GBZ44938.2-2024: Electrical safety of machinery - Part 2: Examples of application for safety-related sensors used to protect persons
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/Z 44938.2-2024	674	Add to Cart	6 days	Electrical safety of machinery - Part 2: Examples of application for safety-related sensors used to protect persons	Valid

Similar standards

GB/T 40437   GB/T 40431   GB/T 40617   GB/T 21097   GB/T 45827   GB/Z 44938.1

Basic data

Standard ID: GB/Z 44938.2-2024 (GB/Z44938.2-2024)
Description (Translated English): Electrical safety of machinery - Part 2: Examples of application for safety-related sensors used to protect persons
Sector / Industry: National Standard
Classification of Chinese Standard: K09
Classification of International Standard: 29.020
Word Count Estimation: 34,372
Date of Issue: 2024-12-31
Date of Implementation: 2025-07-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GBZ44938.2-2024: Electrical safety of machinery - Part 2: Examples of application for safety-related sensors used to protect persons

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
GB /Z 44938.2-2024.Electrical safety of machinery Part 2.Application examples of sensors for protecting personnel safety ICS 29.020 CCSK09 Guiding technical documents of the People's Republic of China on national standardization Electrical safety of machinery Part 2.Protection of persons Application examples of safe sensors (IEC TR62998-2.2020,Safetyofmachinery-Part 2.Examplesof Released on 2024-12-31 2025-07-01 Implementation State Administration for Market Regulation The National Standardization Administration issued

Table of Contents

Preface III Introduction IV 1 Scope 1 2 Normative references 1 3 Terms and definitions, abbreviations 2 3.1 Terms and Definitions 2 3.2 Abbreviations 2 4 Applications of mobile robots 2 4.1 Overview 2 4.2 SRSS 3 on the Mail Transport Mobile Robot 4.3 SRSS Cleaning Mobile Robot 12 5 Application of container loading and unloading equipment in port logistics 18 5.1 Overview 18 5.2 SRSS 18 of CHE Reference 27 Figure 1 Schematic diagram of outdoor scene 3 Figure 2 A mobile robot with two specific safety zones Figure 3 Combining three SRS into one SRSS and its functions 5 Figure 4 Installation location and sensing area of SRS and safety-related area of SRSS 7 Figure 5 Installation location and sensing area of SRS and safety-related area of SRSS 7 Figure 6 Example of measurement data used to evaluate coverage gap 10 Figure 7 Test device 10 Figure 8 CHE application 18 Figure 9 CHE operation area 19 Figure 10 Structure and safety-related functions of SRSS 21 Figure 11 Safety-related area of SRSS 23 Figure 12 Installation location and sensing area of SRS and safety-related area of SRSS 23 Table 1 Safety related requirements 5 Table 2 Example of SRS confidence information 9 Table 3 SRSS usage information 11 Table 4 Safety related requirements14 Table 5 SRSS usage information 17 Table 6 Safety-related requirements 21 Table 7 Environmental restrictions of SRSS 24 Table 8 SRSS usage information 25

Foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for standardization work Part 1.Structure and drafting rules for standardization documents" Drafting. This document is Part 2 of GB /Z 44938 "Electrical Safety of Machinery". GB /Z 44938 has published the following parts. --- Part 1.Sensors used to protect personnel safety; --- Part 2.Application examples of sensors for protecting personnel safety. This document is equivalent to IEC TR62998-2.2020 "Safety of Machinery Part 2.Application Examples". The following editorial changes were made to this document. --- Change the name of the standard to "Electrical safety of machinery Part 2.Application examples of sensors for protecting personnel safety"; --- Changed the format of Figure 1 and changed the picture in the original IEC text to a line diagram; --- Deleted Note 1 and Note 2 in 4.2.5, which are meaningless after conversion into Chinese standard; --- Changed the errata of the original IEC text, changing "6.2.6" in 5.2.10 to "5.2.6", and "6.2.3" to "5.2.3"; --- Changed the errata of the original IEC text, changing "6.2.3" in Table 6 to "5.2.3", "6.2.5" to "5.2.5", and "6.2.6" to "5.2.6"; --- Changed the list of references. Please note that some of the contents of this document may involve patents. The issuing organization of this document does not assume the responsibility for identifying patents. This document was proposed by the China Machinery Industry Federation. This document is under the jurisdiction of the National Technical Committee for Standardization of Industrial Machinery Electrical Systems (SAC/TC231). This document was drafted by. Beijing Machine Tool Research Institute Co., Ltd., Xi'an Jiaotong University, China University of Petroleum (Beijing), Dongguan Haiyu Baitezhi Energy Equipment Co., Ltd., Zhengzhou Coal Machinery Intelligent Working Face Technology Co., Ltd., and Huanghu (Zhejiang) Precision Machine Tool Co., Ltd. The main drafters of this document are. Xue Ruijuan, Wang Jinjiang, Wu Zhai, Zhang Ying, Li Zhikang, Huang Zuguang, Zhao Libo, Wu Yiran, Zhang Peisen, Gao Zhiguo, Wang Chuting, Lin Qijing, Wang Liujun, Zhang Wenqi, and Dong Wei.

