GB/T 5169.31-2022 English PDFUS$244.00 ยท In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email. GB/T 5169.31-2022: Fire hazard testing for electric and electronic products - Part 31: Surface spread of flame - General guidance Status: Valid GB/T 5169.31: Historical versions
Basic dataStandard ID: GB/T 5169.31-2022 (GB/T5169.31-2022)Description (Translated English): Fire hazard testing for electric and electronic products - Part 31: Surface spread of flame - General guidance Sector / Industry: National Standard (Recommended) Classification of Chinese Standard: K04 Classification of International Standard: 13.220.40; 29.020 Word Count Estimation: 14,130 Date of Issue: 2022-10-14 Date of Implementation: 2023-05-01 Older Standard (superseded by this standard): GB/T 5169.31-2008 Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration GB/T 5169.31-2022: Fire hazard testing for electric and electronic products - Part 31: Surface spread of flame - General guidance---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order. Fire hazard testing for electric and electronic products -- Part 31.Surface spread of flame -- General guidance ICS 13.220.40; 29.020 CCSK04 National Standards of People's Republic of China Replacing GB/T 5169.31-2008 Fire hazard test for electrical and electronic products Part 31.General rules for surface spread of flames (IEC 60695-9-1.2013, Firehazard testing- Published on 2022-10-12 2023-05-01 Implementation State Administration for Market Regulation Released by the National Standardization Administration directory Preface I Introduction II 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 Principles of flame spread 5 5 Considerations in choosing a test method6 6 Application and interpretation of test results7 Appendix NA (informative) Part 8 of "Fire Hazard Tests for Electrical and Electronic Products" has been published Reference 10 forewordThis document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for Standardization Work Part 1.Structure and Drafting Rules of Standardization Documents" drafted. This document is part 31 of Fire Hazard Testing of Electrical and Electronic Products. "Fire Hazard Test of Electrical and Electronic Products" has been published See in part in Appendix NA. This document replaces GB/T 5169.31-2008 "Fire Hazard Tests for Electrical and Electronic Products - Part 31.General Surface Spread of Flames" Compared with GB/T 5169.31-2008, in addition to structural adjustment and editorial changes, the main technical changes are as follows. a) In the Scope chapter, a description of the content of this document has been added (see Chapter 1, Chapter 1 of the.2008 edition); b) Changed "Terms and Definitions" (see Chapter 3, Chapter 3 of the.2008 edition). This document is equivalent to IEC 60695-9-1.2013 "Fire Hazard Test Part 9-1.General Rules for Surface Spread of Flame". The following minimal editorial changes have been made to this document. --- In order to be consistent with the existing standard series, the name is changed to "Fire Hazard Test for Electrical and Electronic Products Part 31.Surface Spread of Flame General Rules"; --- Moved IEC Guide104 and ISO /IEC Guide51 in Chapter 2 to References; --- Add informative appendix NA to list the published parts of "Fire Hazard Test for Electrical and Electronic Products". Please note that some content of this document may be patented. The issuing agency of this document assumes no responsibility for identifying patents. This document is proposed by China Electrical Equipment Industry Association. This document is under the jurisdiction of the National Standardization Technical Committee on Fire Hazard Testing of Electrical and Electronic Products (SAC/TC300). This document is drafted by. China Electric Appliance Research Institute Co., Ltd., Guangdong Midea Refrigeration Equipment Co., Ltd., Shenzhen Customs Industry Co., Ltd. Quality Testing Technology Center, the Fifth Electronics Research Institute of the Ministry of Industry and Information Technology, Haiyan Inspection and Testing Co., Ltd., Weikai Testing Technology Co., Ltd., Tsinghua University Shenzhen International Graduate School, Guangdong Shengyi Technology Co., Ltd., Fujian Xinneng Offshore Wind Power R&D Center Co., Ltd., Zhongchuang Ocean Technology Co., Ltd., Zhejiang Yuehua Telecom Co., Ltd., Zhongke Standard (Ningde) Technology Co., Ltd., Beijing Tairuite Testing Technology Service limited liability company. The main drafters of this document. Liu Xin, Zhang Hanping, Yan Jie, Zhang Yuanqin, Wang Qingsong, Liu Yan, Jia Zhidong, Guan Jian, Li Ying, Wang Xilin, He Bo, Wang Sheng, Lin Ying, and Gao Lingsong. The previous versions of this document and its superseded documents are as follows. ---First published in.2008 as GB/T 5169.31-2008; ---This is the first revision.IntroductionFire risk is considered in all circuits. Component, circuit and device design and material screening are designed to reduce the likelihood of fire , even in the event of foreseeable abnormal use, malfunctions and failures. The purpose of "Fire Hazard Test for Electrical and Electronic Products" is to Save lives and protect property by reducing the number or severity of fires. It can be done by. --- Prevent ignition caused by live parts as much as possible, and if ignition occurs, limit the scope of ignition to the enclosure of electrical and electronic products; --- Minimize the spread of the flame to the product shell as much as possible, and will include heat, smoke, toxic or corrosive gases, etc. The harmful effects of the product are minimized. "Fire Hazard Test of Electrical and Electronic Products" now consists of 38 parts, which are divided into three sub-fields. --- Fire hazard test evaluation guidelines and terminology standards, including 1 term and 8 evaluation guidelines, the purpose is for the professional field provide guidelines and reference procedures for fire hazard assessment; --- Small-scale fire test standards, including 4 basic test methods for glow wire/hot wire, 9 flame