GBZ45463-2025 English PDF

Q: How long will the true-PDF of English version of GBZ45463-2025 be delivered?

Upon your order, we will start to translate GBZ45463-2025_English as soon as possible, and keep you informed of the progress. The lead time is typically 1 ~ 3 working days. The lengthier the document the longer the lead time.

Q: Can I share the purchased PDF of GBZ45463-2025_English with my colleagues?

Yes. The purchased PDF of GBZ45463-2025_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.

Q: Does the price include tax/VAT?

Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries). Avoidance of Double Taxation Agreements (DTAs) between Singapore and 100+ Countries: https://www.iras.gov.sg/taxes/international-tax

Q: Do you accept my currency other than USD?

Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay.

US$299.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GBZ45463-2025: Method for porosity measurement of thermally sprayed coatings
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/Z 45463-2025	299	Add to Cart	3 days	Method for porosity measurement of thermally sprayed coatings	Valid

Similar standards

GB/T 45345 GB/T 43101 GB/T 38518 GB/T 45340 GB/T 45333

Basic data

Standard ID: GB/Z 45463-2025 (GB/Z45463-2025)
Description (Translated English): Method for porosity measurement of thermally sprayed coatings
Sector / Industry: National Standard
Classification of Chinese Standard: A29
Classification of International Standard: 25.220.20
Word Count Estimation: 14,154
Date of Issue: 2025-03-28
Date of Implementation: 10/1/2025
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GBZ45463-2025: Method for porosity measurement of thermally sprayed coatings

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
GB /Z 45463-2025.Determination of porosity of thermal spray coatings ICS 25.220.20 CCSA29 Guiding technical documents of the People's Republic of China on national standardization Determination of Porosity of Thermal Sprayed Coatings sprayed coatings, MOD) Released on 2025-03-28 2025-10-01 Implementation State Administration for Market Regulation The National Standardization Administration issued

Preface III 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 Purpose 1 5 Categories 1 6 Principle 1 7 Equipment 1 8 Metallographic sample preparation 2 8.1 Overview 2 8.2 Cutting 2 8.3 Cleaning 2 8.4 Mosaic 2 8.5 Grinding and polishing 3 9 Metallographic Inspection Process 4 10 Characterization of Porosity 4 11 Test Report 5 Appendix A (Informative) Table of tα values at different n and α values 6

Foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for standardization work Part 1.Structure and drafting rules for standardization documents" Drafting. This document is modified to adopt ISO /T R26946.2011 "Determination of porosity of thermal spray coatings". Compared with ISO /T R26946.2011, this document has made the following structural adjustments. --- Chapter 4 corresponds to Chapter 2 in ISO /T R26946.2011; --- Chapter 5 corresponds to Chapter 3 of ISO /T R26946.2011; --- Chapter 6 corresponds to Chapter 4 of ISO /T R26946.2011; --- Chapter 7 corresponds to Chapter 5 and 5.1~5.6 in ISO /T R26946.2011; --- Chapter 8 corresponds to Chapter 6 of ISO /T R26946.2011; 8.1~8.5 correspond to Chapter 6 of ISO /T R26946.2011 6.1~6.5; --- Chapter 9 corresponds to Chapter 7 of ISO /T R26946.2011; --- Chapter 10 corresponds to Chapter 8 of ISO /T R26946.2011; --- Chapter 11 corresponds to Chapter 9 in ISO /T R26946.2011. The technical differences between this document and ISO /T R26946.2011 and their reasons are as follows. --- Changed the scope of application (see Chapter 1); --- Changed the requirements for equipment and metallographic sample preparation personnel (see Chapter 7, Chapter 5 of ISO /T R26946.2011) to adapt to our Technical conditions of the country; --- Added abrasive size units (see 8.5 Table 2) to adapt to my country's technical conditions; --- Changed the metallographic inspection process requirements (see Chapter 9, Chapter 7 of ISO /T R26946.2011) to adapt to my country's technology condition. The following editorial changes were made to this document. --- Added the introductory words of Appendix A to adapt to the technical conditions of my country; --- Deleted Appendix B (informative). Please note that some of the contents of this document may involve patents. The issuing organization of this document does not assume the responsibility for identifying patents. This document was proposed by the China Machinery Industry Federation. This document is under the jurisdiction of the National Technical Committee for Standardization of Metallic and Non-metallic Coverings (SAC/TC57). This document was drafted by. Wuhan Institute of Materials Protection Co., Ltd. of China Machinery Engineering Academy Group, Anhui University of Technology, Dongfang Electric Group Dongfang Steam Turbine Co., Ltd., Beijing Jinlun Kuntian Special Machinery Co., Ltd., Chongqing University, Shanghai Junshan Surface Technology Engineering Co., Ltd. Shenyang Ruite Heat Meter Power Technology Co., Ltd., Nanning Bureau of Ultra-high Voltage Transmission Company of China Southern Power Grid Co., Ltd., Tianjin Zhujin Technology Technology Development Co., Ltd. The main drafters of this document are. Chen Tongzhou, Zhang Shihong, Wang Wei, You Xiaoming, Wang Fan, Wang Xiaoming, Gong Xiufang, Wei Jiao, Chen Jisheng, Cao Xiaoying, Qian Zhu, Gao Mingchuan, Shi Guizhen, Yi Juan. Determination of Porosity of Thermal Sprayed Coatings

1 Scope

This document describes a method for characterizing the porosity of thermal spray coatings by metallographic observation. This document is applicable to the determination of the porosity of thermal sprayed oxide ceramic coatings (such as Al2O3, ZrO2 and TiO2). The evaluation of the rate can also refer to this method.

2 Normative references

This document has no normative references.

3 Terms and definitions

There are no terms or definitions that require definition in this document.

4 Purpose

The main purpose of measuring porosity is to ensure that the quality of thermal spray coatings is not affected by porosity, especially in critical surfaces with functional requirements. On the surface. This document provides a standard test procedure for determining the porosity of thermal spray coatings as part of a comprehensive quality assurance program. This document is also intended to provide a standard method for determining the porosity of thermal spray coatings.

5 Categories

Due to the characteristics of thermal spraying process, the microstructure of thermal spraying coating is mainly manifested in various pores, microcracks, flat particle interfaces and uncoated particles. Although different terms are used, pores and microcracks are essentially volumes that do not contain coating material. Porosity can be There are closed pores, open pores and micropores. Closed pores appear in the coating as independent or clustered holes, which are not connected to the surface. The closed-cell structure is similar, but it is directly connected to the atmosphere, or different pores are connected and then connected to the atmosphere; micropores have both closed pores and open pores. Their size is measurable only on a microscopic scale. Pores and microcracks differ primarily in their aspect ratio (ratio of major axis to minor axis), so they The proportion of the volume space occupied by pores in the thermal spray coating is called porosity.

6 Principles

The porosity of thermal spray coatings is determined by preparing cross sections of coatings with high microscopic surface quality using an optical microscope. Microscopy or scanning electron microscopy (recommended) to quantify the porosity of the coating being examined by using image analysis techniques on the microscope Evaluate.

7 Equipment

The equipment required to measure the porosity of thermal spray coatings is as follows. ......
