GB/T 1127-2023 English PDF

US$269.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 1127-2023: Woodruff keyseat cutters
Status: Valid

GB/T 1127: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 1127-2023	269	Add to Cart	3 days	Woodruff keyseat cutters	Valid
GB/T 1127-2007	359	Add to Cart	3 days	Woodruff key seat cutters	Obsolete
GB/T 1127-1997	359	Add to Cart	3 days	Cutters for woodruff keyseats	Obsolete
GB 1127-1981	199	Add to Cart	2 days	Woodruff key-seat milling cutters	Obsolete

Similar standards

GB/T 33524.2   GB/T 972   GB/T 5104   GB/T 1132   GB/T 1134

Basic data

Standard ID: GB/T 1127-2023 (GB/T1127-2023)
Description (Translated English): Woodruff keyseat cutters
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J41
Classification of International Standard: 25.100.20
Word Count Estimation: 14,123
Date of Issue: 2023-09-07
Date of Implementation: 2024-04-01
Older Standard (superseded by this standard): GB/T 1127-2007
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 1127-2023: Woodruff keyseat cutters

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS 25.100.20 CCSJ41 National Standards of People's Republic of China Replace GB/T 1127-2007 Half round keyway milling cutter Published on 2023-09-07 2024-04-01 Implementation State Administration for Market Regulation Released by the National Standardization Administration Committee

Foreword

This document complies with the provisions of GB/T 1.1-2020 "Standardization Work Guidelines Part 1.Structure and Drafting Rules of Standardization Documents" Drafting. This document replaces GB/T 1127-2007 "Semi-circular keyway milling cutter". Compared with GB/T 1127-2007, except for structural adjustment and editing In addition to the modifications, the main technical changes are as follows. a) In the model, the end process boss structure is deleted (see Figure 1, Figure 1~Figure 4 of the.2007 version); b) Increase the neck diameter d2 size (see Figure 1, Table 1); c) The total length in Table 1 is changed from 55mm to 56mm, 60mm to 63mm, and 65mm to 71mm (see table 1, Table 1 of the.2007 edition); d) The radial circular runout of the circumferential edge to the handle axis is changed from 0.05mm to 0.03mm (see Table 2, Table 2 of the.2007 edition); e) Added high-performance high-speed steel and powder metallurgy high-speed steel among the materials, and added requirements for welding handle materials (see 6.2.1,.2007 version 4.2.1). This document is modified to adopt ISO 12197.2016 "Semi-circular keyway milling cutter dimensions". Compared with ISO 12197.2016, this document has made the following structural adjustments. ---Added Chapter 3 Terms and Definitions; ---Added Chapter 5 mark; ---Added Chapter 6 Technical Requirements; ---Added Chapter 7 logo and packaging. The technical differences and reasons between this document and ISO 12197.2016 are as follows. ---Replaced ISO 3338-1 and ISO 3338-2 with normative reference documents GB/T 6131.1 and GB/T 6131.2 (See 4.2), replaced ISO 3912 (see Table 1) with normative reference document GB/T 1098, added GB/T 6131.3, GB/T 6131.4, to adapt to my country’s technical conditions; ---The handle type adds 2° beveled flat handle and threaded handle to meet domestic needs; ---The structure of the cutting part is divided into types A, B, and C, among which type A is added to meet domestic needs; ---The basic size of the semicircular key is changed from width × height to width × diameter, in line with domestic needs; ---The key width is 6mm and the handle diameter of 8mm is changed from 10mm to 12mm to meet domestic needs; ---The basic size of the milling cutter diameter is increased by 0.5mm, and the limit deviation is changed from 0.5 to 0.4 to h11.The upper deviation is added to the basic size to satisfy Domestic needs; ---Added markings (see Chapter 5) to meet domestic needs; ---Added technical requirements (see Chapter 6) to meet domestic needs; ---Added logo and packaging (see Chapter 7) to meet domestic needs. Please note that some content in this document may be subject to patents. The publisher of this document assumes no responsibility for identifying patents. This document is proposed by China Machinery Industry Federation. This document is under the jurisdiction of the National Tool Standardization Technical Committee (SAC/TC91). This document was drafted by. Sichuan Tianhu Tools Co., Ltd., Wenling Gongliangong Measuring and Cutting Tool Technology Service Co., Ltd., Jiangyin Set Precision Mi Tools Co., Ltd., Weihai Wei Hard Tools Co., Ltd. The main drafters of this document. Liu Qianlun, Wu Jianbo, Lu Shaofeng, Zhang Jiying, Su Fangyou. The previous versions of this document and the documents it replaces are as follows. It was first published as GB/T 1127-1973 in 1973, revised for the first time in 1981, revised for the second time in.1997, and revised for the third time in.2007. This is the fourth revision. Half round keyway milling cutter

1 Scope

This document specifies the basic requirements for semi-circular keyway milling cutters such as size, material, hardness, appearance, surface roughness, marking and packaging. press book The milling cutter produced by the document is suitable for semicircular keyways produced according to GB/T 1098. This document applies to the manufacture of semicircular keyway milling cutters. The relationship between this document and the priority symbols of ISO 13399 (all parts) is shown in Appendix A.

2 Normative reference documents

The contents of the following documents constitute essential provisions of this document through normative references in the text. Among them, the dated quotations For undated referenced documents, only the version corresponding to that date applies to this document; for undated referenced documents, the latest version (including all amendments) applies to this document. GB/T 1098 Cross-sectional dimensions of semicircular keyway GB/T 6131.1 Milling cutter straight shank Part 1.Types and dimensions of ordinary straight shank (GB/T 6131.1-2006, ISO 3338-1. 1996,IDT) GB/T 6131.2 Milling cutter straight shanks Part 2.Types and dimensions of straight shanks (GB/T 6131.2-2006, ISO 3338-2. 2000,MOD) GB/T 6131.3 Milling cutter straight shank Part 3.Types and dimensions of 2° inclined straight shank GB/T 6131.4 Milling cutter straight shank Part 4.Types and dimensions of threaded shank (GB/T 6131.4-2006, ISO 3338-3. 1996,IDT)

3 Terms and definitions

There are no terms or definitions to be defined in this document.

4 Types and sizes

4.1 The type of semi-circular keyway milling cutter is as shown in Figure 1, and the dimensions are as shown in Table 1. 4.2 The shank of the semicircular keyway milling cutter shall be as specified below, and the schematic diagram is shown in Figure 1. ---Ordinary straight handle according to GB/T 6131.1; ---Sharpen straight handle according to GB/T 6131.2; ---2° beveled straight shank according to GB/T 6131.3; ---Threaded handle according to GB/T 6131.4. ......
