GB/T 12665-2017: Requirements of damp-heat testing of electrical machine for service in general environmental condition Delivery: 9 seconds. True-PDF full-copy in English & invoice will be downloaded + auto-delivered via email. See step-by-step procedure Status: Valid GB/T 12665: Historical versions
Similar standardsGB/T 12665-2017: Requirements of damp-heat testing of electrical machine for service in general environmental condition---This is an excerpt. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.), auto-downloaded/delivered in 9 seconds, can be purchased online: https://www.ChineseStandard.net/PDF.aspx/GBT12665-2017 GB NATIONAL STANDARD OF THE PEOPLE’S REPUBLIC OF CHINA ICS 19.040 K 26 Replacing GB/T 12665-2008 Requirements of damp-heat testing of electrical machine for service in general environmental condition Issued on. NOVEMBER 1, 2017 Implemented on. MAY 1, 2018 Issued by. General Administration of Quality Supervision, Inspection and Quarantine; Standardization Administration Committee. Table of ContentsForeword... 3 1 Scope... 4 2 Normative references... 4 3 Technical requirements... 4 4 Test method... 7 5 Inspection rules... 13ForewordThis Standard was drafted in accordance with the rules given in GB/T 1.1-2009. This Standard replaces GB/T 12665-2008 "Requirements of damp-heat testing of electrical machine for service in general environmental condition". Compared with GB/T 12665-2008, the main technical changes in this Standard are as follows. - updated Clause 2 Normative references; - modified "voltage resistance" to "electrical strength" (see 3.3 of this Edition); - modified alternating humidity test method, added Method 2 (see 4.2 of this Edition); - added Figure 2; - deleted moisture-proof humidifier, added NOTE 1 (see 4.3 of Edition 2008); - added test method for leakage current after damp-heat (see 4.4 of this Edition). This Standard was proposed by China Electrical Appliance Industry Association. This Standard shall be under the jurisdiction of National Technical Committee on Rotary Motor of Standardization Administration of China (SAC/TC 26). The drafting organizations of this Standard. China Electric Apparatus Research Institute Co., Ltd., Zhejiang Lianyi Motor Co., Ltd., Hangzhou Weiguang Electronics Co., Ltd., Anhui University, Weikai Detection Technology Co., Ltd., Hangzhou Fusheng Electric Appliance Co., Ltd., Guangdong Welling Motor Manufacturing Co., Ltd., Zhejiang Jiuke Electric Co., Ltd., Xiamen Fran Appliances Technology Co., Ltd., Xi'an Xumai Intelligent Household Appliance Technology Co., Ltd., Wenzhou Anghua New Energy Co., Ltd. Main drafters of this Standard. Zheng Ziying, Huang Haiyan, Li Guoli, He Ping, Liu Mingtao, Zhang Yunchang, Zhang Bing, Wang Jianchi, Long Xinhua, Chen Feng, Bao Yikai. Versions of standard substituted by this Standard are. - GB/T 12665-1990, GB/T 12665-2008. Requirements of damp-heat testing of electrical machine for service in general environmental condition1 ScopeThis Standard specifies the damp-heat test method, technical requirements and inspection rules of rotary electrical machine in general environmental condition. This Standard applies to all types of rotary electrical machines (except micro- control electrical machine, hereinafter referred to as the electrical machine).2 Normative referencesThe following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. GB/T 755, Rotating electrical machines - Rating and performance GB/T 2423.3-2006, Environmental testing for electric and electronic products - Part 2.Testing method test Cab. Damp heat Steady state GB/T 2423.4-2008, Environmental testing for electric and electronic products - Part 2.Test method - Test Db. Damp heat, cyclic (12h+12h cycle) GB/T 12113-2003, Methods of measurement of touch current and protective conductor current3 Technical requirements3.1 Insulation resistance 3.1.1 The insulation resistance value between the windings of the whole machine to the casing and the winding shall not be lower than the following values. 3.1.2 When a large-scale motor component is used for the damp-heat test, the insulation resistance converted to the complete machine is determined according to equation (2). 3.4 Running performance The electrical machine shall be able to operate normally. No sticking or other effects on the normal operation of the motor shall occur. The performance shall meet the requirements of relevant product standards.4 Test method4.1 Preparation before test 4.1.1 Test equipment and instruments The damp-heat test chamber shall meet the requirements of Clause 4 of GB/T 2423.4-2008. 4.1.2 Test specimen requirements When the large-scale electrical machine tests components, aluminum foil is used for the measuring electrode of the high-voltage stator winding and the DC electrical machine compensation winding. For slotted insulation and impregnated coils, a simulation slot shall be made. 4.1.3 Pre-treatment of test specimen Before the damp-heat test, the test specimen shall be placed in a hot and humid test chamber for preheating. The preheating temperature is 25°C ~ 35°C. From the time when the temperature of the damp-heat test chamber reaches 25°C, the time is not less than 8h. 4.2 Damp-heat test method According to GB/T 2423.4-2008, perform the alternating damp-heat test. High temperature is generally 40°C. According to the severity of the use of occasions, it can choose 55°C. There are two ways to reduce the temperature (see Figure 1 and Figure 2). Choose one of them to test. The conditions for each test cycle are shown in Figure 1 and Figure 2.Carry out 6 cycles in total. 