GB/T 6315-2008 English PDF

US$279.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 6315-2008: Vernier, dial and digital display universal bevel protractors
Status: Valid

GB/T 6315: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 6315-2008	279	Add to Cart	3 days	Vernier, dial and digital display universal bevel protractors	Valid
GB/T 6315-1996	319	Add to Cart	3 days	Vernier universal bevel protractor	Obsolete
GB 6315-1986	239	Add to Cart	2 days	Universal bevel protractor	Obsolete

Similar standards

GB/T 1216   GB/T 22092   GB/T 22097   GB/T 6312   GB/T 6314   GB/T 6313

Basic data

Standard ID: GB/T 6315-2008 (GB/T6315-2008)
Description (Translated English): Vernier, dial and digital display universal bevel protractors
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J42
Classification of International Standard: 17.040.30
Word Count Estimation: 12,178
Date of Issue: 2008-02-02
Date of Implementation: 2008-07-01
Older Standard (superseded by this standard): GB/T 6315-1996; JB/T 10026-1999
Quoted Standard: GB/T 2423.3-1993; GB/T 2423.22-2002; GB 4208-1993; GB/T 17163; GB/T 17164; GB/T 17626.2-1998; GB/T 17626.3-1998
Regulation (derived from): National Standard Approval Announcement 2008 No.2 (Total No.115)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the cursor, universal table with several significant foot angle (hereinafter referred to as "universal angle ruler ") terms and definitions, forms and basic parameters, requirements, test methods, such as logo and packaging.

GB/T 6315-2008: Vernier, dial and digital display universal bevel protractors

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Vernier, dial and digital display universal bevel protractors ICS 17.040.30 J42 National Standards of People's Republic of China Replacing GB/T 6315-1996 Cursor, with table and several significant omnipotent angle ruler Posted 2008-02-02 2008-07-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This standard is GB/T 6315-1996 "universal angle ruler cursor" and JB/T 10026-1999 "table with universal angle ruler" two standard Quasi integration amendment. This standard replaces GB/T 6315-1996 "universal angle ruler cursor." From the date of implementation of this standard, JB/T 10026-1999 "Table with universal angle ruler" void. This standard and GB/T 6315-1996 The main differences are as follows. --- Modify the standard name; --- Increasing the table with universal angle ruler, Digital Universal angle ruler requirements. Appendix A of this standard is an informative annex. The standard proposed by China Machinery Industry Federation. The standard measuring instrument by the National Standardization Technical Committee (SAC/TC132) centralized. This standard is drafted by. Harbin Measuring & Cutting Tool Group Co., Ltd., Guilin Guanglu Measuring Instrument Co., Ltd. Participated in the drafting of this standard. Chengdu into a tool Limited and Wuxi Tools Co., ltd. The main drafters of this standard. in Xiaoxia, Wu Ying, Zhang Wei, Zhu Hongjie, Xing Lin Qiang, Li Long Yong, Kongfu Bao, Chen Yongqi, Luhui Liang. This standard replaces the standards previously issued as follows. --- GB/T 6315-1986; --- GB/T 6315-1996. Cursor, with table and several significant omnipotent angle ruler

1 Scope

This standard specifies the cursor table with several significant omnipotent angle ruler (hereinafter referred to as "universal angle ruler") terms and definitions, forms and basic parameters Number, requirements, and other test methods, marking and packaging. This standard applies to indexing is 2 'and 5', the measurement range of the cursor universal angle 0 ° ~ 320 ° and 0 ° ~ 360 ° ruler; indexing value is 2 'and 5 ', the measurement range of 0 ° ~ 360 ° angle with table omnipotent ruler; resolution of 30 ", the number of measuring range of 0 ° ~ 360 ° angle was omnipotent ruler.

2 Normative references

The following documents contain provisions which, through reference in this standard and become the standard terms. For dated references, subsequent Amendments (not including errata content) or revisions do not apply to this standard, however, encourage the parties to the agreement are based on research Whether the latest versions of these documents. For undated reference documents, the latest versions apply to this standard. GB/T 2423.3-1993 electric and electronic products environmental testing procedures Test Ca. Damp heat test method (eqv IEC 60068-2-3. 1984) GB/T 2423.22-2002 Environmental testing for electric and electronic products Part 2. Test methods - Test N. Temperature change (IEC 60068-2-14. 1984, IDT) GB 4208-1993 housing protection (IP Code) (eqv IEC 529. 1989) GB/T 17163 dimensional measuring instruments - Basic terminology GB/T 17164 dimensional measuring instruments - Product terms GB/T 17626.2-1998 Electromagnetic compatibility - Testing and measurement techniques - Electrostatic discharge immunity test (IEC 61000-4-2.1995, IDT) GB/T 17626.3-1998 Electromagnetic compatibility - Testing and measurement techniques RFEMS test (IEC 61000-4- 3.1995, IDT)

3 Terms and Definitions

GB/T 17163, GB/T 17164 and established in the following terms and definitions apply to this standard. 3.1 Electronic digital display measuring principle of the two surfaces separated by relative rotation angle reading angle measurement instrument. 3.2 Error limit by the technical norms and rules of Universal angle ruler regulations.

4 form and basic parameters

4.1 in the form of universal angle ruler as shown in Figure 1 to 3. Illustration illustration purposes only and does not indicate a detailed structure. ......
