FZ/T 01059-2014: Test method of electrostatic clinging of fabric
---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Test method of electrostatic clinging of fabric
ICS 59.080.30
W04
People's Republic of China textile industry standards
Replacing FZ/T 01059-1999
Performance test methods for electrostatic adsorption fabric friction
Issued on. 2014-12-24
2015-06-01 implementation
Ministry of Industry and Information Technology of the People's Republic of China released
Foreword
This standard was drafted in accordance with GB/T 1.1-2009 given rules.
Instead of the standard FZ/T 01059-1999 "Determination of adsorption fabric static friction." This standard FZ/T 01059-1999
Compared to the main differences are as follows.
1. Normative references added GB/T 7568.3 and GB/T 8629, GB 3921 and removed FJ549;
2. The increase in Chapter 3;
3. description of the principle of the refinement;
4. Delete the original standard in Figure 2;
5. Modify the Chapter 6 with air conditioning and testing;
6. Increased 7.1 sample pretreatment;
7. Modify the number of sample 7.2.2.
The standard proposed by China Textile Industry Association.
This standard by the National Standardization Technical Committee on Basic Standards Subcommittee Textiles (SAC/TC209/SC1) centralized.
Drafting of this standard. National Textile Products Quality Supervision and Inspection Center.
The main drafters of this standard. Renhe Ning.
This standard superseded standard previously issued as follows.
--- FZ/T 01059-1999.
Performance test methods for electrostatic adsorption fabric friction
1 Scope
This standard specifies the method for determination of static electricity caused by the friction of fabric adsorption properties.
This standard applies to all types of textile fabrics.
2 Normative references
The following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein
Member. For undated references, the latest edition (including any amendments) applies to this document.
GB/T 7568.3 Textiles Tests for color fastness standard adjacent fabrics - Part 3. polyamide fibers
GB/T 8629-2001 Textiles - Domestic washing and drying test procedures
3 Terms and Definitions
The following terms and definitions apply to this document.
3.1
Electrostatic adsorption electrostaticclinging
It made of a surface electric charge caused by static electricity to attract another object phenomenon.
Principle 4
Standard friction rubbing cloth samples, so that the charged adsorbed on the metal plate, the sample was stripped from the lower end, since the sample charged, will be adsorbed again
To the metal plate, but the charge decay, the electrostatic attraction force between the specimen and the metal plate will become increasingly smaller, measured from the first to the adsorption of metal plate
A metal plate is no longer required for the adsorption time t.
5 instruments and appliances
5.1 Test Plate. size (100 ± 2) mm × (450 ± 2) mm, a thickness of about 1mm stainless steel plate (YB541-70 predetermined
1Cr18Ni9Ti stainless steel), bent at an angle (70 ± 2) ° at one end (150 ± 2) mm position, the unit is equipped with a wide board
(70 ± 2) mm clip, away from the upper end of the test plate (230 ± 2) mm made at a marker for positioning the lower edge of the sample, shown in Figure 1.
5.2 ground plate. size (200 ± 2) mm × (360 ± 2) mm stainless steel plate (YB541-70 provisions of 1Cr18Ni9Ti
Plate) with a ground wire.
5.3 static eliminator. suitable means to eliminate static electricity requirements.
5.4 friction block. size (50 ± 2) mm × (150 ± 2) mm, and weighs about 65g, the appropriate thickness of wood, should ensure smooth wood surface.
5.5 double-sided tape. for rubbing cloth attached to the friction block.
Polyurethane foam gasket 5.6. Size of (100 ± 2) mm × (300 ± 2) mm.
5.7 Stopwatch. accuracy 0.1s.
5.8 Tweezers. Tweezers insulated tip.
...