test methods, and 2 abnormal resistance The purpose of this paper is to introduce the method of thermal capability test, which is suitable for the use of electrical and electronic equipment manufacturers and testing institutions, with a specific heat source model. Small-scale test methods for heat sources intended to cause fires; --- Risk assessment criteria for combustion flow, including 2 corrosiveness, 2 smoke haze, 5 toxicity, 3 heat release, 2 flame surface Spread, the purpose is to provide measurement of combustion flow toxicity, corrosiveness, smoke haze and heat release of electrical and electronic products and their materials Guidelines and the state of the art in current test methods. Heat (thermal hazard) and toxic combustion streams, corrosive combustion streams and fumes (non-thermal hazard) resulting from fire are hazardous to life and property important cause of harm. The fire hazard increases with the size of the burning area, leading to flashover and complete fire in some cases. This is a typical fire situation for a building to catch fire. It is therefore useful to measure the speed and extent of the spread of the flame surface. The flame spread test aims to Provides guidance for product committees wishing to incorporate test methods for surface spread of flame into product standards. Consists of two parts. --- Part 31.General rules for the spread of flame surface. The purpose is to evaluate the flame spread on the surface of electrical and electronic products and materials used. general guide. --- Part 20.Summary and relevance of test methods for surface spread of flames. The purpose is to provide evaluation of electrical and electronic products or their General test method for surface spread of flame from materials. The rate at which a flame surface spreads is the distance traveled by the flame front divided by the time it takes to travel that distance. The rate at which the flame spreads over the surface of the Depends on the heat provided by the flame of the burning material outside and/or in front of the combustion zone, and the ease of ignition. The ease of ignition is material A function of minimum light-off temperature, thickness, density, specific heat capacity and thermal conductivity. The heat provided by the flame depends on the rate of heat release, the orientation of the specimen, Air velocity and direction of air flow relative to the flame direction surface spread. In general, materials exhibit one of the following flame surface spread characteristics. a) No spread. no flame spread beyond the ignition area; b) slow spread. flame spread stops before reaching the end of the material surface; and c) Spread. The flame spreads beyond the ignition area, eventually affecting the entire surface of the material. Properties of materials used to describe the surface spread of flame and surface preheating and pyrolysis, steam generation, mixing of steam with air, ignition, mixing Combustion of compounds and the generation of heat and combustion products. Flame retardants and surface treatments are used to reduce the surface spread of flames. Evaluation material The factors that need to be considered for the spread of flame surface are. 1) Fire situation (including parameters such as surface orientation, ventilation and nature of ignition source); 2) method of measurement (see 5.5); and 3) Use and interpretation of the results obtained (see Chapter 6). Fire hazard test for electrical and electronic products Part 31.General rules for surface spread of flames1 ScopeThis document gives guidelines for assessing the spread of flame on surfaces of electrical and electronic products and materials used. include. --- Explanation of the principle of flame spread on liquid and solid surfaces; --- Guidelines for the selection of test methods; --- Guidelines for the application and interpretation of test results; ---references. This document is intended for use by technical committees in the preparation of standards based on the principles set out in IEC Guide 104 and ISO /IEC Guide 51. One of the tasks of technical committees is to use this series of standards wherever applicable when preparing standards in the field. unless relevant Standard specifically mentioned or listed, the requirements of this document, test methods or test conditions will not apply.2 Normative referencesThe contents of the following documents constitute essential provisions of this document through normative references in the text. Among them, dated citations documents, only the version corresponding to that date applies to this document; for undated references, the latest edition (including all amendments) applies to this document. ISO 2592 Petroleum and related products - Method for determination of flash point and fire point - Cleveland open cup method (Petroleum and related Note. GB/T 3536-2008 Determination of flash point and fire point of petroleum products Cleveland open cup method (ISO 2592.2000, MOD) ISO 13943.20081) Fire Safety Vocabulary (Firesafety-Vocabulary) 1) There is a new version of ISO 13943.2017. IEC 60695-4 Fire Hazard Testing Part 4.Terminology for Fire Hazard Testing of Electrical Products (Firehazard testing-Part 4. Note. GB/T 5169.1-2015 Fire Hazard Test for Electrical and Electronic Products Part 1.Terminology for Fire Test (IEC 60695-4.2012, IDT)3 Terms and DefinitionsTerms and definitions defined in IEC 60695-4 and ISO 13943.2008 and the following terms and definitions apply to this document. 3.1 burning combustion An exothermic reaction between a substance and an oxidant. NOTE. Combustion usually emits a combustion stream, accompanied by a flame (3.11) and/or glow. [Source. ISO 13943.2008, 4.46] 3.2 damage area damagedarea The sum of the surface areas permanently damaged by fire (3.6) under the specified conditions. NOTE 1 The user of this term should state the type of damage considered. Includes, for example, material loss, deformation, softening, melting, charring, combustion (3.1), pyrolysis (3.25) or chemical attack. ...... |