4.3 Measurement of insulation resistance When carrying out the alternating test, the low temperature and high humidity stage of the last week of the damp-heat test shall be maintained at a temperature of 25°C ± 3°C and a relative humidity of 95% ~ 98%. 4.4 Measurement of leakage current After subjected to the damp-heat test, the leakage current of the electrical machine shall be measured by using the circuit device described in Figure 4 of GB/T 12113-2003. 4.6 Running performance check The check of running performance of the electrical machine shall be completed within 48h after the test specimen is removed from the chamber. The check of running performance shall be carried out in the way of power running. The performance requirements of electrical machine are specified by various professional product standards.5 Inspection rules5.1 General The damp-heat test shall be carried out when the product design stereotype or design, process and material used changes affect the damp-heat resistance of the product. 5.2 Sampling method of sample The damp-heat test of the electrical machine allows a representative product to be sampled by a random sampling method in a series of products of the same structure, the same process, and the same material. 5.3 Number of test specimen 5.4 Determination of test results After the damp-heat test of the electrical machine, if it can meet the requirements of Clause 4, the test results shall be qualified. For the damp-heat test of small and micro electrical machines, if one test result is not qualified, it is allowed to double the number of products for retest. If there is another failure, it is not allowed to leave the factory. For medium and large electrical machines, when the test results are unqualified, it is allowed to retest after effectively eliminating product defects. 5.5 Processing for the unqualified Any electrical machine or component that fails the damp-heat test results is allowed to leave the factory after it has been rectified. ......Source: Above contents are excerpted from the full-copy PDF -- translated/reviewed by: www.ChineseStandard.net / Wayne Zheng et al. Tips & Frequently Asked Questions:Question 1: How long will the true-PDF of English version of GB/T 12665-2017 be delivered?Answer: The full copy PDF of English version of GB/T 12665-2017 can be downloaded in 9 seconds, and it will also be emailed to you in 9 seconds (double mechanisms to ensure the delivery reliably), with PDF-invoice.Question 2: Can I share the purchased PDF of GB/T 12665-2017_English with my colleagues?Answer: Yes. The purchased PDF of GB/T 12665-2017_English will be deemed to be sold to your employer/organization who actually paid for it, including your colleagues and your employer's intranet.Question 3: Does the price include tax/VAT?Answer: Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries) -- See Avoidance of Double Taxation Agreements (DTAs): List of DTAs signed between Singapore and 100+ countriesQuestion 4: Do you accept my currency other than USD?Answer: Yes. www.ChineseStandard.us -- GB/T 12665-2017 -- Click this link and select your country/currency to pay, the exact amount in your currency will be printed on the invoice. Full PDF will also be downloaded/emailed in 9 seconds.Question 5: Should I purchase the latest version GB/T 12665-2017?Answer: Yes. Unless special scenarios such as technical constraints or academic study, you should always prioritize to purchase the latest version GB/T 12665-2017 even if the enforcement date is in future. Complying with the latest version means that, by default, it also complies with all the earlier versions, technically.How to buy and download a true PDF of English version of GB/T 12665-2017?A step-by-step guide to download PDF of GB/T 12665-2017_EnglishStep 1: Visit website https://www.ChineseStandard.net (Pay in USD), or https://www.ChineseStandard.us (Pay in any currencies such as Euro, KRW, JPY, AUD).Step 2: Search keyword "GB/T 12665-2017". Step 3: Click "Add to Cart". If multiple PDFs are required, repeat steps 2 and 3 to add up to 12 PDFs to cart. Step 4: Select payment option (Via payment agents Stripe or PayPal). Step 5: Customize Tax Invoice -- Fill up your email etc. Step 6: Click "Checkout". Step 7: Make payment by credit card, PayPal, Google Pay etc. After the payment is completed and in 9 seconds, you will receive 2 emails attached with the purchased PDFs and PDF-invoice, respectively. Step 8: Optional -- Go to download PDF. Step 9: Optional -- Click Open/Download PDF to download PDFs and invoice. See screenshots for above steps: Steps 1~3 Steps 4~6 Step 7 Step 8 Step 9 |
