GBZ44765.3-2024: Systems interface between customer energy management system and the power management system - Part 3: Architecture
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/Z 44765.3-2024	664	Add to Cart	5 days	Systems interface between customer energy management system and the power management system - Part 3: Architecture	Valid

Similar standards

GB/T 51033   GB/T 50082

Basic data

Standard ID: GB/Z 44765.3-2024 (GB/Z44765.3-2024)
Description (Translated English): Systems interface between customer energy management system and the power management system - Part 3: Architecture
Sector / Industry: National Standard
Classification of Chinese Standard: F21
Classification of International Standard: 29.240
Word Count Estimation: 33,361
Date of Issue: 2024-10-26
Date of Implementation: 2025-05-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/Z 44765.3-2024: Systems interface between customer energy management system and the power management system - Part 3: Architecture

---This is an excerpt. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.), auto-downloaded/delivered in 9 seconds, can be purchased online: https://www.ChineseStandard.net/PDF.aspx/GBZ44765.3-2024
GB /Z 44765.3-2024.Interface between user-side energy management systems and grid-side management systems Part 3.Architecture ICS 29.240 CCSF21 Guiding Technical Documents of National Standardization of the People's Republic of China User-side energy management system and grid-side management Interfaces between systems Part 3.Architecture managementsystem-Part 3.Architecture (IEC TS62746-3.2015, IDT) Released on October 26, 2024 Implementation on May 1, 2025 State Administration for Market Regulation The National Standardization Administration issued

Table of Contents

Preface III Introduction IV 1 Scope 1 2 Normative references 1 3 Terms, Definitions and Abbreviations 1 3.1 Terms and Definitions 1 3.2 Abbreviations 3 4 System Architecture Overview 4 4.1 Application Areas 4 4.2 Participants, roles and relationships 5 4.3 Concept 7 4.4 Components/Entities 8 5 Message Transmission and Services 13 5.1 Transmission Requirements 13 5.2 Standards supporting messaging 13 5.3 Message Payload 13 5.4 Message Structure 14 5.5 Message Passing Patterns 15 5.5.1 Overview 15 5.5.2 Transaction Request/Response Message Pattern 15 5.5.3 Query Request/Response Message 16 5.5.4 Event Message 17 5.5.5 State 18 5.6 Publish/Subscribe Messaging 18 6 Security 19 7 Scalability and Availability 20 Appendix A (Informative) Requirement 22 A.1 Overview 22 A.2 Principle 22 A.3 Additional functional requirements related to communication 22 A.4 Non-functional requirements 23 Appendix B (Informative) Message Payload Subset 25 Reference 26 Figure 1 Relationship between IEC 62746 and other standards V Figure 2 Resource-level view 4 Figure 3 High-level example of actors, roles, and their relationships 6 Figure 4 Example of communication domain hierarchy 7 Figure 5 Example of an extended communication domain including operators 8 Figure 6 Communication Domain 9 Figure 7 Implementation example of VTNs and VENs in multiple communication domains 10 Figure 8 Example of multiple communication domains 11 Figure 9 Technology space for a single communication domain in IEC 6274611 Figure 10 Example application of IEC 6274612 Figure 11 CEM and resource relationship 13 Figure 12 Payload Example 14 Figure 13 Transaction request/response message pattern initiated by VTN 15 Figure 14.Transaction request/response message pattern initiated by VEN 16 Figure 15 Query request 16 initiated by VTN Figure 16 Query request initiated by VEN 17 Figure 17 Example of VTN initiated event 17 Figure 18 Example of VEN initiated event 18 Figure 19 Example of a publish/subscribe node Figure 20 Security Overview 20 Figure 21 Scalability and availability configuration Figure B.1 Subset structure 25 Preface This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for standardization work Part 1.Structure and drafting rules for standardization documents" Drafting. This document is Part 3 of GB /Z 44765 "Interface between user-side energy management systems and grid-side management systems". GB /Z 44765 has published the following parts. --- Part 3.Architecture. This document is equivalent to IEC TS62746-3.2015 "Interface between user-side energy management system and grid-side management system Part 3 The document type was adjusted from IEC technical specification to my country's national standardization guidance technical document. Please note that some of the contents of this document may involve patents. The issuing organization of this document does not assume the responsibility for identifying patents. This document was proposed by the China Electricity Council. This document is under the jurisdiction of the National Technical Committee for Standardization of Power System Management and Information Exchange (SAC/TC82). This document was drafted by. China Electric Power Research Institute Co., Ltd., State Grid Electric Power Research Institute Co., Ltd., State Grid Corporation of China State Electric Power Dispatching and Control Center, China Southern Power Grid Electric Power Dispatching and Control Center, Shanghai University of Electric Power, Shandong University, Zhejiang University, Jicheng University Electronics Co., Ltd., Beijing Kedong Electric Power Control System Co., Ltd., Nanjing Nanrui Relay Protection Electric Co., Ltd., Guangdong Power Grid Co., Ltd. Power Dispatching and Control Center of the Company, State Grid Corporation of China East China Branch, State Grid Fujian Electric Power Co., Ltd., Nanjing University of Aeronautics and Astronautics School, Jiangsu Jinwang Testing and Certification Co., Ltd., Nanjing Chunning Electric Power Technology Co., Ltd. The main drafters of this document are. Li Xiaolu, Cao Yang, Li Wei, Sun Dan, Liu Jinbo, Zhou Huafeng, Liang Chenghui, Wang Kangyuan, Zhang Daixin, Zhou Wenjun, Mi Weimin, Yang Shengchun, Cheng Yun, Wan Xiong, Mu Yongzheng, Lu Jiangang, Zhao Ruifeng, Li Yaping, Zhang Liang, Chen Jianhong, Wang Fangdong, Chen Songsong, Peng Zongming, Long Suyan, Feng Kai, Gao Ciwei, Tian Wei, Wang Liwen, Guo Yanmin, Sheng Xiangxiang, Wang Yifan, Dong Kai, Yue Ziyu, Yang Qun, Liu Xiaobo, Wang Man, Zhang Yanxia, Zhou Tianxiang, She Mingyang, Xu Yujie, and Yang Mengjuan.

