GB/T 5089-2017: General technical requirements for fan motors
Status: Valid

GB/T 5089: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 5089-2017	199	Add to Cart	3 days	General technical requirements for fan motors	Valid
GB/T 5089-2008	399	Add to Cart	3 days	General technical requirements for fan A.C. motors	Obsolete
GB/T 5089-2003	399	Add to Cart	3 days	General technical conditions of the AC electric fan motor	Obsolete
GB/T 5089-1985	239	Add to Cart	2 days	General specification for AC table-fan motors	Obsolete

Similar standards

GB/T 39631   GB/T 12665   MT/T 575   GB/T 30144   GB/T 21974

Basic data

Standard ID: GB/T 5089-2017 (GB/T5089-2017)
Description (Translated English): General technical requirements for fan motors
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: K26
Classification of International Standard: 29.160.30
Word Count Estimation: 10,132
Date of Issue: 2017-11-01
Date of Implementation: 2018-05-01
Older Standard (superseded by this standard): GB/T 5089-2008
Regulation (derived from): National Standard Announcement 2017 No. 29
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China

GB/T 5089-2017: General technical requirements for fan motors

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
General technical requirements for fan motors ICS 29.160.30 K26 National Standards of People's Republic of China Replacing GB/T 5089-2008 Electric fans with fans General technical requirements Posted.2017-11-01 2018-05-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China China National Standardization Administration released Directory Preface Ⅰ 1 Scope 1 2 Normative references 1 3 models, the basic parameters and size 1 4 technical requirements 2 5 test methods 6 6 Inspection rules 6 7 packaging, transportation and storage 7

Foreword

This standard was drafted in accordance with the rules given in GB/T 1.1-2009. This standard replaces GB/T 5089-2008 "AC fan motor general technical conditions", compared with the GB/T 5089-2008 main Technical changes are as follows. --- Standard scope of application extends to the permanent magnet brushless DC motor (see Chapter 1); --- Updated normative references (see Chapter 2); --- Increased recommended motor recommended blade (wing) diameter recommended (see 3.5) --- Modify the technical requirements of the motor input power (see 4.7); --- Deleted for the efficiency of the motor requirements, revised to the maximum motor speed requirements (see 4.8); --- Increased motor speed ratio requirements (see 4.10); --- Increasing the requirements of no-load test (see 4.11); --- Modify the motor noise limit requirements (see 4.12); --- Remove the original standard 4.8,4.9,4.10,4.11,4.12,4.15,4.16,4.17,4.18,4.20 About temperature rise, leakage current, dielectric Can, winding insulation resistance, withstand voltage, humidity test, capacitor voltage, creepage distance and clearance, electromagnetic compatibility, grounding measures Shi provisions, summarized as safety requirements should be consistent with the provisions of GB/T 12350 (see 4.13); --- Modify the electrical tolerance of the electrical performance tolerance requirements (see 4.14); --- Deleted the life expectancy; --- Modify the motor input power measurement method (see 5.1); --- Deleted the original standard 6.2.4 in the corresponding type test pass determination requirements; --- Removed the quality assurance requirements. This standard proposed by the China Electrical Equipment Industry Association. This standard by the National Standardization Technical Committee rotating electrical (SAC/TC26) centralized. This standard was drafted unit. China Electric Apparatus Research Institute Co., Ltd., Guangdong Midea Environmental Electric Manufacturing Co., Ltd., Guangdong Welling Motor Manufacturing Co., Ltd. Beijing Jingyi dedicated Electrical Technology Co., Ltd., Zhuhai Kaibang Motor Manufacturing Co., Ltd., Wei Kai Detection Technology Co., Ltd., Zhejiang Lian Yi Motor Co., Ltd., Yueqing Haiyu Intelligent Technology Co., Ltd., Xi'an Xumai Smart Home Appliances Technology Co., Ltd., Xiamen Xiaoxunxin Energy Technology Co., Ltd., Dongguan City, Chi Heng Household Appliances Technology Co., Ltd., Xiamen, Extension Electric Technology Co., Ltd., Wenzhou Ang Wah New Energy Limited. The main drafters of this standard. Wu Yunshan, Li Dianfei, Yang Zhonghua, Zhang Bing, Liu Mingtao, Yao Lei, Chen Dong lock, Zheng Zaiying, Wu Lingyun, Chen Fangyue, Chen Peixian, Chen Feng, Lu Min Guo, Ni Yong, Bao Yat Kai. This standard replaces the standards previously issued as. --- GB/T 5089-1985, GB/T 5089-2003, GB/T 5089-2008. Electric fans with fans General technical requirements

1 Scope

This standard specifies the electric fan motor (hereinafter referred to as the motor) model, the basic parameters and dimensions, technical requirements, test methods, seized The rules, packaging, transportation and storage requirements. This standard applies to the fan capacitor operation of asynchronous motors, shaded pole asynchronous motors and permanent magnet brushless DC motor. Note. Fan motor (hereinafter referred to as the motor) refers to the fan connector above the head, except outside the connecting rod, cover shell, grille, blades (wings).