Introduction

Safety-related sensors are mainly used in machinery and equipment where there is a risk of personal injury. Safety-related sensors enable machines to The sensor industry mainly uses general functional safety standards. GB/T 20438 (IEC 61508) series of standards, or mechanical standards in specific fields such as IEC 62061 and ISO 13849 series of standards as However, these standards do not provide guidance on how to avoid design failure or failure to detect faults under specific environmental conditions. GB /Z 44938 specifies the following requirements for sensors or sensor systems. Functional safety specifies the requirements for the systematic development and integration of sensors and sensor systems, filling the gap in specific sensor design standards. to identify gaps in systematic capability verification between the current standards and common functional safety standards for electrical, electronic and programmable electronic control systems. GB /Z 44938 is planned to consist of three parts. --- Part 1.Sensors used to protect personnel safety. The purpose is to improve the safety level of mechanical and electrical equipment in my country and ensure the safety of related The design, manufacture, and use of sensors that protect personnel safety are guided, and the personal safety of employees is standardized. Functional, safety and test requirements of sensors for personnel safety. --- Part 2.Application examples of sensors for protecting personnel safety. The purpose is to provide guidance and application for the use of Part 1 Example. --- Part 3.Sensor technology and algorithms. The purpose is to provide guidance on how to properly implement algorithms to prevent people from suffering intolerable risk. This document provides guidance and application examples for the use of GB /Z 44938.1 and is of great importance to the implementation of GB /Z 44938.1. significance. Electrical safety of machinery Part 2.Protection of persons Application examples of safe sensors

1 Scope

This document provides guidance for the application of GB /Z 44938.1-2024. The following examples are provided. ---Applications related to SRS/SRSS; ---Use SRS/SRSS information from the application perspective; ---Integrate SRS into SRSS for specific applications; and --- Appropriate instructions for use for a given application.

2 Normative references

The contents of the following documents constitute the essential clauses of this document through normative references in this document. For referenced documents without a date, only the version corresponding to that date applies to this document; for referenced documents without a date, the latest version (including all amendments) applies to This document. GB/T 16855.1-2018 Safety of machinery - Safety-related components of control systems - Part 1.General principles for design (ISO 13849-1. 2015, IDT) GB/T 19876-2012 Safety of machinery - Positioning of safety guards related to approach speeds of parts of the human body (ISO 13855. 2010, IDT) GB/T 36530-2018 Safety requirements for robots and robotic equipment Personal assistant robots (ISO 13482.2014, IDT) GB /Z 44938.1-2024 Electrical safety of machinery Part 1.Safety-related sensors for protection of personnel (IEC TS62998-1. 2019) ISO 12100 Safety of machinery - General principles for risk assessment and risk reduction IEC 60721-3-5 Classification of environmental conditions Part 3.Classification and classification of environmental parameter groups and their severity Section 5.Ground vehicles IEC 61496-1 Electrical safety of machinery - Electro-sensitive protective equipment - Part 1.General technical requirements and tests IEC 61496-3 Electrical safety of machinery - Electro-sensitive protective equipment - Part 3.Active optoelectronic diffuse reflective protective devices (AOPD- (AOPDDR)] IEC 62061 Safety of machinery Functional safety of electrical, electronic and programmable electronic control systems related to safety ......