introduction

The dispatching objects of distribution network are changing from traditional power supply equipment and large users to new user-side controllable resources such as energy storage, microgrid, virtual power plant, etc. Rapid expansion requires standardization of the information interaction architecture from smart grid to smart home/smart building/industrial park, including message transmission and services, communication protocols, etc., to achieve the improvement of grid resilience, reliability and economy and energy saving and efficiency improvement for users. The interface between the user-side energy management system and the grid-side management system is designed to build an interface between the user-side energy management system and the grid-side management system. The information interaction model, which stimulates the response of distributed resources on the user side, is proposed to consist of the following parts. --- Part 2.Use cases and requirements. The purpose is to describe the main pillars of interoperability to assist different technical committees in defining the scope of Covering the system interfaces and communication protocols for the entire chain from smart grid to smart home/smart building/industrial park. --- Part 3.Architecture. The purpose is to establish an interface between the user-side energy management system and the grid-side management system. Architecture. --- Part 10-1.Open Automated Demand Response. The purpose is to specify demand response (DR), pricing and distributed energy resources (DER) Minimal data model and services for communication. --- Part 10-3.Open automated demand response - Smart grid user interface adapted to the IEC common information model. A method is defined to implement a CIM subset containing a DR/DER information model and a utility smart grid user interface (SGUI) Bridging standards to map payloads. This document defines an architecture for IEC 62746 that can be used for the management of user resources and DERs. A resource is a combination of load, generation, and storage resources that can be managed in response to signals provided by the grid or market operator. It can be identified and managed as a single resource with specific capabilities, or as a virtual resource with aggregated capabilities. The architecture focuses on leveraging the Internet to connect grid operators, market operators, distribution system operators, electricity suppliers, aggregators, energy Communication between energy service providers and energy resources. This document makes use of existing IEC standards. The data model of IEC 62746 is based on the Common Information Model and IEC 61850. IEC 62746 is transport-independent. The relationship between IEC 62746 and other IEC and ISO standards is shown in Figure 1. Figure 1 Relationship between IEC 62746 and other standards User-side energy management system and grid-side management Interfaces between systems Part 3.Architecture 1 Scope This document is a standardized guiding technical document that establishes an interface between the user-side energy management system and the grid-side management system. System architecture. DER management system is also a user-side energy management system. 2 Normative references The contents of the following documents constitute the essential clauses of this document through normative references in this document. For referenced documents without a date, only the version corresponding to that date applies to this document; for referenced documents without a date, the latest version (including all amendments) applies to This document. IEC 62351 (all parts) Power systems management and information exchange data and communication security IEC TR62746-2 Interface between user-side energy management systems and grid-side management systems Part 2.Use cases and requirements (Sys- 3 Terms, definitions and abbreviations 3.1 Terms and Definitions The following terms and definitions apply to this document. 3.1.1 aggregation Aggregate the functionality of multiple resources into one virtual resource. NOTE. A common use of aggregation is to aggregate many small resources and provide functionality to the market as a single larger resource. 3.1.2 cascading When a message published in one communication domain causes another message to be published in one or more other communication domains at different levels of the hierarchy Events that occur during a break. 3.1.3 communicationdomain ......
