GB/T 4458.3-2013: Mechanical drawings -- Axonometric drawings
Status: Valid

GB/T 4458.3: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 4458.3-2013	399	Add to Cart	3 days	Mechanical drawings -- Axonometric drawings	Valid
GB/T 4458.3-1984	399	Add to Cart	3 days	Mechanical drawings--Axonometric drawings	Obsolete

Similar standards

GB/T 4096.1 GB/T 5097 GB/T 4249 GB/T 4459.7 GB/T 4460 GB/T 4457.5

Basic data

Standard ID: GB/T 4458.3-2013 (GB/T4458.3-2013)
Description (Translated English): Mechanical drawings -- Axonometric drawings
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J04
Classification of International Standard: 01.100.20
Word Count Estimation: 17,169
Older Standard (superseded by this standard): GB/T 4458.3-1984
Quoted Standard: GB/T 4457.4; GB/T 6567.5; GB/T 14692; GB/T 16948; GB/T 26099.4
Regulation (derived from): National Standards Bulletin No. 25 of 2013
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the method of drawing isometric view of three commonly used. This section applies to manual and computer drawing isometric drawings; also applies to the three-dimensional model projection drawing.

GB/T 4458.3-2013: Mechanical drawings -- Axonometric drawings

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Mechanical drawings. Axonometric drawings ICS 01.100.20 J04 National Standards of People's Republic of China Replacing GB/T 4458.3-1984 Mechanical Drawing isometric view Issued on. 2013-12-17 2014-10-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Introduction Ⅲ 1 Scope 1 2 Normative references 1 3 Terms and definitions 4 1 General Provisions 5 painting 3 6 Dimensioning 8 7 piping system isometric view of the representation 10 Appendix A (informative) isometric exploded view 11

Foreword

This section drafted in accordance with GB/T 1.1-2009 given rules. This Part replaces GB/T 4458.3-1984 "Mechanical Drawing isometric view." This portion of the GB/T 4458.3-1984 compared to the main technical changes are as follows. --- Increase the "scope", "Normative references" "Terms and Definitions" and add the relevant content; --- To increase the standard legend corresponding map name; --- An increase of 4.3 "Three-dimensional pattern of requirements"; --- Increased Chapter 7, "piping system isometric view of representation"; --- Remove Appendix A. This part of the National Technical product documentation Standardization Technical Committee (SAC/TC146) and focal points. This section is drafted. the machine Productivity Promotion Center, Hefei Kaibang Motor Co., Ltd., China Electronics Technology Group Corporation thirty-eighth Institute of Information Technology Co., Ltd. Beijing Branch of the new millennium, Anhui Hongqiao Metal Manufacturing Co., Ltd., Dalian Maritime University, Hefei University of Technology, Jiangsu Institute of Technology. The main drafters of this section. thanks to Yang, Zhang Xiaojun, Li Rong, Zhang Xiangxiang, Cheng May Fourth Chen Xingyu, Chendi Jiang, Liu Jing, Yuchang Guo, Jin Chenyi, Like Shun, Li Daisong, Zhang Hongqi, Gao Hongwei, Zou Yutang, Li Xue Jing, Wang Huai Germany. This part of the standard replaces the previous editions are. --- GB/T 4458.3-1984. Mechanical Drawing isometric view

1 Scope

GB/T 4458 This section specifies the method of drawing an isometric view of the three commonly used. This section applies to hand-drawn and computer isometric view; also applies to the three-dimensional model projection drawing.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. GB/T 4457.4 Mechanical drawings Fatou line Graphics Graphical symbols line GB/T 6567.5 Technical drawings of piping systems, fittings and valves symbol isometric drawing method GB/T 14692 Technical drawings - Projection Method GB/T 16948 Technical product documentation - Vocabulary term projection GB/T 26099.4 three-dimensional modeling of mechanical products General Rules Part 4. The model projection drawing

3 Terms and Definitions

The following terms and definitions apply to this document. 3.1 Isometric view axonometricdrawings The object together with its reference to a Cartesian coordinate system, a direction not parallel to any coordinate plane direction, with parallel projection method to cast a single vote Movies surface of the resulting graph. 3.2 Shaft angle axesangle Isometric view of the angle between the two isometric axes. 3.3 Axial stretching coefficient coefficientofaxialdeformation The ratio of the length unit a unit length corresponding axonometric projection axis of the shaft. OX, stretching coefficient OY, OZ axis respectively p, q and r are simplified representations.

4 General Provisions

4.1 isometric drawings can theoretically infinite variety, but the simple mapping and other factors to consider, generally use the following three kinds. 4.1.1 isometric view of Acronym isometric (Figure 1). ......
