GB/T 11490-2011: Dimensions of base for color picture tubes
Status: Valid

GB/T 11490: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 11490-2011	259	Add to Cart	3 days	Dimensions of base for color picture tubes	Valid
GB/T 11490-1989	359	Add to Cart	3 days	Dimensions of base for colour picture tube	Obsolete

Similar standards

GB/T 12631 GB/T 6206 GB/T 9435

Basic data

Standard ID: GB/T 11490-2011 (GB/T11490-2011)
Description (Translated English): Dimensions of base for color picture tubes
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: L38
Classification of International Standard: 31.100
Word Count Estimation: 11,167
Date of Issue: 2011-12-30
Date of Implementation: 2012-07-01
Older Standard (superseded by this standard): GB/T 11490-1989
Quoted Standard: GB/T 4597
Regulation (derived from): Announcement of Newly Approved National Standards No. 23 of 2011
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the shape of the base color kinescope tube drawing, dimensioning requirements and electrode wiring. This standard applies to the color picture tube and socket connectors.

GB/T 11490-2011: Dimensions of base for color picture tubes

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Dimensions of base for color picture tubes ICS 31.100 L38 National Standards of People's Republic of China Replacing GB/T 11490-1989 Color tubes of group size Issued on. 2011-12-30 2012-07-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This standard GB/T 1.1-2009 given rule drafting. This standard replaces GB/T 11490-1989 "color tubes of group size." This standard compared with GB/T 11490-1989 main changes are as follows. --- Increased in Chapter 2, normative references; --- Increased Chapter 3 Terms and definitions; --- With three types of pipe base Dimensions and concrete dimension example instead of the original standard size concrete pipe base maps and marked Names were specified size; --- Increasing the tube base electrode wiring diagram of an example; --- Deleted Chapter 3 Inspection gauges. The standard proposed by the Ministry of Industry and Information Technology of the People's Republic of China. This standard by the National Standardization Technical Committee electric vacuum devices (SAC/TC167) centralized. This standard was drafted. Rainbow Group. The main drafters of this standard. Huang Ning songs, cow small plum, Han Seung. This standard replaces the standards previously issued as follows. --- GB/T 11490-1989. Color tubes of group size

1 Scope

This standard specifies the color picture tube of the tube-based outline drawings, dimensions and electrode wiring requirements. This standard applies to the plug socket of the color picture tube.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. GB/T 4597 tubes vocabulary

3 Terms and Definitions

Terms and definitions GB/T 4597 established applicable to this document.

4 base size

4.1 8-pin tube base 4.1.1 8-pin tube base outline drawings 8-pin tube base outline drawings shown in Figure 1. 4.1.2 8-pin tube base dimension 8-pin tube base dimensioning example in Table 1. 4.2 10 foot tube single focus group 4.2.1 10-pin single tube focus group outline drawings 10 foot tube single focus group outline drawings shown in Figure 2. 4.2.2 10-pin single focus group pipe dimension 10 foot tube single focus group dimensioning example in Table 2. 4.3 10-pin dual focus tube base 4.3.1 10-pin dual focus tube base outline drawings 10-pin dual focus group outline drawings of pipe as shown in Figure 3. 4.3.2 10-pin dual focus tube dimension group 10-pin dual focus tube dimension sample group are shown in Table 3. ......
