of; --- Delete the contents of the relevant digital photogrammetric systems and scanners for photo requirements; --- Increased its technical design requirements; --- Increase the photograph directional accuracy; --- Added "Related documentation" requirements; --- Modifications that should be turned over to adjust the results of the name of order. This standard was proposed by the National Mapping Geographic Information Bureau. This standard by the National Standardization Technical Committee on Geographical Information (SAC/TC230) centralized. This standard by the National Mapping Bureau of Surveying and Mapping Institute of Standardization responsible for drafting. The main drafters of this standard. Wangzhan Hong, Duan Yihong, Song Yaodong, Linding Rong, Chen Jiliang. This standard replaces the standards previously issued as follows. --- GB/T 17157-1997. 1.250001.500001.100000 Topographic map aerophotogrammetry analytic mapping specification

1 Scope

This standard specifies the application of analytical photogrammetry mapping method 1.25000, 1.50000, 1.100000 topographic map mapping The basic job requirements, specifications and accuracy. This standard applies to use aerial photography mapping analytical methods 1.25000, 1.50000, 1.100000 Topographic Mapping Production operations.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated edition applies to this article Member. For undated references, the latest edition (including any amendments) applies to this document. GB/T 12340 1.250001.500001.100000 topographic map Aerophotogrammetry within industry norms GB/T 12341 1.250001.500001.100000 topographic map Aerophotogrammetry outside the industry norm GB/T 12343.1 national basic scale compilation Part 1. 1.250001.500001.100000 topographic map series Painted Specification GB/T 15661 1.50001.100001.250001.500001.100000 topographic map of aerial photography norm GB/T 17158 photogrammetric digital mapping recording format GB/T 20257.3 national basic scale map drawings - Part 3. 1.250001.500001.100000 topographic map Schema GB/T 24356 mapping results quality inspection and acceptance CH/T1001 mapping rules for preparation of Technical Summary CH/T1004 mapping technology design requirements CH/T8015 HHS90-B/120-B CNC plotter
