JJF 1620-2017: Calibration Specification for Battery Internal Resistance Testers
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
JJF 1620-2017	419	Add to Cart	4 days	Calibration Specification for Battery Internal Resistance Testers	Valid

Similar standards

JJF 1234   JJF 1576   JJG 376   JJF 1617   JJF 1618   JJF 1616

Basic data

Standard ID: JJF 1620-2017 (JJF1620-2017)
Description (Translated English): Calibration Specification for Battery Internal Resistance Testers
Sector / Industry: Metrology & Measurement Industry Standard
Classification of Chinese Standard: A55
Classification of International Standard: 17.220
Word Count Estimation: 18,120
Date of Issue: 2017-02-28
Date of Implementation: 2017-05-28
Quoted Standard: GB/T 2900.41-2008
Regulation (derived from): General Administration of Quality Supervision, Inspection and Quarantine No. 23 of 2017
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine
Summary: This standard applies to the principle of AC injection method of the battery internal resistance tester calibration, with battery resistance test function of the battery test system calibration of the corresponding project can also refer to the implementation of this standard. This standard does not apply to the DC discharge principle of the battery internal resistance tester calibration.

JJF 1620-2017: Calibration Specification for Battery Internal Resistance Testers

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Calibration Specification for Battery Internal Resistance Testers National Metrological Technical Code of the People's Republic of China Battery internal resistance tester calibration specification 2017-02-28 released 2017-05-28 Implementation State Administration of Quality Supervision, Inspection and Quarantine issued Battery internal resistance tester calibration specification Unit. National Electromagnetic Metrology Technical Committee The main drafting unit. Beijing Oriental Metrology and Testing Institute Guangdong Institute of Metrology Participated in the drafting unit. Changzhou Institute of Metrology and Testing Technology Changzhou and Pu Electronic Technology Co., Ltd. Jiangsu Institute of Metrology This specification entrusts the National Electromagnetic Metrology Technical Committee to explain The main drafters of this specification. Tuzhi Guo (Beijing Oriental Metrology and Testing Institute) Sun Xiangping (Beijing Oriental Metrology and Testing Institute) Wu Haiyi (Guangdong Institute of Metrology) Participate in the drafters. Hu Zhiyuan (Beijing Oriental Metrology and Testing Institute) Li Xin (Changzhou Institute of Metrology and Testing Technology) Huangke (Changzhou and Cape Electronic Technology Co., Ltd.) Gao Jie (Jiangsu Institute of Metrology)

table of Contents

Introduction (II) 1 Scope (1) 2 References (1) 3 terms and units of measurement (1) 3.1 Battery internal resistance (1) 4 Overview (1) 5 Metrological characteristics (2) 5.1 Battery internal resistance (2) 5.2 DC voltage (2) 6 Calibration conditions (2) 6.1 Environmental conditions (2) 6.2 Measurement standards and other equipment (2) 7 Calibration items and calibration methods (2) 7.1 Calibration items (2) 7.2 Calibration method (3) 8 Calibration results (5) 8.1 Calibration Certificate (5) 8.2 Data revision (5) 9 re-school time interval (5) Appendix A Battery Internal Resistance Tester Measurement Uncertainty Evaluation Example (6) Appendix B Calibrate Original Record Format (11) Appendix C Calibration Certificate Inside Page Format (12)

Introduction

JJF 1071-2010 "Rules for the preparation of national metrological calibration specifications", JJF 1001-2011 "General measurement terms and Definition ", JJF 1059.1-2012" measurement uncertainty assessment and representation "together constitute the support of the calibration standard development Work of the basic series of norms. This specification is the first release. Battery internal resistance tester calibration specification

1 Scope

This specification applies to the principle of AC injection method of the battery internal resistance tester calibration, with the battery resistance test function Calibration of the corresponding items of the battery test system can also be performed with reference to this specification. This specification does not apply to the principle of DC discharge Calibration of battery internal resistance tester.

2 reference file

This specification refers to the following documents. Electrotechnical terminology - Primary batteries and accumulators GB/T 2900.41-2008 For dated references, only the dated edition applies to this specification; references that are not dated , The latest version (including all modifications) applies to this specification.

3 terms and units of measurement

The following terms and definitions apply to this specification. 3.1 battery internal resistance batteryinternalresistance Under the conditions of the battery voltage changes with the corresponding discharge current changes, also known as the apparent resistance.

4 Overview

Battery internal resistance tester is used to measure the battery resistance of the instrument, according to the purpose can be divided into special and general type, according to the original Can be divided into exchange injection method, DC discharge method. Commonly used battery injection resistance method based on the principle of manufacturing battery resistance test Instrument, generally by the AC constant current source, lock-in amplification unit, DC voltage measurement unit, comparison and alarm circuit and control And instructions (display) and other components, it is applied to the measured object to a certain frequency (usually 1kHz) of the AC current Signal, the use of lock-in amplification technology to measure the measured internal resistance of the battery voltage drop, the internal impedance value. Block diagram of the principle As shown in Figure 1. Figure 1 block diagram of the battery resistance tester ......
