FZ/T 01143-2018 English PDF

US$139.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
FZ/T 01143-2018: Coated fabrics--Test method of flexing resistance at low temperature
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
FZ/T 01143-2018	139	Add to Cart	3 days	Coated fabrics--Test method of flexing resistance at low temperature	Valid

Similar standards

FZ/T 01149   GB/T 251   GB/T 730   FZ/T 01150   FZ/T 01148

Basic data

Standard ID: FZ/T 01143-2018 (FZ/T01143-2018)
Description (Translated English): Coated fabrics--Test method of flexing resistance at low temperature
Sector / Industry: Spinning & Textile Industry Standard (Recommended)
Classification of Chinese Standard: W04
Classification of International Standard: 59.080.40
Word Count Estimation: 6,669
Date of Issue: 2018-10-22
Date of Implementation: 2019-04-01
Regulation (derived from): Ministry of Industry and Information Technology Announcement No. 54 of 2018
Issuing agency(ies): Ministry of Industry and Information Technology of the People's Republic of China
Summary: This standard specifies the test method for the folding resistance of coated fabrics under low temperature conditions. This standard applies to coated fabrics with a thickness of not more than 3 mm.

FZ/T 01143-2018: Coated fabrics--Test method of flexing resistance at low temperature

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
(Painting process computer aided design requirements) ICS 59.080.40 W04 People's Republic of China Textile Industry Standard Test method for low temperature folding resistance of coated fabrics Published on.2018-10-22 Implementation of.2019-04-01 Ministry of Industry and Information Technology of the People's Republic of China

Foreword

This standard was drafted in accordance with the rules given in GB/T 1.1-2009. This standard was proposed by the China National Textile and Apparel Council. This standard is under the jurisdiction of the Basic Standards Branch of the National Textile Standardization Technical Committee (SAC/TC209/SC1). This standard was drafted. Guangzhou Fiber Products Testing and Research Institute, Shenzhen Changshuo New Textile Materials Co., Ltd., China Textile Standard Inspection and Certification Shares Limited. The main drafters of this standard. Yang Xinhui, Liao Chunqiang, Deng Hua, Luo Jun, Yan Shuang, Xu Baiqing, Jiang Hong. Test method for low temperature folding resistance of coated fabrics

1 Scope

This standard specifies the test method for the folding resistance of coated fabrics under low temperature conditions. This standard applies to coated fabrics with a thickness of not more than 3 mm.

2 Normative references

The following documents are indispensable for the application of this document. For dated references, only the dated version applies to this article. Pieces. For undated references, the latest edition (including all amendments) applies to this document. FZ/T 01003 coated fabric thickness test method

3 Principle

The one end of the sample is folded inwardly and clamped in the movable upper clamp, and then the sample is folded outward and the other end is turned downward and coated. Face-to-face, the lower end is clamped in the fixed lower fixture. In the specified low temperature environment, the upper clamp drives the specimen to move to the specified number of flexing times. Check the surface of the specimen for damage.

4 Terms and definitions

The following terms and definitions apply to this document. 4.1 Low temperature folding performance flexingresistanceatlowtemperature The material resists repeated flexing properties under low temperature conditions.

5 equipment

5.1 folding tester 5.1.1 Upper clamp consisting of a pair of flat metal plates rotating around the axis, see Figure 1. After the low temperature box (5.2) reaches the test temperature, the folding tester The upper clamp starts to make a round-trip flexion with a flexing angle of (22.5 ± 0.5) ° and a flexing frequency of (100 ± 5) times/min. 5.1.2 Lower clamp, which is a fixed fixture, on the same vertical plane as the upper clamp. When the upper clamp has a flexion angle of 0°, the lower edge of the upper clamp is The upper edge of the lower clamp is parallel and the vertical distance is (25 ± 1) mm. 5.1.3 Counter indicating the number of flexings. 5.2 Low temperature box It can accommodate the folding tester, the temperature can meet the test requirements, and the temperature deviation in the low temperature box should be controlled at ±2 °C. ......
