GB/T 44522-2024: Printing machinery - Technical specification for centralized ink supply system
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 44522-2024	279	Add to Cart	3 days	Printing machinery - Technical specification for centralized ink supply system	Valid

Similar standards

GB/T 40286 GB/T 38220 JB/T 10247 GB/T 44685 GB/T 15110.2

Basic data

Standard ID: GB/T 44522-2024 (GB/T44522-2024)
Description (Translated English): Printing machinery - Technical specification for centralized ink supply system
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J87
Classification of International Standard: 37.100.10
Word Count Estimation: 14,188
Date of Issue: 2024-09-29
Date of Implementation: 2024-09-29
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 44522-2024: Printing machinery - Technical specification for centralized ink supply system

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS 37.100.10 CCSJ87 National Standard of the People's Republic of China Technical specification for centralized ink supply system of printing machinery Released on 2024-09-29 2024-09-29 implementation State Administration for Market Regulation The National Standardization Administration issued

Preface III Introduction IV 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 Classification and structural composition 2 4.1 Classification 2 4.2 Structural composition 2 5 Design Requirements 2 5.1 Basic Requirements 2 5.2 Ink pump station 2 5.3 Pipeline 2 5.4 Ink filling device 2 5.5 Control System 3 6 System performance requirements 3 7 Upgrade 3 8 Safety protection requirements 3 9 Installation Requirements 3 10 System performance test, inspection and document handover 4 10.1 System performance test 4 10.2 Inspection 4 10.3 Document Handover 5 11 Maintenance 5 Appendix A (Normative) Printing Enterprise Demand Questionnaire 6 Appendix B (Normative) Design Scheme Detailed List 7 Appendix C (Normative) Maintenance plan for centralized ink supply system 8 Appendix D (Informative) Maintenance Record Sheet 9 Table 1 Inspection Items 4 Table A.1 Printing Enterprise Demand Survey 6 Table B.1 Design scheme details 7 Table C.1 Maintenance plan details 8 Table D.1 Maintenance Record 9

Foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for standardization work Part 1.Structure and drafting rules for standardization documents" Drafting. Please note that some of the contents of this document may involve patents. The issuing organization of this document does not assume the responsibility for identifying patents. This document was proposed by the China Machinery Industry Federation. This document is under the jurisdiction of the National Printing Machinery Standardization Technical Committee (SAC/TC192). This document was drafted by. Guangzhou Qiancai Paper Printing Co., Ltd., Shenzhen Yutong Packaging Technology Co., Ltd., Zhongshan Baoshi Printing Equipment Co., Ltd., Foshan Lacker Fluid Technology Co., Ltd., Beiren Intelligent Equipment Technology Co., Ltd., Wuhan Jerrys Machinery Co., Ltd. Co., Ltd., Guangdong Wangying Environmental Protection Packaging Industry Co., Ltd., Beijing Zhongke Printing Co., Ltd., Zhejiang Shuchuang Intelligent Equipment Co., Ltd., Beijing Li Madun Pacific Packaging Co., Ltd., Shanghai Publishing and Printing College, Zhejiang Maili Electromechanical Co., Ltd., Zhejiang Yaxin Packaging Materials Co., Ltd. Ltd., Zhejiang Zhongte Machinery Technology Co., Ltd., Suzhou Coswood Color Technology Co., Ltd., Shenzhen Runtianzhi Digital Equipment Co., Ltd. Co., Ltd., Beijing Xinhua Printing Co., Ltd., Wenzhou Globo Electronics Co., Ltd., Hubei Jinghua Color Printing Co., Ltd., Yunnan Provincial Government The Second Printing Center of the Administrative Bureau of Finance, Zhejiang Meige Machinery Co., Ltd., Suzhou Yutong Printing Co., Ltd., Guangdong Xingyi Digital Printing Co., Ltd. Co., Ltd., China Printing Science and Technology Research Institute Co., Ltd. The main drafters of this document are. Wu Wei, Wang Zejie, Liang Yongjun, Su Xiaoyan, Zhao Bohang, Ren Yuanhua, Liu Yangcheng, Liu Shuiyuan, Wang Mingli, Qiu Shuai, Ruan Wei, Tian Min, Li Xiaoping, Zhong Shihui, Zeng Jianjun, Cai Yongbin, Huang Feng, Wu Guanhua, Qiao Junwei, Gong Yun, Ye Wenzhe, Liu Bing, Kong Xiuying, Lin Xiaoyu, Lin Shichao, Sha Jihong, Xu Xing, Liu Hongnian, Li Liang, Wen Cun, Fang Qinshuang, Huang Xingbo, Hu Chao, Gao Ziqiang, Ma Xingyu, Mu Yunhong, Liu Guofang, Lou Bo, Zhao Xiaobing, Huang Zhen, Peng Ming, Ning Wenxiong.

Introduction

The centralized ink supply system can supply ink safely, stably, reliably and quantitatively, freeing the printer operator from the need to frequently add ink. In the future, it will not only improve the utilization rate of ink, but also reduce the emission of volatile organic compounds (VOCs) and protect the ecological environment. Printing companies have installed and renovated centralized ink supply systems. Since centralized ink supply systems need to be based on user needs and workshop layout At present, there is no scientific detection and evaluation method for the testing and acceptance of the centralized ink supply system. This document combines the standardization of the centralized ink supply system design process with the standardization of system components. Standardizing and requiring the entire process of installation, use, and upgrading and transformation will be conducive to the promotion and application of centralized ink supply technology in the industry, improving the quality of the products from the source. Improve ink utilization efficiency, reduce the cost of ink centralized supply transformation, accelerate printing enterprises to achieve green control of production process, and build a green, circular, The low-carbon printing ecology supports the high-quality development of the printing industry. Technical specification for centralized ink supply system of printing machinery

1 Scope

This document defines the classification and structural composition of the centralized ink supply system, and stipulates system design, system performance, upgrade and transformation, safety protection, Requirements for installation, performance inspection, acceptance inspection, document handover and maintenance. This document is applicable to centralized ink supply systems for offset printing presses, centralized ink supply systems for gravure, flexographic and screen printing presses. For reference only, not suitable for centralized ink supply systems for digital printing presses.

2 Normative references

The contents of the following documents constitute essential clauses of this document through normative references in this document. For referenced documents without a date, only the version corresponding to that date applies to this document; for referenced documents without a date, the latest version (including all amendments) applies to This document. GB/T 5226.1-2019 Electrical safety of machinery Electrical equipment of machinery Part 1.General technical requirements GB/T 8163-2018 Seamless steel pipe for conveying fluids GB/T 13277.1-2023 Compressed air Part 1.Pollutant purification levels GB/T 19672-2021 Technical requirements for pipeline valves GB/T 20801.4-2020 Pressure piping specification Industrial piping Part 4.Fabrication and installation GB/T 20801.6-2020 Pressure piping specification Industrial piping Part 6.Safety protection

3 Terms and definitions

The following terms and definitions apply to this document. 3.1 The ink pump is used to transport the ink stored in the ink tank (barrel) through a closed pipeline to one or more printing presses to realize the ink supply. The corresponding system. Note. The capacity of the ink storage tank is usually.200L. 3.2 Ink pump inkpump A device that delivers or pressurizes ink through a gear pump or a plunger pump. 3.3 Ink pump station inkpumpstation The area where one or more ink pumps and their associated equipment are located. Note. Accessories do not include ink tanks. 3.4 Inkadding device A device that adds a certain amount of ink to the ink fountains (or ink trays, ink chambers) of each color group of a printing press through ink supply tubes. ......
